IBASE Technology SA-112-N User Manual

Android/linux digital signage player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SA-112-N
Android / Linux
Digital Signage Player
User's Manual
Version 1.0
(Jun. 2016)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA-112-N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBASE Technology SA-112-N

Summary of Contents for IBASE Technology SA-112-N

  • Page 1 SA-112-N Android / Linux Digital Signage Player User’s Manual Version 1.0 (Jun. 2016)
  • Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).

  • Page 3: Compliance

    Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) • Bis(2-ethylhexyl) phthalate (DEHP) • Butyl benzyl phthalate (BBP) • Dibutyl phthalate (DBP) • Diisobutyl phthalate (DIBP) SA-112-N User Manual...

  • Page 4: Important Safety Information

    You are not suggested to disassemble, repair or make any modification to the device. Disassembly, modification, or any attempt at repair could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. SA-112-N User Manual...

  • Page 5: Caution

    Software in use (such as OS and application software, including the version numbers) If repair service is required, you can download the RMA form at our website > Support > RMA Service. Fill out the form and contact your distributor or sales representative. SA-112-N User Manual...

  • Page 6: Table Of Contents

    Exit from Playing Mode ................. 25 Wireless Connection ................26 Firmware Update .................. 28 Loading Factory Default ................ 30 Chapter 4 Content Management ............. 31 ADPlayer ....................32 Uploading and Updating Media Files ............. 34 Editing Media Files ................35 SA-112-N User Manual...
  • Page 7 Setting up the Playing Schedule ............36 Appendix ...................... 37 APK Example Content ................38 The Protocol File of ADPlayer ............... 38 SA-112-N User Manual...

  • Page 8: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes:  Features  Packing List  Specifications  Overview  Dimensions...

  • Page 9: Introduction

    1.1 Introduction SA-112-N, a product code of IBASE Digital Signage Player series, is an Android / Linux system for general applications. It is a fanless signage player ® ® with ARM -based Cortex A9 i.MX6 Dual/Quad processor and outputs through HDMI or VGA. The device provides 3D graphics acceleration and supports various peripherals, such as RS-232 COM, CAN, USB, VGA and HDMI, and audio line-out.

  • Page 10: Packing List

    1.3 Packing List Your SA-112-N package should include the items listed below. If any of the items below is missing, contact the distributor or the dealer from whom you purchased the product.  SA-112-N Android / Linux Digital Signage Player ...

  • Page 11: Specifications

    CE, FCC, cULus, CCC I/O Ports 1 x HDMI (up to 1920 x 1080) Display 1 x VGA 1 x GbE RJ45 Serial Port 1 x COM (RS-232) 2 x USB 2.0 Type A 1 x Mini-USB (OTG) SA-112-N User Manual...
  • Page 12 Operating: -40 ~ 75 °C (-40 ~ 167 °F), without adapter Temperature  Storage: --50 ~ 85 °C (-58 ~ 185 °F) Relative 5 ~ 90% (non-condensing) Humidity Vibration Operating, random vibration 5 grms (5~500Hz) Protection All specifications are subject to change without prior notice. SA-112-N User Manual...

  • Page 13: Overview

    No. Name Name LED Indicators LAN Port Power Button USB 2.0 Port DC Jack Audio Line Out HDMI Port SD Card Slot COM RJ45 Port USB OTG Port VGA Port WiFi / 3G / 4G Antenna Hole SA-112-N User Manual...
  • Page 14 Oblique View SA-112-N User Manual...

  • Page 15: Dimensions

    1.7 Dimensions Unit: mm SA-112-N User Manual...

  • Page 16: Chapter 2 Installation And Motherboard Information

    Chapter 2 Installation and Motherboard Information The information provided in this chapter includes:  Hardware Installation  Information and locations of connectors...

  • Page 17: Hardware Installation

    2.1.1 WiFi / 3G / 4G Module Installation 1. Remove the following 4 screws to remove the cover of SA-112-N. 2. Remove the cover, thread the WiFi / 3G / 4G antenna and cable through an antenna hole and fasten the antenna.
  • Page 18 4. Fix the other end of the cable onto the board to receive signals. 2.1.2 Wall Mount Installation Fasten 6 screws for VESA mount installation. SA-112-N User Manual...

