INSTALLATION AND USER'S GUIDE
We value your feedback!
Your input helps to create even better products and experiences.
Share the warmth and leave a review.
dimplex.com/sharethewarmth
IMPORTANT SAFETY INFORMATION:
Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety
instructions contained in this manual to prevent personal injury or property damage.
To view the full line of Dimplex products, visit www.dimplex.com
Models
500002573 Evolve 50
500002574 Evolve 60
500002608 Evolve 74
500002563 Evolve 100
Certified to:
UL 2021, 4th Ed.
7216710100R05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dimplex Evolve 50
Summary of Contents for Dimplex Evolve 50
- Page 1 Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, visit www.dimplex.com 7216710100R05...
-
Page 2: Table Of Contents
NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of re, serious injury, or death. www.dimplex.com... -
Page 3: Welcome
Welcome Thank you and congratulations for choosing to purchase a Dimplex replace. Please carefully read and save these instructions. WARNING: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, re hazard and will void the warranty. -
Page 4: Important Instructions
⑦ Do not use this fireplace outdoors. ⑧ Never locate the fireplace where it may fall into a bathtub or other water container. SAVE THESE INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN NO USER-SERVICEABLE PARTS INSIDE www.dimplex.com... - Page 5 IMPORTANT INSTRUCTIONS CALIFORNIA PROPOSITION 65 WARNING: WARNING: This product can expose you to chemicals including nickel which is known to the State of California to Remote control contains a small battery. cause cancer. For more information, visit Keep away from children. If swallowed, seek www.P65Warnings.ca.gov medical attention immediately.
-
Page 6: Technical Specifications
74" model 74.31 in [1887 mm] 100" model 100.31 in [2548 mm] 4.34 in. 50" model 51.41 in [1306 mm] 110 mm 60" model 61.41 in [1560 mm] 5.79 in. 74" model 75.41 in [1941 mm] 147 mm 100" model 101.41 in [2576 mm] www.dimplex.com... -
Page 7: Package Contents
Package Contents Quantity Image Description 500002573 500002574 500002608 500002563 Evolve 50 Evolve 60 Evolve 74 Evolve 100 Remote Control Bag of Medium Acrylic ~1.2 lb ~1.5 lb ~1.8 lb ~2.4 lb Crystals ~0.54 kg ~0.68 kg ~0.8 kg ~1.08 kg... -
Page 8: Optional Accessories
Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, visit www.dimplex.com 7216710100R04... -
Page 9: Installation
Installation Placement NOTE: It is recommended that the bottom of the unit be mounted between 5" (13 cm) and 40" (102 cm) from the ground to maintain an optimized viewing angle of the ame. WARNING: The top of the replace must be installed a minimum of 24" (61 cm) from the ceiling. The replace must be installed a minimum of 5"... -
Page 10: Installation Instructions
4. Lift the rebox into the opening in the frame using the handles on the back of the replace. 5. Using a bubble level (supplied) ensure that the replace is level within the framing. Adjust as required. Cable Clamp www.dimplex.com... - Page 11 Installation Distance from the right side to the wiring inlet: 500002573 , 500002574 Evolve 50 Evolve 60 500002563 Evolve 100 500002608 Evolve 74 13" (330.25mm) 20" (508.4mm) 6. Drive four supplied mounting screws through the four mounting holes located on the inside surface of the replace chassis, into wall studs.
-
Page 12: Electrical Installation
( B R E A K E R R e d - L 2 RED – L2 P A N E L ) G re e n - G rou nd G re e n - G rou nd www.dimplex.com... - Page 13 Installation 240 V Hardwire Installation Power Cord Installation WARNING: Power cord option is only suitable for You will need a 4-wire 240 V supply (L1, L2, Neutral, and 120 V installations. Ground). 1. Connect the black L1 wire from the unit to the L1 wire 1.
-
Page 14: Heater Hardware Disconnect
To disconnect the heater and fan permanently: 1. Locate the control board. The heater hardware disconnect jumper location is labeled “HEAT”. (Figure 10) 2. Pull out the heater hardware disconnect jumper. (Figure 11) Figure 10 Figure 11 Heater Hardware Disconnect Jumper/Connecter www.dimplex.com... -
Page 15: Mirrored Glass Installation
2. Remove the provided suction cup from the inside cavity of the unit (not included in 500002573 units). Evolve 50" 3. Ensure that the back of the glass is clean and free from particles and ngerprints. 4. Secure the suction cup to the mirrored glass on the re ective side 5. -
Page 16: Media Arrangement
The custom media must t easily without scratching the glass or bowing the media bed, and must not be composed of sand or liquid, which could interfere with the safety of the rebox. Figure 14 Figure 14 Figure 15 Figure 16 www.dimplex.com... -
Page 17: Front Glass Installation
Installation Front Glass Installation NOTE: Install the front glass before the replace is powered on. If the unit is powered on before the glass is installed, a full power reset will be required to activate the hidden touch controls. 1. Ensure that the mirrored glass and the inside of the front glass is clean and free from particles and ngerprints. 2. -
Page 18: Operation
NOTE: To operate correctly, the remote control must be pointed toward the front of the unit. The replace is capable of being controlled using the Flame Connect app for mobile devices. For up-to-date information about the app, please visit www.dimplex.com/fcapp Figure 20 Figure 19 www.dimplex.com... - Page 19 Operation Press to turn on the unit or to put it in standby mode. Standby When the unit is turned back on, it will retain the previously used settings. Flame Effect Press to turn the ame effect and media on or off. Press to turn the heat on or off.
- Page 20 3 seconds to reset all the settings to Factory Reset factory default. This action will also disconnect the unit from the Wi-Fi network if connected. This action must be performed on the hidden touch controls. www.dimplex.com...
-
Page 21: Maintenance
Maintenance Figure 21 Remote Control Battery Replacement 1. Remove battery cover of the remote control using a Philips screwdriver. 2. Correctly install the 3 Volt (CR2032 or similar) battery in the battery holder with the + side facing up. 3. Secure the battery cover using the previously removed screw. Batteries must be recycled or disposed of properly. -
Page 22: Troubleshooting
Ambient temperature is No action required. Err12 above 45° C (113° F) Ambient temperature is No action required. Err13 below 5° C (41° F) For more troubleshooting and error codes, consult the Service Manual which can be found at www.dimplex.com/product-downloads www.dimplex.com... -
Page 23: Wiring Diagrams
Wiring Diagrams 500002573 Evolve 50 500002574 Evolve 60... - Page 24 Wiring Diagrams 500002608 Evolve 74 500002563 Evolve 100 www.dimplex.com...
-
Page 25: Warranty
Section 1 Products to which this Limited Warranty Applies • Glen Dimplex Americas will in its sole discretion either repair or replace such defective product or part without This Limited Warranty applies to your newly purchased charge. If Glen Dimplex Americas is unable to repair or... - Page 26 The QR Code can be found on the back of the manual. 1-888-346-7539 | www.dimplex.com In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice. A BRAND OF GLEN DIMPLEX AMERICAS © 2023 Glen Dimplex Americas...
