- Page 1 INSTALLATION GUIDE Esta™ Single Handle Lavatory Faucet KVF-1210 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. JUN 06, 2019...
- Page 2 Congratulations on the purchase of your new Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com Have the model number available, and retain a copy of your receipt...
-
Page 3: Prior To Installation
Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • Turn off the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •... - Page 4 Diagram and Parts List F. Mounting Nut A. Faucet Body B. Aerator G. Screws C. Aerator Key H. Hex Wrench D. Plastic Washer I. Drain E. Metal Washer...
- Page 5 Faucet Dimension 6 7/8" [173.2mm] 5 1/8" 2 1/2" [130.1mm] [62.7mm] M18.5X1.0-6g 2 1/8" [54.8mm] 9/16-24UNEF-2B Installer Tip:...
- Page 6 Drain Dimension 2 3/4" [69.0mm] Ø2 3/8" [61.1mm] G1 1/4-11 Ø1 1/4" [31.7mm] Installer Tip:...
- Page 7 Step 1: Remove washers and mounting nut Shut off the water supply. Remove the old faucet. Clean the mounting surface. Remove the mounting nut & screws (F&G), metal washer (E) and plastic washer (D) from the faucet (A). F&G Step 2: Installing the faucet Place faucet (A) through the hole in countertop.
- Page 8 Step 3: Connect waterlines to main valve Attach waterlines to angle stops and tighten until snug. Turn on angles stops and check for leaks (DO NOT TURN FAUCET ON) Step 4: Install Press pop-up assembly Unscrew the nut (6) from the pop-up body (2), move over the tail pipe (7) and washer (5), then unscrew the coupling nut (4) and remove the...
- Page 9 Step 4: Install Press pop-up assembly Place the washer (1) underneath the flange of the pop-up body (2). Slide the pop-up body (2) down through the drain hole on the vessel or basin. From underside, slide the washer (3) against the bottom of the vessel or basin, thread on the coupling nut (4) and tighten.
-
Page 10: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # GR, BL* 1. Cover Button KP27002 2. Set Screw KP27001 SFS, MB, 3. Handle KP27150 GM, BG* SFS, MB, 4. Cap KP27151 GM, BG* 5. Bonnet Nut KP27152 6. Screw KP27153 7. -
Page 11: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following coorective steps: P R O B L E M C A U S E A C T I O N Leakage under the Bonnet nut (5) has Remove the cover button (1). - Page 12 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 13 Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 14 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
