SI-606 User Manual Table of Contents Setting up your system ......................v Care during use ........................vi Acknowledgments ......................... vii CHAPTER 1 INTRODUCTION ................... 1 1.1 General Description ......................1 1.2 System Specifications ...................... 2 1.2.1 Hardware Specifications ....................2 1.2.2 Dimensions ........................
SI-606 User Manual Care during use • Do not walk on the power cord or allow anything to rest on it. • Do not spill water or any other liquids on your system. • When the system is turned off, a small amount of electrical current still flows. Always unplug all power, and network cables from the power outlets before cleaning the system.
SI-606 User Manual CHAPTER 1 INTRODUCTION 1.1 General Description The “Signature Book™” SI-606 is a professional digital signage system powered I Desktop Processors with AMD Radeon™ E8860 graphics. ® by 4 Gen. Intel Core The SI-606 integrates six (6) DP ports with independent video output and one DVI-I for console.
SI-606 User Manual 1.2 System Specifications 1.2.1 Hardware Specifications Model Name SI-606 System Mainboard MBD60E 4th Generation Intel® Core™ i7/i5/i3 and Pentium® QC/DC processors; Up to 3.5GHz Memory 4x DDR3 1600 MHz, Max. 32GB I/O Interface 6x DP with independent video output 1x DVI-I for console 4x USB 3.0 ports 2x RJ45 for Gigabit LAN...
SI-606 User Manual 1.3.1 Parts Description Part No. Description Part No. Description SI-606_BASE 4028_fan DP Board Module Power module SI-606 Main Board SI-606_HDD-TRAY SI-606_HDD-BRK Screw F Type M3*0.5 SATA Cable 2.5" SATA HDD M3 nut M3 double screw bolt SI-606_top-cover_L SI-606_top-cover_r Screw PW Type M3*0.5 M3 screw...
SI-606 User Manual 1.5 HARDWARE INSTALLATION 1.5.1 Mounting Installation 1. Please install SI-606 to the intended location using 4x M4*0.7*6L screws, as shown in the picture.
SI-606 User Manual 2.3 Setting the Jumpers Jumpers are used on MBD60E to select various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your needs. The following lists the connectors on MBD60E and their respective functions.
SI-606 User Manual 2.4 Connectors on MBD60E J1: COM2 Connector [HRS DF11-10DP-2DSA(08)] Signal Name Signal Name Pin # Pin # Data carrier detect Receive data Transmit data Data terminal ready Ground Data set ready Request to send Clear to send Ring indicator Not Used J2: ATX +12V Jack [HAOGUO ATX4PT-NY46]...
Page 26
SI-606 User Manual J12: Mini PCIe Slot (Full size with mSATA) J13: ATX Power Supply Connector Signal Name Pin # Pin # Signal Name 3.3V 3.3V -12V 3.3V Ground Ground PS-ON Ground Ground Ground Ground Ground Power good 5VSB +12V +12V Ground +3.3V...
Page 28
SI-606 User Manual CN4: I218LM / USB3.0 Connector CN5/6:SATA 3 Connector CPU_FAN1: CPU Fan Power Connector Pin # Signal Name Ground +12V Rotation detection Control GPU_FAN1: GPU Fan Power Connector Pin # Signal Name Ground +12V Rotation detection Control...
SI-606 User Manual CHAPTER 3 BIOS SETUP This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: 3.1 BIOS Introduction The BIOS (Basic Input/Output System) installed in your computer system’s ROM supports Intel processors.
Page 42
SI-606 User Manual Legacy USB Support Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. USB3.0 Support Enable/Disable USB3.0 (XHCI) Controller support. XHCI Hand-off This is a workaround for OSes without XHCI hand-off support.
SI-606 User Manual CHAPTER 4 DRIVERS INSTALLATION The Intel Chipset Drivers should be installed first before the software drivers to enable Plug & Play INF support for Intel chipset components. Follow the instructions below to complete the installation. IMPORTANT NOTE: After installing your Windows operating system, you must install first the Intel Chipset Software Installation Utility before proceeding with the drivers installation.
Page 56
SI-606 User Manual 5. On the Readme File Information screen, click Install to continue the installation. 6. The Setup process is now complete. Click Finish to restart the computer and for changes to take effect.
Page 62
SI-606 User Manual 3. On the Welcome to the InstallShield Wizard screen, click Yes to proceed with and complete the installation process. 4. The InstallShield Wizard Complete. Click Finish to restart the computer and for changes to take effect.
Page 68
SI-606 User Manual 3. Click Yes to to agree with the license agreement. 4. When the Setup Progress screen appears, click Next. Then, click Finish when the setup progress has been successfully installed.
SI-606 User Manual 4.6 Intel® USB 3.0 eXtensible Host Controller Driver 1. Insert the DVD that comes with the board. Click System and then SI-606 Series Products. Click Intel® USB 3.0 eXtensible Host Controller Driver. 2. When the Welcome screen to the InstallShield Wizard for Intel® USB 3.0 eXtensible Host Controller Driver, click Next.
Page 74
SI-606 User Manual 3. When the Ready to Install the Program screen appears, click Install to continue. 4. When InstallShield Wizard is complete, click Finish.
Page 76
SI-606 User Manual AMD Catalyst Driver is now available on the AMD Embedded Developer website: https://wwwd.amd.com/amd/devsite.nsf/edg/e6760.htm. The driver supports up to 6 displays with various AMD Eyefinity SLS grid configurations. Refer to the following table for the supported AMD Eyefinity modes. Note: The resolution of your display configuration should be no more than 16K either in width or in height.
Page 78
SI-606 User Manual Step 3: Click Show More for information on the available Mixed Mode. If the box does not show on your screen, your device does not support Mixed Mode. Step 4: Click Use a new arrangement, then click Next.
Page 80
SI-606 User Manual For 2 displays output: For 3 displays output: • • 2 x 1 Landscape Display Group 3 x 1 Landscape Display Group • 2 x 1 Portrait Display Group • 3 x 1 Portrait Display Group • 1 x 2 Landscape Display Group •...
Page 82
SI-606 User Manual For 6 displays output: • • 6 x 1 Portrait Display Group 2 x 3 Landscape Display Group • 1 x 6 Landscape Display Group • 2 x 3 Portrait Display Group • 3 x 2 Landscape Display Group •...
Page 84
SI-606 User Manual Step 8: Each display connected to your system will show a blue background, one at a time. Select a display by clicking a box in the schematic layout shown corresponding to the display currently identified with the blue background. Then the next display is identified by displaying the blue background.
Page 86
SI-606 User Manual Step 10: Click Align All to align the displays automatically. You can perform the alignment manually by clicking one or more of the boxes and moving them up and down with the arrow keys in the wizard. Use the rulers on the flanking sides of the displays for reference, as shown below.
SI-606 User Manual C. Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ0 System Timer IRQ3 Serial Port #2 IRQ4 Serial Port #1 IRQ 5...
Page 94
SI-606 User Manual //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. //--------------------------------------------------------------------------- #include "F81846.H"...
Page 96
SI-606 User Manual //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE. //--------------------------------------------------------------------------- #ifndef __F81846_H #define __F81846_H...
