- Page 1 INSTALLATION MANUAL Ceramic Bathroom Vessel Sinks KCV-120 / KCV-121 / KCV-122 / KCV-125 / KCV-126 / KCV-127 KCV-135 / KCV-140 / KCV-141 / KCV-142 / KCV-150 / KCV-341 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. January 8, 2021...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Toll-Free: 800-775-0703 or customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional. -
Page 4: Tools You Will Need
Tools you will need Safety Goggles Drill Silicone Adhesive Pencil Tape Measure 4" Hole Saw Dimensions 19 1/4" (488mm) 15 1/4" (386mm) R 1 5/8" R 3/4" Ø 1 3/4" (40mm) (20mm) (45mm) Ø 1 3/4" 18" 14" (458mm) (356mm) (45mm) R 5/8"... - Page 5 Dimensions Ø 1 3/4" 16 3/4" (427mm) (45mm) R2 3/8" 19 3/8" (493mm) Ø 1 3/4" (60mm) (45mm) 10" (255mm) 18 5/8" (473mm) 15 1/4" (387mm) 3/8" 3/4" R 5/8" (10mm) (20mm) (15mm) 11 3/8" Ø 2 3/4" (290mm) (70mm) KCV-122 KCV-125 19 3/8"...
- Page 6 Dimensions 15 3/4" (400mm) Ø 1 3/4" (45mm) Ø 17 3/4" (450mm) Ø 1 3/4" (45mm) R 30" R3 7/8" (100mm) (762mm) Ø 17 1/4" 14 5/8" (372mm) (438mm) 1/4" (6mm) R 3/8" (10mm) R 5/8" Ø 2 3/4" (15mm) (70mm) Ø...
- Page 7 Dimensions 18 5/8" (472mm) Ø 1 3/8" (35mm) Ø 1 3/4" (45mm) Ø 13" Ø 13 3/4" (330mm) (350mm) Ø 1 3/4" 17 3/8" (442mm) (45mm) Ø 1" R 5/8" (25mm) (15mm) Ø 5 1/2" Ø 2 3/4" (70mm) (140mm) KCV-150 KCV-341 Ø...
- Page 8 1. Mark Faucet and Drain Hole Location · Place sink in desired location on countertop and mark drain hole and faucet hole centerline with a pencil. NOTE: Make sure clearance is suitable for backsplash, faucet, and sink plumbing. NOTE: Please allow a minimum of 4.5” from wall to edge of sink for faucet placement clearance.
- Page 9 · · Allow sealant to set for 30 – 60 minutes NOTE: Please make sure Kraus logo is facing you when mounting sink NOTE: Use acetone or rubbing alcohol to remove any excess sealant immediately after application 4. Install Plumbing Fixtures ·...
- Page 10 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 11 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
- Page 13 INSTALLATION GUIDE Arlo Single Lever Basin Faucet ™ KBF-1201 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. APR 08, 2021...
- Page 14 Congratulations on the purchase of your new Kraus plumbing xture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
- Page 15 Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • Turn off the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •...
- Page 16 Diagram and Parts List A. Faucet Body E. Aerator Key I. Deck plate & Base plate B. Waterlines F. Hex Wrench J. Drain C. Flange & Washer G. Metal Washer K. Spanner Key D. Aerator H. Nut...
- Page 17 Faucet Dimension 6 3/4" 6 5/8" [172mm] 6 1/4" [169mm] 5" 5" [159mm] [126mm] [126mm] 2 1/4" [56mm] 3/8" compression 3/8" compression Installer Tip:...
- Page 18 Step 1: Remove washer and lock nut old faucet. Clean the mounting surface. WITH FLANGE: Remove the metal washer (G) and lock nut (H) from the faucet (A) as WITH DECK PLATE: Remove the metal Step 2.1: Install faucet (with deck plate) Align the hole on the deck plate (I) with the mounting hole on the sink.
- Page 19 Step 2.2: I Before installation, ensure that the of the faucet (A). Place the faucet (A) through the mounting holes in the sink until the faucet (A) sets on top of the sink. Secure the faucet (A) to the sink using the washer (G) and lock nut (H) provided.
- Page 20 Step 4: Install drain Remove the waste stopper (1) and drain ange (2) from the drain body (5). Screw the nut (4) all the way down, and push the concave washer (3) down. Apply silicone sealant (not included) under the drain ange(1) and place the drain ange (1)into the drain hole of the sink.
- Page 21 Step 4: Install drain Insert the waste stopper (1) into the drain Insert 1 Insert 2 hole in the sink. Remove the strap (6) and clip (5) from the ball rod (3). Remove the ball nut (4). Insert the ball rod (3) into the drain body (2) and through the hole of the stopper (1).
- Page 22 Step 4: Install drain Attach the ball rod (1) to the strap (3) using the clip (2). Loosen the thumb screw (3) on the strap (2). Push down on the lift rod (1) until the stopper is in the open position.
-
Page 23: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # 1. Cover Button GR, BL* KP27002 2. Set Screw KP27001 CH, SFS, ORB, MB, 3. Handle KP27046 BG, SFSB* CH, SFS, ORB, MB, 4. Cap KP27048 BG, SFSB* 5. Bonnet Nut KP27049 6. -
Page 24: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Remove the cover button (1). Leakage under the Bonnet nut (5) has Loosen set screw (2) with hex... - Page 25 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 26 Puerto Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 27 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
