ICP DAS USA NSM-209FCS Quick Start Manual

NSM-209FCS
8-port unmanaged Ethernet with 1 fiber port switch
Quick Start Guide
Product Website:
https://www.icpdas-usa.com/nsm_209fcs.html

1. Introduction

The NSM-209FCS (SC Connector; Single-mode) is a Unmanaged 8-Port Industrial
Ethernet(10/100Base-TX) with Fiber (100Base-FX) Switch that secures data
transmission by using fiber optic transmission to provide immunity from EMI/RFI
interference. It is used Ethernet for transmitting a signal up to 15 Km, and is the perfect
solution for applications where transmission must be protected from electrical exposure,
surges, lightning or chemical corrosion.
The NSM-209FCS operates at full duplex mode. In full duplex mode, range is 15km with
8.3/125, 8.7/125, 9/125 or 10/125 μm fiber cables.
The Ethernet supports 10/ 100M auto-negotiation feature and auto MDI /MDIX function.
NSM-209FCS provides two power inputs that can be connected simultaneously to live
DC power sources. If one of the power inputs fails, the other live source acts as a
backup to automatically support the NSM-209FCS's power needs.
-Port fiber Switch
