- Page 1 SI-613 Book-Size Digital Signage Player User’s Manual Version 1.0 (May 2017)
- Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
-
Page 3: Compliance
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) SI-613 User Manual... -
Page 4: Important Safety Information
You are not suggested to disassemble, repair or make any modification to the device. Disassembly, modification, or any attempt at repair could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. SI-613 User Manual... -
Page 5: Caution
Software in use (such as OS and application software, including the version numbers) 3. If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. SI-613 User Manual... -
Page 6: Table Of Contents
EDID Clearance Button (SW2) ..........19 2.5.3 LED Indicators for HDD & Power (LED5, LED6) ....20 2.5.4 DC Power Input (CN12) ............20 2.5.5 HDMI 2.0 Port (CN1, CN2, CN3) .......... 21 2.5.6 LAN Port (CN6) ..............21 SI-613 User Manual... - Page 7 CPU Configuration ..............45 4.4.7 SATA Configuration ..............46 4.4.8 CSM Configuration ..............47 4.4.9 USB Configuration ..............48 Chipset Settings ..................49 4.5.1 System Agent Bridge .............. 50 4.5.2 PCH-IO Configuration ............. 53 Security Settings ................... 54 SI-613 User Manual...
- Page 8 Boot Settings..................55 Save & Exit Settings................56 Appendix ...................... 57 I/O Port Address Map ................58 Interrupt Request Lines (IRQ) ............... 60 Watchdog Timer Configuration .............. 61 viii SI-613 User Manual...
-
Page 9: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Overview • Dimensions... -
Page 10: Introduction
1.1 Introduction SI-613, a product code of IBASE digital signage player series, is a mid-range system with iSMART and capable of auto-scheduling for general applications. It is slim with a segregated ventilation design. The device is designed with the ®... -
Page 11: Packing List
General Information 1.3 Packing List Your SI-613-N package should include the items listed below. If any of the items below is missing, contact the distributor or the dealer from whom you purchased the product. • SI-613 Digital Signage Player •... -
Page 12: Specifications
(W x H x D) Net Weight 2.2 kg (4.85 lb) Certificate CE, FCC, cULus, CCC I/O Ports HDMI 3 x HDMI 2.0 (4K at 60 Hz) 1 x GbE RJ45 Serial 1 x RJ45 for COM port (RS-232) SI-613 User Manual... - Page 13 • Storage: -20 ~ 80 °C (-4 ~ 176 °F) Relative 5 ~ 90% at 45 °C (non-condensing) Humidity Vibration M.2: Operating, random vibration 5 grms (5~500Hz) Protection All specifications are subject to change without prior notice. SI-613 User Manual...
-
Page 14: Overview
1.6 Overview Top View Oblique View SI-613 User Manual... - Page 15 Be sure to press the EDID Clearance Button shortly so as to clear the EDID register if any connected display/monitor is unable to be recognized, or when the image displayed cannot not be resampled to fit the screen. SI-613 User Manual...
-
Page 16: Dimensions
1.7 Dimensions Unit: mm SI-613 User Manual... -
Page 17: Hardware Installation & Motherboard Information
Chapter 2 Hardware Installation & Motherboard Information The information provided in this chapter includes: • Installation of memory, M.2 and mini PCIe card • Information and locations of connectors... -
Page 18: Essential Installation Before You Begin
2.1.1 Memory Installation There are two SO-DIMM DDR4 memory slots inside SI-613 for a maximum total memory of 32 GB. If you need to install or replace a memory module, locate the memory slot inside the device and perform the following steps. -
Page 19: Mini-Pcie & M.2 Network Cards Installation
(Insert the M.2 network card in the same way.) 2. Push the card down and fix it with the a screw of M3 x 3.8 mm. (Fix the M.2 network card with a screw of M2 x 3.8 mm.) Mini PCIe: M.2: SI-613 User Manual... -
Page 20: Wifi / 3G / 4G Antenna Installation
1. Thread and fasten the hex nut and the 2. Apply adhesive around here. washer. Then install the antenna. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). SI-613 User Manual... -
Page 21: Setting The Jumpers
Motherboard Information 2.2 Setting the Jumpers Set up and configure your SI-613 by using jumpers for various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your use. -
Page 22: Jumper & Connector Locations On Motherboard
2.3 Jumper & Connector Locations on Motherboard Motherboard: MBD613 CN12 ® Intel H170/ Q170 ® Intel Gen. Core™ CPU Socket MBD613 - top SI-613 User Manual... - Page 23 Motherboard Information Battery Open Lock MBD613 - bottom SI-613 User Manual...
