Summary of Contents for Dimplex Opti-Myst Cassette 500

  • Page 1 CAS500 CAS1000 08/52890/0 Issue 1 The product complies with the European Safety Standards EN60335-2-30 and the European Standard Electromagnetic Compatibility (EMC) EN55014, EN60555-2 and EN60555-3 These cover the essential requirements of EEC Directives 2006/95/EC and 2004/108/EC...
  • Page 2 Dimplex CAS500, CAS1000 Introduction Please read this information guide carefully to be able to safely install, use and maintain your product. Important Safety Advice When using electrical appliances, basic precautions should always be followed to reduce the risk of fi re, electrical shock and injury to persons, including the following: If the appliance is damaged, check with the supplier before installation and operation.
  • Page 3: General Information

    General Information Only use fi ltered water in this appliance. Unpack the appliance carefully and retain the packaging for possible future use, in the event of moving or returning the fi re to your supplier. Always ensure that the appliance is sitting on a level surface. The appliance is a fl...
  • Page 4: Operating The Product

    the Maintenance section Please note: the water pressure is to be between 8Bar (800Kilopascals) and 0.5Bar (50Kilopascals). If you do not feel confi dent making this connection please consult a qualifi ed plumber, to ensure a safe and secure installation. Electrical Connection Plug the fi...
  • Page 5: Getting The Desired Flame Effect

    beep when you reach the maximum level • is the reduce fi re crackling sound. Press this to reduce the volume of the crackling sound. The minimum volume for this is off • is the increase fi re crackling sound. Press this to increase the volume of the crackling sound. CAS1000 Mains Switch ‘A’:- Controls the electricity supply to the appliance.
  • Page 6: Bluetooth Remote Control

    12. Reverse the above steps to reassemble. Transducer The transducer is a consumable item and may need to be replaced through time, depending on its usage. Replacement transducers can be purchased from our website http://spares.dimplex.co.uk. The transducer is fi xed in the sump with a...
  • Page 7: Additional Information

    plastic clip. If you need to replace your transducer 1. Follow the steps 1-5 in the CLEANING Sump section under ‘Maintenance’ to gain access to the transducer 2. Press the clip back and lift the transducer upwards out of its holder. 3.
  • Page 8: Troubleshooting

    Troubleshooting Symptom Cause Corrective Action The fl ame effect will Mains plug is not plugged in. Check plug is connected to wall socket cor- not start. rectly. Low water level. Check that the water tank is full and there is water in the sump.
  • Page 9 MODEL DIM ‘A’ CAS500 508mm CAS1000 1017mm Fig.1 Fig.2 Fig.3a Fig.3b Fig.3c Fig.4 Fig.5...
  • Page 10 Fig.6 Fig.7 CAS500 CAS1000 Fig.8a Fig.8b...
  • Page 11 Switch ‘A’ CAS500 Fig.9 CAS1000 Fig.10 Fig.11 Fig.12 Fig.13 Fig.14...
