- Page 1 INSTALLATION MANUAL Elavo ™ White Ceramic Square Semi-Recessed Bathroom Sink w/ Overflow KCR-281 www.kraususa.com Toll Free: 1.800.775.0703 © 2018 Kraus USA Inc. REV. July 22, 2020...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: STOP DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
· chipped during shipping. · Use the cut-out template provided by Kraus to cut the opening in your countertop . · Observe all plumbing and building codes according to your state requirements Additional floor and wall preparation may be required to avoid damaging the sink ·... -
Page 4: Tools You Will Need
Safety Goggles Drill Silicone Adhesive Jig Saw Pencil Tape Measure Scissors Putty Knife NOTE: Specialized tools may be necessary to install Kraus Ceramic Semi-Recessed sinks with countertop materials other than wood, marble, or granite. Parts List · Sink · Cut-Out Template... - Page 5 Dimensions 16 1/4" (413mm) R1 5/8" (40mm) 15" (381mm) Ø 1/2" (13.5mm) 2 1/2" (65mm) KCR-281 16 1/4" x 16 1/4" x 6 3/4"...
- Page 6 1. Cut Paper Template · Use scissors to cut along the inside line of the paper template. 13.4” (340mm) 2. Trace Template · Place the cut-out template in the desired location on the countertop and trace with a pencil. · Mark the faucet hole centerline on the countertop using the vertical line in the center of the paper template.
- Page 7 3. Cut Countertop · Cut the countertop opening by carefully following the pencil line traced from the template. NOTE: Please use the appropriate saw that best fits your countertop material .
- Page 8 4. Install Sink · Check the alignment of the sink to the opening in the countertop. Use a bead of clear silicone (or preferred adhesive) around the underside of the sink · Carefully insert the sink in place, align, and press firmly ·...
- Page 9 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 10 Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied are given, including but not limited to, any implied warranty of merchantability or fitness for a particular purpose.
- Page 11 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
