- Page 1 SI-623-N Digital Signage Player User’s Manual Version 1.0 (Oct. 2017)
- Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
-
Page 3: Compliance
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) SI-623-N User Manual... -
Page 4: Important Safety Information
CAUTION There is a danger of explosion if the lithium-ion battery is replaced with an incorrect battery. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries by observing local regulations. SI-623-N User Manual... -
Page 5: Warranty Policy
The arrangement of the peripherals • Software used (such as OS and application software) 3. If repair service is required, please download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. SI-623-N User Manual... -
Page 6: Table Of Contents
2.4.4 CPU Fan Power Connector (J3) ..........20 2.4.5 USB 2.0 Ports Header (J12) ............ 21 2.4.6 COM2 RS-232 Port (J10) ............21 2.4.7 System Function Connector (J14) ......... 22 2.4.8 Digital I/O Connector (J13) ............22 SI-623-N User Manual... - Page 7 4.5.2 PCH-IO Configuration .............. 44 Security Settings ..................45 Boot Settings..................46 Save & Exit Settings................47 Appendix ....................... 48 I/O Port Address Map ................49 Interrupt Request Lines (IRQ) ..............51 Watchdog Timer Configuration ............... 52 SI-623-N User Manual...
-
Page 9: Chapter 1 General Information
Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Optional Accessories • Overview • Dimensions... -
Page 10: Introduction
1.1 Introduction ® The SI-623-N is a fanless digital signage system powered by Intel Generation mobile processors. It supports three display outputs for HDMI high definition video playback and iSmart energy-saving features such as power on/off scheduling and power resume function. The device operates in environments with temperatures ranging from 0°C to 45°C. -
Page 11: Packing List
General Information 1.3 Packing List If you buy a barebone SI-623-N, your product package should include the items listed below. If any of the items below is missing, contact the distributor or the dealer from whom you have purchased the product. -
Page 12: Specifications
(W x H x D) Net Weight 2.4 kg (5.29 lb) Compliance CE, FCC class B, cULus & CCC I/O Ports • 1 x HDMI 2.0 HDMI • 2 x HDMI 1.4 1 x GbE RJ45 LAN port SI-623-N User Manual... - Page 13 1 x Mini-PCIe (x1) for WiFi / BT / TV tuner / 4G LTE options Environment • Operating: 0°C ~ 45°C (32°F ~ 113°F) Temperature • Storage: -20°C ~ 80°C (-4°F ~ 176°F) Relative 10 ~ 90% (non-condensing) Humidity All specifications are subject to change without prior notice. SI-623-N User Manual...
-
Page 14: Overview
1.6 Overview Top View Wall Mount Side Mount Remarks: The same set (2pcs) of mounting kit can be used for wall mount or side mount methods as shown above. SI-623-N User Manual... - Page 15 USB 2.0 Mounting Kit LAN Port Antenna Hole Be sure to press the EDID Button to acquire or change the EDID data when the connected display/monitor cannot be recognized, or the displayed image does not fit the screen. SI-623-N User Manual...