-
Page 24: Jumpers Quick Reference
2.4 Jumpers Quick Reference Jumper: Function Connector Name Page AT / ATX Power Mode Connector CMOS Data & RTC Clearance 2.4.1 AT / ATX Power Mode Connector (JP4) Function Pin closed Illustration (default) SI-613 User Manual... -
Page 25: Cmos Data & Rtc Clearance (Jp5)
Motherboard Information 2.4.2 CMOS Data & RTC Clearance (JP5) Function Pin closed Illustration Normal 1-3 (CMOS) (default) 2-4 (RTC) 3-5 (CMOS) Clear CMOS & RTC 4-6 (RTC) SI-613 User Manual... -
Page 26: Connectors Quick Reference
COM2 RS232 Port J10: System Function Connector SIM Card Socket Digital I/O Header NGFF M.2 Connector J16 (B-KEY 3042) J18 (M-KEY 2280) Mini PCIE Connectors DDR4 SO-DIMM J2, J17 Factory Use Only J4, J5, J6, J7, J8, J9, J11 SI-613 User Manual... -
Page 27: Power Button (Sw1)
Note: Be sure to press this button shortly so as to clear the EDID register if any connected display/monitor is unable to be recognized, or when the image displayed cannot not be resampled to fit the screen. SI-613 User Manual... -
Page 28: Led Indicators For Hdd & Power (Led5, Led6)
LED5 is the green LED indicator for HDD. When HDD is being read, it blinks. LED6 is the red LED indicator for power status. It stays on (not blinks) as the device is on. 2.5.4 DC Power Input (CN12) Assigment Assigment Ground +12V Ground +12V SI-613 User Manual... -
Page 29: Hdmi 2.0 Port (Cn1, Cn2, Cn3)
Motherboard Information 2.5.5 HDMI 2.0 Port (CN1, CN2, CN3) 2.5.6 LAN Port (CN6) 2.5.7 USB 3.0 Port (CN4, CN5) SI-613 User Manual... -
Page 30: Usb 2.0 Port (Cn8, Cn9)
2.5.8 USB 2.0 Port (CN8, CN9) 2.5.9 COM1 Serial Port (CN7) Assigment Assigment Ground Ground SI-613 User Manual... -
Page 31: Audio Jack (Cn10, Cn11)
Motherboard Information 2.5.10 Audio Jack (CN10, CN11) CN10: Line-out CN11: Microphone Input SI-613 User Manual... -
Page 32: Cpu Fan Power Connector (J3)
2.5.11 CPU Fan Power Connector (J3) Assigment Ground +12V Rotation detection 2.5.12 USB 2.0 Ports Header (J12) Assigment Assigment Data- (Port 1) Data- (Port 2) Data+ (Port 1) Data+ (Port 2) Ground Ground SI-613 User Manual... -
Page 33: Com2 Rs-232 Port (J10)
RTS (Request to send) TXD (Transmit data) CTS (Clear to send) DTR (Data terminal ready) RI (Ring indicator) Ground 2.5.14 System Function Connector (J14) Assigment Assigment Power BTN Power BTN HDD LED+ HDD LED- Reset BTN Reset BTN +5VSB SI-613 User Manual... -
Page 34: Sim Card Socket (J19)
2.5.15 SIM Card Socket (J19) Open Lock 2.5.16 Digital I/O Connector (J13) Assigmentd Assigment Ground OUT3 OUT1 OUT2 OUT0 SI-613 User Manual... -
Page 35: Ngff M.2 Connector (J16, J18)
Motherboard Information 2.5.17 NGFF M.2 Connector (J16, J18) J16 is a M.2 B-Key (3042) connector with PCIe (x2) , USB 2.0, USB 3.0, and SATA. J18 is a M.2 M-Key (2280) connector with SATA and PCIe (x4). SI-613 User Manual... -
Page 36: Mini Pcie Connector (J20)
2.5.18 Mini PCIe Connector (J20) J20 is a Mini PCIe connector with PCI-e, USB and SIM. 2.5.19 DDR4 SO-DIMM (J2, J17) J17: SI-613 User Manual... -
Page 37: Chapter 3 Driver Installation
Chapter 3 Driver Installation The information provided in this chapter includes: • ® Intel Chipset Software Installation Utility • ® Intel Graphics Driver Installation • HD Audio Driver Installation • LAN Driver Installation • ® Intel Trusted Execution Engine Installation •... -
Page 38: Introduction
Chipset Device Software appears, click Next to continue. 3. Accept the license agreement and proceed with the installation process. 4. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. SI-613 User Manual... -
Page 39: Vga Driver Installation
3. Click Yes to agree with the license agreement and continue the installation. 4. On the Readme File Information screen, click Next for installation. 5. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. SI-613 User Manual... -
Page 40: Hd Audio Driver Installation
1. Run the Setup.exe file. 2. On the Welcome screen of the InstallShield Wizard, click Next for installation. 3. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. SI-613 User Manual... -
Page 41: Lan Driver Installation
4. On the Setup Options screen, tick the checkbox to select the desired driver(s) and click Next for installation. 5. The driver has been completely installed. You are suggested to restart the computer and for changes to take effect. SI-613 User Manual... -
