- Page 1 Ancona Range Hood GCB630 and GCB636 User Manual & Installation Instructions IMPORTANT SAFETY INSTRUCTIONS Carefully read the important information regarding installation, safety and maintenance. Keep these instructions for future reference. MAAN1528-01 2018-11-14...
-
Page 2: Before You Begin
Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 and 5 and Installation Instructions are on pages 9 to 15. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood. -
Page 3: Table Of Contents
Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 6 Range Hood Dimensions ........................7 Specifications ............................ 7 Mounting Brackets ..........................8 Installation ............................9 Step 1 - Read the Safety Instructions .................... 9 Step 2 - Unpack Range Hood and Prepare Tools ................ -
Page 4: Important Safety Information
Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using the range hood to prevent the risk of fire, electric shock, personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur. - Page 5 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high • Extinguish any open flame. settings. Boilovers cause smoking and greasy • DO NOT turn on the lights or any type of appliance.
-
Page 6: Included Parts
Included Parts Damper Range Hood Hood Mounting Bracket Lower Chimney Upper Chimney Bracket Lower Chimney Bracket Upper Chimney 4 + 1 Screws C 4 + 1 Screws / Washers D Installation of Glass Canopy Installation of Glass Canopy 2 Filter 4 + 1 Chimney Screws F 4 + 1 Damper Screws E Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to... -
Page 7: Range Hood Dimensions
Range Hood Dimensions 27.5 cm (10.8 in.) 30.5 cm (12 in.) 55.4 - 104.4 cm (21.8 - 41.1 in.) 7.9 cm (3.1 in.) 74.8 cm (29.4 in.) / 50 cm (19.6 in.) 89.5 cm (35.2 in.) Specifications Body Design Stainless Steel Power Rating 120 V / 60 Hz (cETLus Certified) Total Input Power... -
Page 8: Mounting Brackets
Mounting Brackets Upper Chimney Bracket 30.1 cm (11.8 in.) 16.2 cm (6.3 in.) 3.8 cm (1.5 in.) Lower Chimney Bracket 28.7 cm (11.3 in.) 16.1 cm (6.3 in.) 3.8 cm (1.5 in.) 28.1 cm (11 in.) 29.9 cm (11.7 in.) Mounting Bracket Hook 10 cm (3.9 in.) 10 cm (3.9 in.) -
Page 9: Installation
Installation STEP 1 Read the Safety Instructions • It is very important to read the safety instructions on pages 4 and 5. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools • Carefully unpack the range hood and parts. -
Page 10: Step 5 - Venting Installation Guidelines
Installation STEP 5 Venting Installation Guidelines • The following steps are for exterior ventilation. For the most efficient and quiet operation: IMPORTANT: • It is recommended that the range hood be vented • Vent system must terminate to the outside (roof or side wall). vertically through the roof through 6 in. (15.3 cm) or • DO NOT terminate the vent system in an attic or other bigger round metal/aluminum vent work. - Page 11 Installation IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) • A minimum of 6 in. (15.3 cm) round or 3-1/4 x 10 in. (25.4 cm for electric cook tops. x 8.3 cm) rectangular duct (purchased separately) must be • It is important to install the hood at the proper mounting used to maintain maximum airflow efficiency.
-
Page 12: Step 6 - Preparations
Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. • Determine and mark the center line on the ceiling or wall where the range hood will be installed. • Make sure there is proper clearance within the ceiling or wall for exhaust vent. • Due to the weight and size of this unit, please make sure that the support system or framework being used is stable and secure in the ceiling or wall. -
Page 13: Step 10 - Installing The Damper
Installation STEP 10 Installing the Damper • Fix the damper on the top vent of hood with four screws E. (See Figure #3) • If ventilation system is equipped with an external air duct with a different diameter, apply a reduction fitting. However, for maximum performance and safety, a 6 in. -
Page 14: Step 13 - Install Chimney
Installation STEP 13 Install Chimney Inner Chimney Bracket • Place chimney on top of the main housing. • Remove the protective coating from the upper chimney. Carefully slide the upper chimney down into the lower chimney. • Use two screws F to fix the two chimneys together with the lower chimney bracket, make sure upper chimney is moving freely. -
Page 15: Step 15 - Install Filters
Installation STEP 15 Install Filters To install filters for the following three steps (See Figure #8): • Angle the filter into slots at the left side of the hood. • Push the button on handle of the filter. • Release the handle once the filter fits into a resting position. Fig #8 Maintenance Cleaning Filters... -
Page 16: Operation
Operation 15 minute delay On / Off / Light Slow down Speed Up Power settings Timer Function Press the button once and the motor starts to The control module provides the option to run the motor for operate at Low speed. a predetermined time period in order to evacuate remaining vapors from the kitchen. -
Page 17: Range Hood Assembly
Range Hood Assembly Number Part Baffle filter Blower assembly Touch Switch board Touch Switch Touch Switch box bracket Switch Guide wire Lamp Guide wire LED puck lights Tempered glass Decorative strip Electrical box base LED puck lights driver 3 holes tension disc 2 holes tension disc Electrical box cover Plug... -
Page 18: Assembly
100.00 mm Assembly Circuit Diagram Electrical Assembly Number Part PCB box base Capacitor PCB box cover — 18 —... -
Page 19: Use And Care Information
Use and Care Information Operations • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing. - Page 20 Ancona is in association with Mr Appliance for all after sales service calls. Please contact their service provider or visit their website: Phone: 888-998-2011 Website: www.mrappliance.com MAAN1528-01 © 2018 Copyright of Ancona Home. All rights reserved. This material may not be reproduced, displayed, modified or distributed. — 20 —...
