Ancona WPRO30 User Manual And Installation Instructions

Wall range hood

Advertisement

Quick Links

Wall Range Hood
User Manual
and
Installation Instructions
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the important information
regarding installation, safety and maintenance.
Keep these instructions for future reference.
MAAN1410-06
2020-11-27

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WPRO30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ancona WPRO30

  • Page 1 Wall Range Hood User Manual Installation Instructions IMPORTANT SAFETY INSTRUCTIONS Carefully read the important information regarding installation, safety and maintenance. Keep these instructions for future reference. MAAN1410-06 2020-11-27...
  • Page 2: Before You Begin

    Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 and 5 and Installation Instructions are on pages 8 to 13. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood.
  • Page 3: Table Of Contents

    Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 6 Range Hood Dimensions ........................7 Specifications ............................ 7 Installation ............................8 Step 1 - Read the Safety Instructions .................... 8 Step 2 - Unpack Range Hood and Prepare Tools ................
  • Page 4: Important Safety Information

    Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using the range hood to prevent the risk of fire, electric shock, personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur.
  • Page 5 Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high • Extinguish any open flame. settings. Boilovers cause smoking and greasy •...
  • Page 6: Included Parts

    Included Parts Ceiling Bracket 8pc Angle Range Hood Mounting Bracket 23.6 in. (600 mm) Mounting screws Ceiling bracket (20 + 1 pcs) Mounting screws angle bracket (24 + 1 pcs) Damper 6 in. 2 x Filters Nuts (24 + 1 pcs) Damper screws (4 + 1 pcs) `S` mounting hook...
  • Page 7: Range Hood Dimensions

    Range Hood Dimensions Specifications Body Design Stainless Steel Power Rating 120 V / 60 Hz (cETLus Certified) Total Input Power 472 W Motor Input Power 460 W Total Amps 3.8 A Speed Control Levels 4 Levels Interference Levels Radio Frequency Interference Protected Motors Single Motor Control Electronic Control Panel Filtration Stainless Steel Filters...
  • Page 8: Installation

    Installation STEP 1 Read the Safety Instructions • It is very important to read the safety instructions on pages 4 and 5. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. NOTE: Use threaded drywall anchors only when mounting the hood on sheet rock. Mounting the hood on wall studs or lumbars is highly recommended.
  • Page 9: Step 5 - Venting Installation Guidelines

    Installation STEP 5 Height and Clearance Venting Installation Guidelines A - Floor to ceiling height B - Ceiling to cooking surface (center/plumb line height) • The following steps are for exterior ventilation. C - Cooking surface to bottom of hood height •...
  • Page 10: Step 6 - Measuring

    Installation STEP • Measure the distance between stove top and the bottom of the range hood. A distance of 24" to 30" is recommended with a minimum of 30" for gas stove tops. • To reach 9ft ceiling make sure hood is installed at 30" from cooking surface. •...
  • Page 11: Step 8 - Venting

    Installation STEP Venting • Fix the damper into the damper hole on top of the range hood motor box (see Figure #3). • (see Figure #4). " • Figure #3 Figure #4 STEP (see Figure #5). Remove the protective coating from the inner chimney. Carefully slide the inner chimney down into the outer chimney.
  • Page 12: Step 10 - Finishing Installation

    Installation STEP Finishing Installation Slide the inner chimney up to the ceiling and attach it to the ceiling bracket using the screws (see gure #7). • Remove the protective coating from the hood body and outer chimney. • Installation is nished. •...
  • Page 13: Step 11 Install Filters

    Installation IMPORTANT: • Observe all governing codes and ordinances. • It is the customer’s responsibility to contact a qualified electrical installer. • If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line. • DO NOT ground to a gas pipe. • Check with a qualified electrician if you are not sure that the range hood is properly grounded. • DO NOT have a fuse in the neutral or ground circuit. IMPORTANT: Save this Installation Guide for electrical inspector’s use. GROUNDING INSTRUCTIONS: •...
  • Page 14: Operation

    Operation Using the Fan Turning the Light On or Off Press to turn light on Press to begin low and again to turn light speed. Screen will display off. Press to increase speed suction. Screen will display increments as 2, 3, 4. Press again to decrease suction.
  • Page 15: Maintenance

    Maintenance Replacing the Light Bulbs Cleaning the Range Hood Unplug the unit from the AC outlet. Be sure electrical power is off and all surfaces are cool before cleaning or servicing any part of the hood. Range Hood Body Remove five screws from the light panel, then remove the light bulbs by popping them out.
  • Page 16 Canada & USA Phone: 1-800-350-4562 Fax: 800-350-8563 Email: service@anconahome.com Website: www.anconahome.com Ancona is in association with Mr Appliance for all after sales service calls. Please contact their service provider or visit their website: Phone: 888-998-2011 Website: www.mrappliance.com MAAN1410-06 — 16 —...