Page 42: Intel Management Engine Components Drivers Installation
2. When the Weocome screen appears, click Next. 3. Accept the license agreement and click Next for installation. 4. The driver has been completely installed. You are suggested to restart the computer and for changes to take effect. SI-613 User Manual... -
Page 43: Intel Usb 3.0 Driver Installation
3. Click Yes to agree with the license agreement. 4. On the Readme File Information screen, click Next for installation. 5. The driver has been completely installed. You are suggested to restart the computer and for changes to take effect. SI-613 User Manual... -
Page 44: Chapter 4 Bios Setup
Chapter 4 BIOS Setup This chapter the different settings available in the AMI describes BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Security Settingss •... -
Page 45: Introduction
These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. SI-613 User Manual... -
Page 46: Main Settings
4.3 Main Settings BIOS Setting Description System Date Sets the date. Use the <Tab> key to switch between the data elements. System Time Set the time. Use the <Tab> key to switch between the data elements. SI-613 User Manual... -
Page 47: Advanced Settings
BIOS Setup 4.4 Advanced Settings This section allows you to configure, improve your system and allows you to set up some system features according to your preference. SI-613 User Manual... -
Page 48: Trusted Computing
4.4.1 Trusted Computing BIOS Setting Description Security Device Support Enables / Disables BIOS support for security device. The operating system will not show security device. TCG EFI protocol and INT1A interface will not be available. SI-613 User Manual... -
Page 49: Ismart Controller
Controller BIOS Setting Description Power-On after Power Enables / Disables the system to be turned on failure automatically after a power failure. Schedule Slot 1 / 2 Sets up the hour / minute for system powe-on. SI-613 User Manual... -
Page 50: Amt Configuration
Amt Wait Timer Sets timer to wait before sending ASF_GET_BOOT_OPTIONS. Activate Remote Triggers CIRA boot. Assistance Process PET Progress Enables / Disables PET events progress to receive PET events. Watchdog Timer Enables / Disables Watchdog Timer. SI-613 User Manual... -
Page 51: Super Io Configuration
BIOS Setup 4.4.4 Super IO Configuration BIOS Setting Description Serial Port Configuration Sets parameters of Serial Ports (COMA). Enables / Disables the serial port and select an optimal setting for the Super IO device. SI-613 User Manual... -
Page 52: Hardware Monitor
These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status. Shutdown Temperature This field enables or disables the Shutdown Temperature SI-613 User Manual... -
Page 53: Cpu Configuration
BIOS Setup 4.4.6 CPU Configuration BIOS Setting Description Intel(R) SpeedStep(tm) Supports more than two frquency ranges. SI-613 User Manual... -
Page 54: Sata Configuration
SATA Controller(s) Enables / Disables SATA devices. SATA Mode Selection Determines how the SATA controller(s) operate. Options: AHCI Mode / RAID Mode Serial ATA Ports Enables / Disables Serial Ports. Hot Plug Designates this port as Hot Pluggable. SI-613 User Manual... -
Page 55: Csm Configuration
BIOS Setup 4.4.8 CSM Configuration BIOS Setting Description Network SATA Controls the execution of UEFI and legacy PXE Controller(s) OpROM. SI-613 User Manual... -
Page 56: Usb Configuration
The maximum time the device will take before it properly reports itself to the Host Controller. “Auto” uses default value for a Root port it is 100ms. But for a Hub port, the delay is taken from Hub descriptor. SI-613 User Manual... -
Page 57: Chipset Settings
BIOS Setup 4.5 Chipset Settings BIOS Setting Description System Agent (SA) System Agent (SA) parameters Configuration PCH-IO Configuration PCH parameters SI-613 User Manual... -
Page 58: System Agent Bridge
4.5.1 System Agent Bridge BIOS Setting Description VT-d Checks if VT-d function on MCH is supported. SI-613 User Manual... - Page 59 Primary PEG. Primary PCIE Selects PCIE0 / PCIE1 / PCIE2 / PCIE3 / PCIE4 / PCIE5 / PCIE6 / PCIE7 Graphics device should be primary PCIE. Internal Graphics Keeps IGD enabled based on the setup options. SI-613 User Manual...