  • Page 19: Connector Locations On Motherboard

    2.2 Connector Locations on Motherboard Motherboard: MBD112 SA-112-N User Manual...

  • Page 20: Jumper & Connector Quick Reference Table

    Mini PCIe Connector RTC Battery Connector I/O coastline connectors: Function Connector Name Page Audio Jack COM RJ45 Port DC Jack HDMI Port Mini USB OTG Port RJ45 LAN Port SD Card Connector USB 2.0 Port P6, P7 VGA Port SA-112-N User Manual...
  • Page 21 2.3.1 AT / ATX Power Mode Connector (P16) Function Pin closed Illustration ATX Mode AT Mode 2.3.2 CAN Connector (P12) Assigment CAN2_RX CAN2_TX SA-112-N User Manual...
  • Page 22 2.3.3 GPIO Connector (P15) Assigment Assigment OUTPUT 3 OUTPUT 1 OUTPUT 2 OUTPUT 0 INPUT 3 INPUT 1 INPUT 2 INPUT 0 SA-112-N User Manual...
  • Page 23 2.3.4 Mini PCIe Connector (P9) Assigment Assigment Assigment nWAKE USB-D- nDISABLE USB-D+ Nreset AUD4_TXC AUD4_TXD AUD4_RXD AUD4_TXFS SA-112-N User Manual...
  • Page 24 2.3.5 RTC Battery Connector (P12) Assigment Battery + Battery - 2.3.6 Audio Jack (P5) Assigment HP_RIGHT HP_DET_B HP_LEFT 2.3.7 COM RJ45 Connector (P13) Assigment Assigment SA-112-N User Manual...
  • Page 25 2.3.8 DC Jack (P3) Assigment DC_5V DC_GND 2.3.9 HDMI Port (P10) Assigment Assigment TX2_P TXC_N TX2_N CEC_A TX1_P DSCL TX1_N DSDA TX0_P TX0_N TXC_P 2.3.10 Mini USB OTG Port (P8) Assigment USB_OTG_ID SA-112-N User Manual...
  • Page 26 RJ45 LAN Port (P11) Assigment Assigment TRX0+ TRX3+ TRX0- TRX3- TRX1+ LED_Y+ TRX2+ LED_Y- TRX2- LED_G+ TRX1- LED_G- 2.3.12 SD Card Connector (P4) Assigment Assigment SD2_DATA3 SD2_CMD SD2_DATA0 SD2_DATA1 SD2_DATA2 SD2_CLK SD_DET_B 2.3.13 USB 2.0 Port (P6, P7) Assigment SA-112-N User Manual...
  • Page 27 2.3.14 VGA Port (P14) Assigment Assigment VGA_R VGA_G VGA_B VGA_HS VGA_VS SA-112-N User Manual...

  • Page 28: Chapter 3 System Setup

    Chapter 3 System Setup The information provided in this chapter includes:  System Quick Installation  Playing Mode  Exit from Playing Mode  Wireless Connection  Firmware Update  Loading Factory Default...

  • Page 29: System Quick Installation

    3.1 System Quick Installation To set up your SA-112-N, place the device on a flat, stable and solid surface, and prepare all the items in the package. Then follow the steps below for quick installation. 1. Connect your SA-112-N to a display device with supplied HDMI cable.
  • Page 30 You can upate or change these media files. 2. If your SA-112-N does not have any media content pre-loaded, the below screen will show up and you will need to upload media files. Refer to Chapter 3 Content Management.

  • Page 31: Playing Mode

    The images are played with a default interval of 10 seconds, and the interval is only configurable by IBASE. The text messages scroll automatically. Note: The video files playing over the network should be short in length. For more information about updating media files, refer to Chapter 3 Content Management. SA-112-N User Manual...

  • Page 32: Exit From Playing Mode

    The following screenshots are based on Android. After exiting from the playing mode, you will see the Home screen of Android below. Then if there is no user activity for 60 seconds, the system will return to the playing mode automatically. SA-112-N User Manual...

  • Page 33: Wireless Connection

    3.4 Wireless Connection 3.4.1 WiFi Connection With the built-in WiFi module in SA-112-N, you are able to access to network on this device. Follow the steps below to turn on WiFi. The following screenshots are based on Android. 1. On the Home screen of SA-112-N, click the Menu icon 2.
  • Page 34 Internet now. 3.4.2 Bluetooth Connection 1. On the Home screen, click the Menu icon 2. In the APPS tab, click Settings in the APPS tab. 3. Click Bluetooth, and turn it on. SA-112-N User Manual...

  • Page 35: Firmware Update

    3.5 Firmware Update To update the firmware of SA-112-N, you need to contact IBASE for the latest new firmware image, copy it to a USB flash drive or an SD card, and insert to the device. Then update the firmware by referring to the following instructions.
  • Page 36 4. In this example, the firmware image is named ”mbd101-ota-20150505- 172629.zip”. Click Update Firmware to start. SA-112-N User Manual...

  • Page 37: Loading Factory Default

    If you need to load the factory default settings, follow the steps below. 1. On the Home screen, click the Menu icon 2. In the APPS tab, click Settings in the APPS tab. 3. Click Factory Data Reset and the factory default settings will be automatically loaded. SA-112-N User Manual...

  • Page 38: Chapter 4 Content Management

    Chapter 4 Content Management The information provided in this chapter includes:  ADPlayer  Uploading / Updating Media Files  Editing Media Files  Setting up the Playing Schedule...

  • Page 39: Adplayer

    Home screen, click ES File Explore, and click the Adplayer.apk for installation. The Advance ADPlayer is a software program applying for SA-112-N, supporting 2 types of screen layout as below – portrait and landscape. Choose a desired type of layout per your request. We also provide another software program if a specific screen layout is preferred.
  • Page 40 The content manager will regularly keep checking the media files from the SD card, USB flash drive, and the network directory. If there is any change made to the media content, the text message file text.xml will be updated. SA-112-N User Manual...

  • Page 41: Uploading And Updating Media Files

    After the media files have been completely transferred, SA-112-N will start to play these files. Note: 1. Do not turn off SA-112-N or remove the USB flash drive or SD card during transfer. 2. It may time some time to transfer large-sized media files.

  • Page 42: Editing Media Files

    4.3 Editing Media Files Not only can you edit the media files saved on SA-112-N, but the media files saved either on the USB flash drive or on the SD card can also be edited when inserted to the device.

  • Page 43: Setting Up The Playing Schedule

    The media playing schedule goes on the basis of the names of the media files. You can create a naming convention with respect to ordering relation and make the filenames all begin with a numeric or alphabetical character in a contiguous sequence. SA-112-N User Manual...

  • Page 44: Appendix

    Appendix The information provided in this chapter includes:  APK Example Content  The Protocol File of ADPlayer...

  • Page 45: Apk Example Content

    Update all: all the files in the relative direction will update, and remove original file Update section: copy files in the relative direction and keep original file SA-112-N User Manual...
