IBASE Technology SI-32-N Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SI-32-N User Manual
SI-32-N Series
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-32-N Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBASE Technology SI-32-N Series

Summary of Contents for IBASE Technology SI-32-N Series

  • Page 1 SI-32-N User Manual SI-32-N Series User Manual...
  • Page 2 SI-32-N User Manual Revision Release Date V0.1 2014/09/01...
  • Page 3 IBASE Technology Inc. Copyright © 2013 IBASE Technology Inc. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of IBASE Technology INC.

  • Page 4: Table Of Contents

    SI-32-N User Manual Table of Contents Setting up your system ...................... v Care during use ......................... vi Acknowledgments ......................vii CHAPTER 1 INTRODUCTION ..................1 1.1 General Description...................... 1 1.2 System Specifications....................2 1.2.2 Dimensions ........................ 3 1.2.3 I/O View ........................4 1.3 Exploded View of the SI-32-N Assembly..............

  • Page 5: Setting Up Your System

    DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 80° C (176° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 6: Care During Use

    SI-32-N User Manual Care during use  Do not walk on the power cord or allow anything to rest on it.  Do not spill water or any other liquids on your system.  When the system is turned off, a small amount of electrical current still flows. Always unplug all power, and network cables from the power outlets before cleaning the system.

  • Page 7: Acknowledgments

    FINTEK is a registered trademark of FINTEK Electronics Corporation.  REALTEK is a registered trademark of REALTEK Electronics Corporation.  All other product names or trademarks are properties of their respective owners. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 9: Chapter 1 Introduction

    SI-32-N User Manual CHAPTER 1 INTRODUCTION 1.1 General Description The “Signature Book™” SI-32-N is a professional fanless digital signage system powered by the AMD Embedded high performance R-Series Quad-Core R-452L (1.6/2.4GHz) APU. Clients can have flexible video wall display configuration support from AMD Eyefinity function.

  • Page 10: System Specifications

    SI-32-N User Manual 1.2 System Specifications 1.2.1 Hardware Specifications Model Name SI-32-N System Mainboard IB939-45 AMD R-452L Quad-Core (1.6/2.4GHz) APU Memory 2 x DDR3 1600MHz SO-DIMM Memory, Max. 8GB I/O Interface 1 x Hybrid-DVI (VGA/DVI/HDMI with audio) 1 x Dual-link DVI-I 3 x USB 3.0 ports 2 x RJ45 for LAN 1 x RJ45 for RS232...

  • Page 11: Dimensions

    IBASE Technology Inc. 1.2.2 Dimensions Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 12: I/O View

    SI-32-N User Manual 1.2.3 I/O View Item Connector Item Connector ATX 4pin Power Jack 2 x RJ45 for Gigabit LAN Power On/off button 2 x DVI-I COM port Line-in / Line-out 3 x USB 3.0 ports (Vertical type)

  • Page 13: Exploded View Of The Si-32-N Assembly

    1.3.1 Parts Description Part No. Description Part No. Description IB939 main board SI-32-N Heat sink SI-32-N Base SI-32-N rear bracket SI-32-N wall mount bracket SI-32-N SSD bracket mSATA Battery SI-32-N battery bracket Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 14: Packing List

    SI-32-N User Manual 1.4 Packing List Item No. Description Driver CD Power adaptor Power Cord 1.4.1 Optional Items Description WiFi Solution Wireless; PCI-E Mini Card 802.11B/G/N QCOM WiFi module [AW-NE238H] (A008WLAWNE238H000P) External Antenna-2pcs WiFi Antenna (A055RFA02C2M20800P) Internal Antenna, 100mm [BTC130-1-70B-200-1] Internal cable-2pcs RoHS (A055RFA0000020000P) 3G Solution...

  • Page 15: Hardware Installation

    1. Remove the 13 screws on the sides that are used to secure the cover to the chassis. Once all the screws are removed, from the side, push the cover forward to remove it. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 16 SI-32-N User Manual 2. Push the WIFI module into the slot. Screw two screws to secure the module into the slot.

  • Page 17: Installing Storage

    1. Remove the 13 screws on the sides that are used to secure the cover to the chassis. Once all the screws are removed, from the side, push the cover forward to remove it. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 18 SI-32-N User Manual 2. First, put the thermal pad and push the module into the slot. Screw two screws to secure the module into the slot.