-
Page 16: Dimensions
1.7 Dimensions Unit: mm SI-623-N User Manual... -
Page 17: Hardware Installation & Motherboard Information
Chapter 2 Hardware Installation & Motherboard Information This section contains general information about: • Essential installations instructions • Jumper and connectors... -
Page 18: Installations
To remove a module, use your fingers to press the clips outwards until the module pops up. Grab the module gently and pull it out of the slot. SI-623-N User Manual... -
Page 19: Mini-Pcie & M.2 Cards Installation
(Insert M.2 cards by using the same method.) 2. Push the mini PCIe card downwards as shown in the picture, and fix it with a screw. (Fix M.2 cards by using the same method.) Mini PCIe: M.2: SI-623-N User Manual... -
Page 20: Wifi / 3G / 4G Antenna Installation
Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). 2.1.4 HDMI Cable Holder Installation An HDMI cable holder comes with the product package. Align it to the HDMI ports and secure it with the supplied round-head screws (2x) with washer as shown below. SI-623-N User Manual... -
Page 21: Mounting Installation
The method of mounting must be able to support weight of the SI-623-N plus the weight of the suspending cables attached to the system. Use the following methods for mounting your system: Wall Mounting Installation Turn your device upside down. -
Page 22: Pin Assignment For Power Input Connector
2.1.6 Pin Assignment for Power Input Connector Signal Signal Ground +12V Ground +12V SI-623-N User Manual... -
Page 23: Setting The Jumpers
Motherboard Information 2.2 Setting the Jumpers Configure your SI-623-N by using jumpers to enable the features that you need based on your applications. Contact your supplier if you have doubts about the best configuration for your use. 2.2.1 How to Set Jumpers Jumpers are short-length conductors consisting of several metal pins with a base mounted on the circuit board. -
Page 24: Jumper & Connector Locations On Motherboard
2.3 Jumper & Connector Locations on Motherboard Motherboard: MBD623 MBD623 – top view SI-623-N User Manual... - Page 25 Motherboard Information MBD623 – bottom view SI-623-N User Manual...
-
Page 26: Jumper & Connectors Quick Reference
Factory Use Only J4, J7, J8, J9, J11 Be sure to press the EDID Button to acquire or change the EDID data when the connected display/monitor cannot be recognized, or the displayed image does not fit the screen. SI-623-N User Manual... -
Page 27: Clearing Cmos Data Selection (Jp7)
Motherboard Information 2.4.1 Clearing CMOS Data (JP7) Function Pin closed Illustration Normal (default) Clear CMOS 2.4.2 DC Power Input (CN12) Signal Signal Ground +12V Ground +12V SI-623-N User Manual... -
Page 28: Com1 Rs-232 Port (Cn7)
DCD (Data carrier detect) Ground DTR (Data terminal ready) Ground CTS (Clear to send) TX (Transmit) RTS (Request to send) RX (Receive) RI (Ring indicator) 2.4.4 CPU Fan Power Connector (J3) Signal Name Signal Name Ground Rotation detection +12V SI-623-N User Manual... -
Page 29: Usb 2.0 Ports Header (J12)
COM2 RS-232 Port (J10) Signal Name Signal Name DCD (Data carrier detect) DSR (Data set ready) RXD (Receive data) RTS (Request to send) TXD (Transmit data) CTS (Clear to send) DTR (Data terminal ready) RI (Ring indicator) Ground SI-623-N User Manual... -
Page 30: System Function Connector (J14)
2.4.7 System Function Connector (J14) Signal Name Signal Name Power BTN Power BTN HDD LED+ HDD LED- Reset BTN Reset BTN +5VSB 2.4.8 Digital I/O Connector (J13) Signal Name Signal Name Ground OUT3 OUT1 OUT2 OUT0 SI-623-N User Manual... -
Page 31: Chapter 3 Driver Installation
Chapter 3 Driver Installation The information provided in this chapter includes: • ® Intel Chipset Software Installation Utility • ® Intel HD Graphics Drivers • HD Audio Drivers • LAN Network Drivers • ® Intel Management Engine Components Drivers... -
Page 32: Introduction
Next to continue. 3. Accept the license agreement and proceed with the installation process. 4. On the Readme File Information screen, click Install. 5. Installation is now complete. Restart the system for changes to take effect. SI-623-N User Manual... -
Page 33: Intel Graphics Driver Installation
