Black Compact Electric Single Motor Desk Frame
Instruction Manual
SKU: DESK-E151PB
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-e151pb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-E151PB and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo DESK-E151PB

  • Page 1 Black Compact Electric Single Motor Desk Frame Instruction Manual SKU: DESK-E151PB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-e151pb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
  • Page 3 TOOLS NEEDED Phillips Screwdriver DO NOT EXCEED WEIGHT CAPACITY. 154lbs Failure to do so may result in serious injury. (70kg) Level Drill ASSEMBLY STEPS STEP 1 Loosen the two set screws on the telescopic crossbar (A) using the Allen wrench (S-F). Adjust the crossbar length to suit the desktop.
  • Page 4 STEP 3 Attach the side brackets (E) to both ends of the frame using four M6x12mm bolts (S-A). Tighten with the Allen wrench (S-F). STEP 4 Loosen the knob on the socket end of the sync rod (F) and slide the sync rod onto the shaft of the motorized leg.
  • Page 5 STEP 6 Place the frame upside down on desktop and drill pilot holes for the screws. Use a 3/32” or 3mm bit, and drill holes to a depth of 3/8” (10mm). Readjust the sync rod if necessary. STEP 7 Place the feet (G) on the legs as shown.
  • Page 6 STEP 9 Connect the AC adapter and motorized leg to the controller (K). Connect the power cable (J) to the AC adapter. STEP 10 Insert the anti-vibration pads (S-E) into the desktop mounting holes in the crossbar and side brackets. STEP 11 Place the assembled frame on the desktop, making sure the pre-drilled holes are aligned with the desk frame, and secure the frame using...
  • Page 7 STEP 12 Attach the controller to the underside of the desktop using screws (S-C) as shown. ST3.5x20 Once controller is installed, cable clips (S-E) can be attached to the desk for cable management. Refer to the Controller User Guide for operational instructions.
