Vivo DESK-E155TW Instruction Manual

White 55" x 24" electric desk
Hide thumbs Also See for DESK-E155TW:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

White 55" x 24" Electric Desk
Instruction Manual
SKU: DESK-E155TW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-e155tb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-E155TW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo DESK-E155TW

Summary of Contents for Vivo DESK-E155TW

  • Page 1 White 55" x 24" Electric Desk Instruction Manual SKU: DESK-E155TW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-e155tb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Electrical Safety Instructions

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.

  • Page 3: Tools Needed

    PACKAGE CONTENTS - CONTINUED S-A (x8) S-B (x10) S-C (x27) S-D (x8) T-A (x1) T-B (x1) M6X35mm M6x11mm M5x16mm Wooden 2mm Allen 5mm Allen Screws Screws Screws Dowels Wrench Wrench TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 176lbs Level Phillips Drill Failure to do so may result in serious injury.
  • Page 4 STEP 2 Turn assembly upside and install Foot (G) onto Leg (E) and Motorized Leg (F) using M6x35mm Screws (S-A) and 5mm Allen Wrench (T-B). STEP 3 Attach Side Brackets (C) to Leg (E) and Motorized Leg (F) using M6x11mm (S-B) and 5mm Allen Wrench (T-B), Enusre that arrow on Side Brackets (C) are pointed away from desk.
  • Page 5 STEP 4 Loosen the nut on Sync Rod (D) and insert the hex rod end into Leg (E). While holding the hex end, pull the larger rod out until the connector engages with Motorized Leg (F). Tighten the set screw on Sync Rod (D) using 2mm Allen Wrench (T-A), then tighten the nut.
  • Page 6 STEP 6 Secure desk frame to desktop by installing M5x16mm Screws (S-C) into Side Brackets (C). Install Control Panel (I) and Headphone Hook (K) using M5x16mm Screws (S-C). STEP 7 Connect AC Adapter (J) and cord from Motorized Leg (F) to Control Panel. Organize cables underneath desk with Cable Clips (M).
  • Page 7 STEP 7 Place Grommet Covers (L) into grommet holes on desktop. CAUTION! Do not exceed desk Keep area of vertical Keep weight on desk Leave enough slack in weight limit. motion free of balanced for correct cables to allow for full obstacles.
  • Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