3. Click Yes to agree with the license agreement and continue the installation. 4. On the Readme File Information and Setup Progress screen, click Next until the installation starts. 5. Installation is now complete. Restart the system for changes to take effect. SI-623-N User Manual... -
Page 34: Hd Audio Driver Installation
1. Run the Setup.exe file and the wizard starts. 2. On the Welcome screen of the InstallShield Wizard, click Next to start installing the audio driver on your system. 3. Installation is now complete. Restart the system for changes to take effect. SI-623-N User Manual... -
Page 35: Lan Driver Installation
3. Accept the license agreement and click Next. 4. On the Setup Options screen, tick the checkbox to select the desired driver(s) and click Next. 5. Click Install. 6. Installation is now complete. Restart the system for changes to take effect. SI-623-N User Manual... -
Page 36: Intel Management Engine Components Drivers Installation
Installation 1. Run the Setup.exe file. 2. When the Welcome screen appears, click Next. 3. Accept the license agreement and click Next for installation. 4. Installation is now complete. Restart the system for changes to take effect. SI-623-N User Manual... -
Page 37: Chapter 4 Bios Setup
Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Security Settings •... -
Page 38: Introduction
These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. SI-623-N User Manual... -
Page 39: Main Settings
System Language Choose the system default language. System Date Sets the date. Use the <Tab> key to switch between the data elements. System Time Set the time. Use the <Tab> key to switch between the data elements. SI-623-N User Manual... -
Page 40: Advanced Settings
This section allows you to configure, improve your system and allows you to set up some system features according to your preference. 4.4.1 M.2 (NGFF) Configuration BIOS Setting Description M.2 (NGFF) B-Key Configures M.2 (NGFF) B-Key function. SI-623-N User Manual... -
Page 41: Ismart Controller
For example, if setting up a schedule from Wednesday 5 p.m. to Thursday 2 a.m., configure two schedule slots. But if setting up a schedule from 3 p.m to 5 p.m. on Wednesday, configure only a schedule slot. SI-623-N User Manual... -
Page 42: Amt Configuration
BIOS Setting Description Intel AMT Enables / Disables Intel(R) Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled. This option just controls the BIOS extention execution. If enabled, additional firmware in the SPI device are required. SI-623-N User Manual... -
Page 43: F81846 Super Io Configuration
Sets parameters of Serial Ports (COMA). Enables / Disables the serial port and select an optimal setting for the Super IO device. 4.4.4.1. Serial Port 1 Configuration BIOS Setting Description Serial Port Sets parameters of Serial Ports (COMA). SI-623-N User Manual... - Page 44 IO = 2F8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 3E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 SI-623-N User Manual...
- Page 45 IO = 2E8h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 2F0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 • IO = 2E0h; IRQ = 3, 4, 5, 6, 7, 9, 10, 11, 12 SI-623-N User Manual...
-
Page 46: Hardware Monitor
This field enables or disables the Shutdown Temperature Temperature Temperatures / Voltages These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status. SI-623-N User Manual... -
Page 47: Cpu Configuration
BIOS Setup 4.4.6 CPU Configuration BIOS Setting Description Intel Virtualization When the function is enabled,a VMM can Technology utilize the additional hardware capabilities provided by Vanderpool Technology. SI-623-N User Manual... -
Page 48: Sata Configuration
SATA Controller(s) Enables / Disables SATA devices. SATA Mode Selection Determines how the SATA controller(s) operate. Options: AHCI Mode, RAID Mode Serial ATA Ports Enables / Disables Serial Ports. Hot Plug Designates this port as Hot Pluggable. SI-623-N User Manual... -
Page 49: Csm Configuration
BIOS Setup 4.4.8 CSM Configuration BIOS Setting Description CSM Support Enables or disables CSM support. SI-623-N User Manual... -
Page 50: Usb Configuration
The maximum time the device will take before it properly reports itself to the Host Controller. “Auto” uses default value for a Root port it is 100ms. But for a Hub port, the delay is taken from Hub descriptor. SI-623-N User Manual... -
Page 51: Chipset Settings
