- Page 1 INSTALLATION GUIDE Elavo™ White Ceramic Soft Square Vessel Bathroom Sink KCV-127 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. October 25, 2017...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Prior to Installation: • Make sure that you have all necessary parts by checking the parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. • Inspect the sink prior to installation to make sure it has not been cracked or chipped during shipping •... - Page 4 Tools you will need: Adjustable wrench Silicone Sealant Safety Goggles Drill Silicone Adhesive Tape Measure Pencil 4” Hole Saw Dimensions 18.1”L x 16.1”W x 5.5”H Ø1.77” 45mm...
- Page 5 Top View Front View Back View Side View...
- Page 6 1. Mark faucet and drain hole location • Place sink in desired location on countertop and mark the drain hole and faucet hole centerline with a pencil Make sure clearance is suitable for backsplash, faucet, and plumbing for NOTE: the sink Please allow a minimum of 4.5”...
- Page 7 2. Drill countertop • Cut the opening for the drain in the countertop by carefully placing the 4” hole saw on the area marked by pencil...
- Page 8 • Carefully place the sink on the countertop, align, and press firmly • Allow sealant to set for 30 – 60 minutes Please make sure Kraus logo is facing you when mounting sink NOTE: Use acetone or rubbing alcohol to remove any excess sealant...
- Page 9 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 10 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
