Capacities:
Miter angle ............................................................................................................................................. 90 to 45 deg.
Round capacity at 90° ............................................................................................................................. 7" (180 mm)
Round capacity at 45° ............................................................................................................................. 4" (100 mm)
Round capacity at 30° ......................................................................................................................... 6-3/4"(171mm)
Rectangle capacity at 90° (W x H) .............................................................................. 7" x 10-13/64" (180 x 260 mm)
Rectangle capacity at 45° (W x H) .......................................................................................3-3/4" x 4" (95x 100 mm)
Rectangle capacity at 30° (W x H) ....................................................................................5-3/4" x 6" (146 x 150 mm)
Coolant tank capacity ............................................................................................................................. 9L (2.25 gal)
Motor and Electricals:
Motor type ........................................................................................................ totally enclosed fan cooled, induction
Horsepower ....................................................................................................................................... 1 HP (0.75 kW)
Phase ............................................................................................................................................................... single
Voltage ........................................................................................................................... 115/230 V (prewired 115V)
Cycle .................................................................................................................................................................. 60Hz
Listed FLA (full load amps) .............................................................................................................................. 14/7 A
Starting amps ....................................................................................................................................................... 35A
Running amps (no load) ...................................................................................................................................... 12A
Power transfer ............................................................................................................................................... gearbox
Control switch ........................................................................................................ push button with emergency stop
Motor speed ................................................................................................................................................. 1720 rpm
Blade speeds ............................................................................................................................... 145, 200, 245 sfpm
Power cord length ............................................................................................................................... 6 feet (180 cm)
Power cord type ........................................................................................................................................ 16AWGx3c
Power plug installed .............................................................................................................................................. yes
Recommended circuit size
Noise emission:
without load ............................................................................................................. 70 dB at 60 inches from blade
with load .................................................................................................................. 75 dB at 60 inches from blade
Coolant pump:
Horsepower ..................................................................................................................................................... 1/8 HP
Phase ............................................................................................................................................................... single
Voltage .......................................................................................................................................................115/230 V
Cycle .................................................................................................................................................................. 60Hz
Listed FLA (full load amps) .........................................................................................................................0.5/0.25 A
Weights:
Net Weight ......................................................................................................................................... 396 lb (180 kg)
Shipping Weight .................................................................................................................................. 462 lb (210 kg)
Dimensions:
Blade .................................................................................................. 3/4"W x 0.035"T x 93"L (19 x 0.9 x 2360 mm)
Blade wheel diameter ..................................................................................................................... 11-1/2" (292 mm)
Vise jaw height ........................................................................................................................................ 4" (102 mm)
Vise jaw depth ........................................................................................................................................ 7" (180 mm)
Table size (LxW) ................................................................................................................... 17" x 7" (432 x 178 mm)
Table height from floor, horizontal .................................................................................................. 22-7/8" (580 mm)
Vertical cutting plate ................................................................................................. 9-1/2"L x 10"W (241 x 254 mm)
Cutting plate height from floor ................................................................................................... 42-29/32" (1090 mm)
Overall assembled, horizontal position ........................................... 50"L x 31-1/2"W x 48"H (1260 x 800x 1220 mm)
Overall assembled, vertical position .................................... 50"L x 31-1/2"W x 72-29/64"H (1260 x 800 x 1840 mm)
Other:
Miter stops .......................................................................................................................................... 90 and 45 deg.
Blade tension range ...................................................................................... 22000-25000 lb/in² (1550-1760 kg/cm²)
1 230V requires purchase and installation of 230V-only magnetic contactor (p/n HVBS710S-250N).
2
subject to local and national electrical codes.
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, JET reserves the right to change specifications at any time and without prior notice, without incurring
obligations.
2
............................................................................................ 20A for 115V; 15A for 230V
