Installation and User's Guide
We value your feedback!
Your input helps to create even better products and experiences.
Share the warmth and leave a review.
dimplex.com/sharethewarmth
@DimplexNorthAmerica
IMPORTANT SAFETY INFORMATION:
Read this manual first before attempting to install or use this electric fireplace. Always comply with the
warnings and safety instructions contained in this manual to prevent personal injury or property damage.
To view the full line of Dimplex products, visit www.dimplex.com
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE
Models
ASP30-AM
ASP36-AM
ASP42-AM
ASP48-AM
Certified to:
UL 2021, 4th
Ed.
7216830100R01
Advertisement
Table of Contents
Related Manuals for Dimplex Aspire ASP30-AM
Summary of Contents for Dimplex Aspire ASP30-AM
- Page 1 Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, visit www.dimplex.com INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
-
Page 2: Table Of Contents
Procedures and techniques techniques that are which, if not carefully which, if not carefully followed, considered important followed, will result in will expose the user to the risk enough to emphasize. damage to the equipment. of fire, serious injury, or death. www.dimplex.com... -
Page 3: Registration
If you have questions regarding the operation of this product or if you require service, before returning this product to the place of purchase. For technical support, contact us at: www .dimplex .com/support Toll-Free 1-888-346-7539 Please have your model number and product serial number ready. -
Page 4: Important Instructions
⑦ Never locate the fireplace where it may fall into a for compliance could void user’s authority to bathtub or other water container. operate the equipment. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN NO USER-SERVICEABLE PARTS INSIDE www.dimplex.com... -
Page 5: Fcc Compliance
IMPORTANT INSTRUCTIONS FCC Compliance WARNING: This product can expose you to chemicals including nickel which is known to CAUTION: This unit has been tested and found the State of California to cause cancer. For more to comply with the limits for Class B digital information, visit www.P65Warnings.ca.gov device, pursuant to part 15 of the FCC Rules. -
Page 6: Technical Specifications
" 777 mm 28" 711 mm " 953 mm ASP36-AM " 929 mm 34" 864 mm " 1105 mm ASP42-AM " 1082 mm 37" 940 mm " 1181 mm ASP48-AM " 1243 mm 40" 1016 mm " 1258 mm www.dimplex.com... -
Page 7: Package Contents
Read this manual first before attempting to install or use this electric fireplace. Always comply with the warnings and safety instructions contained in this manual to prevent personal injury or property damage. To view the full line of Dimplex products, visit www.dimplex.com INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. -
Page 8: Installation
NOTE: 10" (25 cm) Using normal heat mode, surfaces 10" (25 cm) above the fireplace will not exceed 40° C, as long as installation procedures are followed and heater inlet and outlet are not obstructed. www.dimplex.com... -
Page 9: Install Mounting Brackets
Installation NOTE: Two or more people are required for installation. Use the handles located at the top of the fireplace on the front and back to maneuver the unit. NOTE: If using the accessory for open-sided installation (sold separately), consult the manual included in the accessory kit for modified installation directives. -
Page 10: Connect Power Supply
NOTE: The fireplace is supplied with the power switch in the OFF position. White - Neutral Neutral It is located in the lower right side. Black - L1 Live 240 V Live Yellow - L2 Power supply Green - Ground Ground www.dimplex.com... - Page 11 Installation Place the firebox in the framing and level it 1. Lift the firebox into the opening in the frame using the handles on the back and sides of the fireplace. 2. Using the bubble level, ensure the firebox is level, adjusting as necessary.
- Page 12 (black edge goes at the top). 2. Lift the mirrored glass and place it into the bottom slot at an angle, then tilt the mirrored glass into a vertical position. 3. Align the bracket to two screw holes and secure with screws. www.dimplex.com...
- Page 13 Installation Install the side glass NOTE: The side glass should be installed even on closed-sided installations. 1. Secure the suction cup to the side glass to prevent fingerprints on the outside of the glass. 2. Slide the glass in from the from the front. Once it place it will drop to its final position.
- Page 14 2 and 9 . 4. Place 3 , 8 , and 10 . Aspire 42 & 48: 5. Place 4 . Aspire 36, Aspire 42 & 48: 6. Place 5 and 6 . Aspire 36 Aspire 42 & 48 www.dimplex.com...
- Page 15 The sill trim is secured with magnets. Bracket location Bracket location Place the Dimplex sill trim on the bottom lip of the fireplace, ensuring the bracket on the trim is aligned to the left. Optional step: install the kick plate The kick plate is secured with magnets.
-
Page 16: Finish Installation
Mark the location of the holes. 2. Secure the wall mount using the anchors and screws, as required. 3. Snap on the cover to the wall mount. 4. Place the remote in the wall mount. www.dimplex.com... -
Page 17: Operation
Operation WARNING: This electric firebox must be properly installed before it is used. NOTE: The fireplace will retain the previously used settings after a power interruption. Heater Operation This firebox operates with Comfort$aver technology, which automatically adjusts the fan speed and heater wattage to safely and precisely match the requirements of the room based on the thermostat setting. -
Page 18: Flame Connect App
For additional information, visit www .flame-connect .com To add the fireplace to the Flame Connect app: 1. Press and hold on the onboard controls for 10 seconds until it flashes blue. 2. Follow the instructions in the app to complete the installation. www.dimplex.com... - Page 19 Operation Press to turn on the unit or to put it in standby mode. Standby When the unit is turned back on, it will retain the previously used settings. Press to turn the flame theme and ember bed on or off. Press to cycle through the different flame theme settings, indicated by LEDs on the remote control.
-
Page 20: Maintenance
For this reason the heater must be inspected regularly, depending upon conditions and at a minimum yearly intervals. Servicing Except for installation and cleaning described in this manual, an authorized service representative should perform any other servicing. www.dimplex.com... -
Page 21: Troubleshooting
Troubleshooting For more troubleshooting, consult the Aspire Service Manual which can be found at www.dimplex.com/customer_support/technical_and_troubleshooting Problem Display Cause Solution Some gravel detached from It is normal for some gravel to become Normal occurence media bed detached from the ember bed during transit. -
Page 22: Wiring Diagrams
Wiring Diagrams ASP30-AM ASP36-AM www.dimplex.com... - Page 23 Wiring Diagrams ASP42-AM ASP48-AM...
-
Page 24: Warranty
Warranty • Glen Dimplex Americas will in its sole discretion either ASPIRE™ 5-YEAR LIMITED WARRANTY repair or replace such defective product or part without Section 1 Products to which this Limited Warranty charge. If Glen Dimplex Americas is unable to repair or... - Page 25 For additional information, visit www .flame-connect .com Available in the App Store and Google Play 1-888-346-7539 | www.dimplex.com In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice. © 2024 Glen Dimplex Americas...