  • Page 19: Chapter 2 Motherboard Introduction

    2 x Microjack Audio connectors for Line-in / Line-out 3 x USB 3.0 ports SATA / eSATA Same as SI-38 1 x SATA 3.0 2.5” open frame SSD. 1 x SATA 3.0 header Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 20 SI-32-N User Manual LPC I / O NCT6106 COM1 (RS232) (RJ45 same as original IB938) Monitor (2 thermal inputs, 2 voltage monitor inputs COM 2/3 with pin-9 with power for 2 ports (500 mA each port) Expansion slot 1x mPCIe(x1) 26.8 mm 1x mPCIe(x1) 51 mm (mPCIe &...

  • Page 21: Installations

    DDR3 module in place when the DDR3 module touches the bottom of the socket. 3. To remove the DDR3 module, press the clips with both hands. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 22: Setting The Jumpers

    SI-32-N User Manual 2.3 Setting the Jumpers JP4, JP5: COM4 RS232 RI/+5V/+12V Power Setting JP4/JP5 Setting Function Pin 1-2 Short/Closed Pin 3-4 Short/Closed Pin 5-6 Short/Closed J15: Clear CMOS Setting JP15 Function Normal Clear CMOS...

  • Page 23: Connectors On Ib939

    IBASE Technology Inc. 2.4 Connectors on IB939 Connector Locations on IB939 Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 24 SI-32-N User Manual CN19: DC_IN Connector (+12V~24V 4 Pin) Signal Name Pin # DC_IN DC_IN SW1: Power Button LED3: Power LED (Green), HDD LED (RED) The green LED at the bottom is power LED. The red LED on top is the HDD LED. COM1: COM1 Connector COM1 Pin #...
  • Page 25 Ground No connect. J9: Digital I/O Pin # Pin # Signal Name Signal Name OUT3 OUT1 OUT2 OUT0 JP10: US2.0 Connector Pin # Pin # Signal Name Signal Name Ground Ground Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 26 SI-32-N User Manual J12: Mini PCIE Slot (Support mSATA) J17: MCU JTAG (factory use only) J19: Power LED Connector J20: System Function Connector J19: Power LED Connector Signal Name Pin # Ground J24: CPU_FAN Connector This is a 3-pin header for the CPU fan. The fan must be a 12V (500mA). Pin # Signal Name Ground...