BIOS Setup 4.5 Chipset Settings BIOS Setting Description System Agent (SA) System Agent parameters Configuration PCH-IO Configuration PCH parameters 4.5.1 System Agent Bridge Name SI-623-N User Manual... -
Page 52: Pch-Io Configuration
4.5.2 PCH-IO Configuration BIOS Setting Description PCI Express PCI Express configuration settings Configuration SI-623-N User Manual... -
Page 53: Security Settings
BIOS Setup 4.6 Security Settings BIOS Setting Description Administrator Password Sets an administrator password for the setup utility. User Password Sets a user password. SI-623-N User Manual... -
Page 54: Boot Settings
Specifies the Boot device priority sequence from available hard disk drives. Boot Mode Select Selects a Boot mode. Fixed Boot Order Sets the system boot order. Priorities Boot Option Priorities Sets the system boot order priorities for hard disk, CD/DVD, USB, Network. SI-623-N User Manual... -
Page 55: Save & Exit Settings
Restore Defaults Restores / Loads defaults values for all the setup options. Save as User Defaults Saves the changes done so far as user defaults. Restore User Defaults Restores the user defaults to all the setup options. SI-623-N User Manual... -
Page 56: Appendix
Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Digital I/O Sample Code • Watchdog Timer Configuration... -
Page 57: I/O Port Address Map
Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources 0x00001800-0x000018FE Motherboard resources 0x0000164E-0x0000164F Motherboard resources 0x00000800-0x0000087F Motherboard resources 0x00000020-0x00000021 Programmable interrupt controller 0x00000024-0x00000025 Programmable interrupt controller 0x00000028-0x00000029 Programmable interrupt controller 0x0000002C-0x0000002D Programmable interrupt controller 0x00000030-0x00000031 Programmable interrupt controller 0x00000034-0x00000035 Programmable interrupt controller SI-623-N User Manual... - Page 58 Intel(R) 100 Series/C230 Series Chipset Family SMBus - A123 0x00000060-0x00000060 Standard PS/2 Keyboard 0x00000064-0x00000064 Standard PS/2 Keyboard 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer 0x0000F090-0x0000F097 Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F060-0x0000F07F Standard SATA AHCI Controller SI-623-N User Manual...
-
Page 59: Interrupt Request Lines (Irq)
Intel(R) USB 3.0 eXtensible Host Controller - 1.0 (Microsoft) IRQ 4294967291 Intel(R) HD Graphics 530 IRQ 4294967292 Intel(R) Ethernet Connection (2) I219-V IRQ 4294967293 Standard SATA AHCI Controller IRQ 4294967294 Intel(R) 100 Series/C230 Series Chipset Family PCI Express Root Port #6 - A115 SI-623-N User Manual... -
Page 60: Watchdog Timer Configuration
Fintek 81846, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime); if (bTime) EnableWDT(bTime); } else DisableWDT(); } return 0; SI-623-N User Manual... - Page 61 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81846_LD(0x07); //switch to logic device 7 bBuf = Get_F81846_Reg(0xFA); bBuf &= ~0x01; Set_F81846_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81846_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81846_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- SI-623-N User Manual...
- Page 62 Init_Finish; } F81846_BASE = 0x00; result = F81846_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81846 (void) outportb(F81846_INDEX_PORT, F81846_UNLOCK); outportb(F81846_INDEX_PORT, F81846_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81846 (void) outportb(F81846_INDEX_PORT, F81846_LOCK); //--------------------------------------------------------------------------- void Set_F81846_LD( unsigned char LD) Unlock_F81846(); outportb(F81846_INDEX_PORT, F81846_REG_LD); outportb(F81846_DATA_PORT, LD); Lock_F81846(); SI-623-N User Manual...
- Page 63 //--------------------------------------------------------------------------- #defineF81846_INDEX_PORT (F81846_BASE) #defineF81846_DATA_PORT (F81846_BASE+1) //--------------------------------------------------------------------------- #defineF81846_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81846_UNLOCK 0x87 #defineF81846_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81846(void); void Set_F81846_LD( unsigned char); void Set_F81846_Reg( unsigned char, unsigned char); unsigned char Get_F81846_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81846_H SI-623-N User Manual...
