Summary of Contents for Ancona WPRO30
- Page 1 Wall Range Hood User Manual Installation Instructions IMPORTANT SAFETY INSTRUCTIONS Carefully read the important information regarding installation, safety and maintenance. Keep these instructions for future reference. MAAN1132-03 2020-04-17...
-
Page 2: Before You Begin
Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 and 5 and Installation Instructions are on pages 9 to 14. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood. -
Page 3: Table Of Contents
Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 6 Range Hood Dimensions ........................7 Specifications ............................ 7 Mounting Brackets ..........................8 Installation ............................9 Step 1 - Read the Safety Instructions .................... 9 Step 2 - Unpack Range Hood and Prepare Tools ................ -
Page 4: Important Safety Information
Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using the range hood to prevent the risk of fire, electric shock, personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur. - Page 5 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high • Extinguish any open flame. settings. Boilovers cause smoking and greasy • DO NOT turn on the lights or any type of appliance.
-
Page 6: Included Parts
Included Parts Vent/Damper Hood Mounting Bracket Main Housing Upper Chimney Bracket Lower Chimney Bracket Lower Chimney 2 Filters 4 + 1 Damper Screws Upper Chimney 6 + 1 Chimney Screws Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. -
Page 7: Range Hood Dimensions
Range Hood Dimensions 17.2 cm (6.75 in.) 22.2 cm (8.75 in.) 40 - 78 cm (15.75 - 30.7 in.) 30 cm (11.8 in.) 4 cm (1.5 in.) 60 cm (23.6 in.) 50 cm (19.6 in.) Specifications Body Design Stainless Steel Power Rating 120 V / 60 Hz (cULus Certified) Total Input Power... -
Page 8: Mounting Brackets
Mounting Brackets Upper Chimney Bracket 4 7/8” (124 mm) 8 5/8” (219 mm) Lower Chimney Bracket 8” (203 mm) 4 5/8” (119 mm) 8 5/8” (219 mm) Mounting Bracket Hook 7 7/8” (200 mm) 3 15/16” (100 mm) 3 15/16” (100 mm) 8 5/8”... -
Page 9: Installation
Installation STEP 1 Read the Safety Instructions • It is very important to read the safety instructions on pages 4 and 5. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools • Carefully unpack the range hood and parts. -
Page 10: Step 5 - Venting Installation Guidelines
Installation STEP 5 Venting Installation Guidelines • The following steps are for exterior ventilation. For the most efficient and quiet operation: IMPORTANT: • It is recommended that the range hood be vented • Vent system must terminate to the outside (roof or side wall). vertically through the roof through 6 in. (15.3 cm) or • DO NOT terminate the vent system in an attic or other bigger round metal/aluminum vent work. - Page 11 Installation IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) • A minimum of 6 in. (15.3 cm) round or 3-1/4 x 10 in. (8.3 cm for electric cook tops. x 25.4 cm) rectangular duct (purchased separately) must be • It is important to install the hood at the proper mounting used to maintain maximum airflow efficiency.
-
Page 12: Step 6 - Preparations
Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. • Determine and mark the center line on the ceiling or wall where the range hood will be installed. • Make sure there is proper clearance within the ceiling or wall for exhaust vent. • Due to the weight and size of this unit, please make sure that the support system or framework being used is stable and secure in the ceiling or wall. -
Page 13: Step 10 - Mount Range Hood Onto Wall
Installation STEP 10 Mount Range Hood onto Wall • Hang the range hood on the hooks of the hood mounting bracket. (See Figure #3) • Screw the range hood to the wall. CAUTION - Make certain the range hood is secure before releasing! Fig #3 STEP 11... -
Page 14: Step 13 - Connect To Ac
Installation STEP 13 Connect to AC • Connect AC plug into a grounded AC outlet having 120V, 3-Pronged Plug 60Hz. Place the outlet at a maximum distance of 33-1/2 in. (851 mm) from where the cord exits on the hood. Ground Plug 3-Prong Receptacle IMPORTANT: • Observe all governing codes and ordinances. • It is the customer’s responsibility to contact a qualified electrical installer. • If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line. -
Page 15: Operation
Operation Increase Decrease Timer Light Speed Speed Power Settings Lights Press the button once and the motor starts to Press the light button to turn halogen lights on operate at Low speed. and off. Press the button and the motor will reach Medium speed. -
Page 16: Maintenance
Maintenance Replacing the Light Bulbs IMPORTANT: ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN PANEL BEFORE CARRYING OUT ANY OPERATION ON THE APPLIANCE. This range hood uses halogen bulbs: 20 W 12 V type G4. Make sure the range hood is unplugged or turn OFF Wear a cotton glove or use a cloth to handle the breaker. -
Page 17: Range Hood Assembly
Range Hood Assembly Number Part Flexible tube-optional Upper chimney Lower chimney Upper chimney bracket Lower chimney bracket Power cord Air metal outlet Hood mounting bracket Connection plate Rear plate Housing Decorative plate Front plate Light Electronic box PCB board Capacitor Transformer Transformer box Grid... -
Page 18: Assembly
Assembly Capacitor Circuit Diagram 0V 60Hz Main PCB Driver Blower Assembly Number Part Charcoal Bracket Blower Net Rubber Bracket Cover of Rubber Bracket Motor Blower of Motor Electrical Assembly Number Part Electrical box base Electrical cover Capacitor Screw (ST3*10) Screw (ST3*6) —... -
Page 19: Use And Care Information
Use and Care Information Operations • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing. - Page 20 Ancona is in association with Mr Appliance for all after sales service calls. Please contact their service provider or visit their website: Phone: 888-998-2011 Website: www.mrappliance.com MAAN1132-03 © 2020 Copyright of Ancona Home. All rights reserved. This material may not be reproduced, displayed, modified or distributed. — 20 —...
