NS-205R
5-Port Industrial 10/100 Mbps Robust Ethernet
Switch
Quick Start Guide
Product Website:
http://www.icpdas-usa.com/ns_205R_ethernet_switch.html

1. Introduction

The NS-205R has 5 Ethernet Switching ports that support 10/100Base-T(X),
with a 10/100M auto-negotiation feature and auto MDI/MDI-X function. It
can connect 5 workstations and automatically switches the transmission
speed (10 Mbps or 100 Mbps) for corresponding connections. The flow
control mechanism is also negotiated. LEDs embedded in RJ-45 jacks
make for easy monitoring. Port connectors are shielded RJ-45. A power
source for +10 ~ +30VDC is required.
Figure 1-1 NS-205R
5-Port Switch
NS-205R
- QuickStart (Jul/2017)
ICP DAS USA, Inc. |
www.icpdas-usa.com
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-205R and is the answer not in the manual?

Questions and answers

Related Manuals for ICP DAS USA NS-205R

Summary of Contents for ICP DAS USA NS-205R

  • Page 1 Product Website: http://www.icpdas-usa.com/ns_205R_ethernet_switch.html 1. Introduction The NS-205R has 5 Ethernet Switching ports that support 10/100Base-T(X), with a 10/100M auto-negotiation feature and auto MDI/MDI-X function. It can connect 5 workstations and automatically switches the transmission speed (10 Mbps or 100 Mbps) for corresponding connections. The flow control mechanism is also negotiated.
  • Page 2 Table 1 shows the LED indicator functions. The module includes an internal. 5-Port Switch NS-205R - QuickStart (Jul/2017) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
  • Page 3 UTP and a crossover UTP cable: 4. Checking Power: Since the NS-205R consumes 2.4W, ensure that your power supply is able to meet this demand. The Input voltage range is +10~+30VDC. External power supply is connected using the removable terminal block as shown below:...
  • Page 4 5-Port Switch NS-205R - QuickStart (Jul/2017) ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717...