  • Page 27: Chapter 3 Bios Setup

    <PgDn> keys to change entries, <F1> for help and <Esc> to quit. When you enter the Setup utility, the Main Menu screen will appear on the screen. The Main Menu allows you to select from various setup functions and exit choices. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 28 SI-32-N User Manual Main Settings Aptio Setup Utility – Copyright © 2011 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Choose the system BIOS Information default language Memory Information 8176 MB (DDR3) → ← Select Screen Total memory ↑↓...
  • Page 29 F4: Save ESC: Exit ACPI Sleep State Select ACPI sleep state the system will enter, when the SUSPEND button is pressed. Lock Legacy Resources Enabled or Disabled Lock of Legacy Resources. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 30 SI-32-N User Manual CPU Configuration This section shows the CPU configuration parameters. Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit CPU Configuration Module Version: 4.6.5.1 TrinityPI 012 → ← Select Screen AGESA Version: 1.0.0.3 ↑↓ Select Item Enter: Select PSS Support Enable...
  • Page 31 → ← Select Screen ↑↓ Select Item Enter: Select SATA Port0 WDC WD800AAJS-(80.0G +- Change Field F1: General Help SATA Port2 Not Present F2: Previous Values F3: Optimized Default F4: Save ESC: Exit Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 32 SI-32-N User Manual Shutdown Temperature Configuration Aptio Setup Utility Advanced Main Chipset Boot Security Save & Exit → ← Select Screen APCI Shutdown Temperature Disabled ↑↓Select Item Enter: Select +- Change Field F1: General Help F2: Previous Values F3: Optimized Default F4: Save ESC: Exit ACPI Shutdown Temperature...
  • Page 33 Maximum time the device will take before it properly reports itself to the Host Controller. ‘Auto’ uses default value: for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 34 SI-32-N User Manual NCT6106D Super IO Configuration Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit NCT6106D Super IO Configuration → ← Select Screen ↑↓Select Item Enter: Select NCT6106D Super IO Chip NCT6106D +- Change Field ► Serial Port 0 Configuration F1: General Help F2: Previous Values ►...
  • Page 35 OnChip SATA Type Native IDE /n RAID /n AHCI /n AHCI /n Legacy IDE /n IDE->AHCI /n HyperFlash OnChip IDE mode Legacy mode or Native mode SATA IDE Combined Mode Enabled or Disabled. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 36 SI-32-N User Manual SB USB Configuration Options: Main Advanced Chipset Boot Security Save & Exit → ← Select Screen ↑↓Select Item Enter: Select XHCI Controller 0 Disabled +- Change Field F1: General Help XHCI Controller 1 Disabled F2: Previous Values F3: Optimized Default F4: Save ESC: Exit Aptio Setup Utility...
  • Page 37 Set display mode for Option ROM. Options are Force BIOS and Keep Current. INT19 Trap Response Enable: Allows Option ROMs to trap Int 19. Boot Option Priorities Sets the system boot order. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 38 SI-32-N User Manual CSM parameters OpROM execution, boot options, filter, etc. Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit Launch CSM Always → ← Select Screen Boot option filter UEFI and Legacy ↑↓Select Item Launch PXE OpROM policy UEFI only Enter: Select +- Change Field...
  • Page 39 +- Change Field Maximum length F1: General Help F2: Previous Values F3: Optimized Default Administrator Password F4: Save ESC: Exit User Password Administrator Password Set Setup Administrator Password. User Password Set User Password. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 40 SI-32-N User Manual Save & Exit Settings Aptio Setup Utility Main Advanced Chipset Boot Security Save & Exit Save Changes and Exit Discard Changes and Exit Save Changes and Reset Discard Changes and Reset Save Options Save Changes → ← Select Screen Discard Changes ↑↓Select Item Enter: Select...

  • Page 41: Chapter 4 Drivers Installation

    After installing your Windows operating system, you must install first the Intel Chipset Software Installation Utility before proceeding with the drivers installation. 4.1 VGA Drivers Installation 1. Insert the drivers DVD that comes with the board. Click AMD, then AMD A70M Chipset Drivers. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 42 SI-32-N User Manual 2. Click AMD A70M Series Graphics Drivers. 3. When the welcome screen appears, click Next.
  • Page 43 4. Select the language you would like to be displayed and click Next. 5. Click Next to continue the installation process. 6. Select Express and the installation location and click Next. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
  • Page 44 SI-32-N User Manual 7. Click Accept to accept the End User License Agreement. 8. To reboot the system, click Yes.

  • Page 45: Audio Driver Installation

    Definition Audio Driver. 2. When the Welcome screen to the InstallShield Wizard appears, click Next. 3. InstallShield Wizard is now complete, click Finish to restart the system and for changes to take effect. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 46: Lan Drivers Installation

    SI-32-N User Manual 4.3 LAN Drivers Installation 1. Insert the drivers DVD that comes with the board. Click LAN Card. 2. Click Realtek LAN Controller Drivers.
  • Page 47 IBASE Technology Inc. 3. When the Welcome screen appears, click Next. 4. Now click Install to begin the installation. 5. InstallShield Wizard is complete. Click Finish. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 48: Appendix

    SI-32-N User Manual Appendix Mounting SI-32-N to the Wall You can install SI-32-N on plastic (LCD monitor), wood, drywall surface over studs, or a solid concrete or metal plane directly. Ensure the installer uses at least six M3 length 6mm screws to secure the system on the wall. Two M3 length 6mm screws are recommended to secure the system onto the wall.

  • Page 49: Wall Mounting Requirements

    This recommendation reduces the risk that someone may accidentally walk into and damage the device. Local laws governing the safety of individuals might require this type of consideration. Copyright © 2013 IBASE Technology Inc. All Rights Reserved.

  • Page 50: 32-N Mounting Bracket Solution

    SI-32-N User Manual SI-32-N Mounting Bracket Solution SI-32-N mounting bracket Ibase part number: SC2SIMK3---0A1100P Please install SI-32-N to the mounting bracket with 4 screws as shown.