- Page 60 4.5.1.2. Memory Configuration BIOS Setting Description Memory Configuration Displays the RC version, frequency and total size of memory. SI-613 User Manual...
-
Page 61: Pch-Io Configuration
Description PCH LAN Controller Enables / Disables the on-board NIC. Wake on LAN Enables / Disables the integrated LAN to wake the system. (The Wake On LAN cannot be disabled if ME is on at Sx state.) SI-613 User Manual... -
Page 62: Security Settings
4.6 Security Settings BIOS Setting Description Administrator Password Sets an administrator password for the setup utility. User Password Sets a user password. SI-613 User Manual... -
Page 63: Boot Settings
Enables / Disables boot with initialization of a minimal set of devices required to launch the active boot option. There no effect for BBS boot options. Fixed Boot Order Sets the system boot order. Priorities Boot Option Priorities Sets the system boot order. SI-613 User Manual... -
Page 64: Save & Exit Settings
Restore Defaults Restores / Loads defaults values for all the setup options. Save as User Defaults Saves the changes done so far as user defaults. Restore User Defaults Restores the user defaults to all the setup options. SI-613 User Manual... -
Page 65: Appendix
Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Digital I/O Sample Code • Watchdog Timer Configuration... -
Page 66: I/O Port Address Map
0x0000FFFF-0x0000FFFF Motherboard resources 0x00001800-0x000018FE Motherboard resources 0x0000164E-0x0000164F Motherboard resources 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller 0x00000038-0x00000039 Programmable interrupt controller SI-613 User Manual... - Page 67 PCI Express Root Complex 0x00000D00-0x0000FFFF PCI Express Root Complex 0x0000F0A0-0x0000F0A7 Intel(R) Active Management Technology - SOL (COM3) 0x0000FF00-0x0000FFFE Motherboard resources 0x0000F040-0x0000F05F Intel(R) 100 Series/C230 Series Chipset Family SMBus - A123 0x00000060-0x00000060 Standard PS/2 Keyboard 0x00000064-0x00000064 Standard PS/2 Keyboard SI-613 User Manual...
-
Page 68: Interrupt Request Lines (Irq)
Microsoft ACPI-Compliant System IRQ 4294967290 Intel(R) Management Engine Interface IRQ 4294967291 Intel(R) USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) IRQ 4294967292 Intel(R) HD Graphics 530 IRQ 4294967293 Intel(R) Ethernet Connection (2) I219-LM IRQ 4294967294 Standard SATA AHCI Controller SI-613 User Manual... -
Page 69: Watchdog Timer Configuration
Fintek 81866, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime); if (bTime) EnableWDT(bTime); } else DisableWDT(); } return 0; SI-613 User Manual... - Page 70 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81866_LD(0x07); //switch to logic device 7 bBuf = Get_F81866_Reg(0xFA); bBuf &= ~0x01; Set_F81866_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81866_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81866_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- SI-613 User Manual...
- Page 71 Init_Finish; } F81866_BASE = 0x00; result = F81866_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81866 (void) outportb(F81866_INDEX_PORT, F81866_UNLOCK); outportb(F81866_INDEX_PORT, F81866_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81866 (void) outportb(F81866_INDEX_PORT, F81866_LOCK); //--------------------------------------------------------------------------- void Set_F81866_LD( unsigned char LD) Unlock_F81866(); outportb(F81866_INDEX_PORT, F81866_REG_LD); outportb(F81866_DATA_PORT, LD); Lock_F81866(); SI-613 User Manual...
- Page 72 //--------------------------------------------------------------------------- #defineF81866_INDEX_PORT (F81866_BASE) #defineF81866_DATA_PORT (F81866_BASE+1) //--------------------------------------------------------------------------- #defineF81866_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81866_UNLOCK 0x87 #defineF81866_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81866(void); void Set_F81866_LD( unsigned char); void Set_F81866_Reg( unsigned char, unsigned char); unsigned char Get_F81866_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81866_H SI-613 User Manual...
