Revolution Deep
Draft Lift Manual
9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
PART #: F-702RLNA-DD-04
www.aquacreek.com
US PATENT NUMBER: [D507,769 S]
400 LB. [181 kg] MAXIMUM WEIGHT CAPACITY
FOR INDOOR OR OUTDOOR USE
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
ADA COMPLIANT
READ CAREFULLY
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may aff ect the safety of the user.
1
Copyright © 2020 Aqua Creek Products All Rights Reserved
Revised 6/25/20
Advertisement
Related Manuals for Aqua Creek Revolution Deep F-702RLNA-DD-04
Summary of Contents for Aqua Creek Revolution Deep F-702RLNA-DD-04
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may aff ect the safety of the user. Copyright © 2020 Aqua Creek Products All Rights Reserved...
- Page 2 Supervise children at all times. No jumping or diving from the lift. Seat may be hot, use caution when entering. Keep covered when not in use. Inspect and clean before use. INDOOR BATTERY CHARGER: AMPERAGE = 0.65 FREQUENCY = 60 24 VOLT BATTERY AMPERAGE = 8 IP RATING = IPX5 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 3 1. The Revolution Deep Draft Main Assembly 2. Deep Draft Control Arm 3. Deep Draft Lifting Arm 4. Deep Draft Seat Arm 5. Footrest 6. Actuator 7. Handset 8. 24V Battery Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 4 • Deck slope no greater than 1:48 • The seat must submerge at least 18 inches into the water. The lift should be installed at a location with 42 inches - 48 inches of depth (deck to pool fl oor) • Anchor setbacks are based on straight pool/spa walls. Curved pool/spa walls will eff ect the anchor setback. [187.9cm] 74" [122cm] 48" REQUIRED CLEAR DECK [91.4cm] SPACE 36" [30.5cm] 12" [73.7cm] 29" [40.6cm] 16" WATER POOL WALL FIGURE 1 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 5 Anchor Installation: New Construction or Retro-Fit You may need to saw cut and remove a portion of an existing pool deck in order to achieve the 10 inch depth footing requirement. Aqua Creek does NOT recommend a core drill installation for this lift. To properly install this anchor, you will need to have a concrete footing comprised of 2500 psi concrete that is 10 inches deep and 4 feet - 3 inches square and reinforced with rebar. Refer to Figures A and B below. If cutting into an existing pool deck, the rebar must be drilled and secured to the surrounding pool deck on three sides (do not secure into bond beam).
- Page 6 7. Re-install the lift into the anchor and using the 1/2 inch bolt and washer, carefully thread into the installed anchor until snug. TO PREVENT BREAKING THE FIXING BRACKET, DO NOT OVERTIGHTEN! 1/2" X 2" HEX BOLT 1/2" FLAT MAIN ASSEMBLY WASHER POST ANCHOR DECK STEP 1 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 7 SHOULDER BOLT 3/8" FLAT SHOULDER BOLT WASHER 3/8" NYLOCK NUT CONTROL 5/16" NYLOCK NUT 5/16" FLAT WASHER 3/8" NYLOCK 3/8" X 2" SHOULDER BOLT LIFTING ACTUATOR STEP 3 STEP 2 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 8 In its highest position the seat will clear a 24 inch [609mm] high wall (with the pull-out legrest). STEP 5 3/8" X 2" SHOULDER BOLT 5/16" FLAT WASHER (3) 5/16" NYLOCK NUT (2) 5/16" X 4 1/2" HEX BOLT Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 9 With the lift completely assembled, run the lift fully out and back in 3-5 times, without weight, for the lifts “break in” cycle period. HANDSET CONTROL STEP 6 BATTERY CONTROL FOOTREST ASSEMBLY 1/4" FLAT WASHER 1/4" LOCK WASHER 1/4" X 3/4" THUMB SCREW STEP 7 Not Seated Seated Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 10 Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 11 Pinch Point Locations CAUTION! PINCH POINT AREAS! Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 12 3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts, contact Aqua Creek Products Toll free: (888) 687-3552 Copyright © 2020 Aqua Creek Products All Rights Reserved...
- Page 13 24 VOLT LINAK BATTERY NN 1/4 NUT, 316 SS, NYLOCK, 1/4-20 F-UBC BATTERY/CONTROL BOX COVER BOLT, 18-8 SS, 1/2 X 2 3/4 BS 1/2 X 2 3/4 18-8 SHOULDER, 3/8-16 THREAD Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 6/25/20...
- Page 14 Aqua Creek may void warranty. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. Within thirty (30) days after receipt of a written warranty claim by Aqua Creek, and barring any unforeseen delays, the place of purchase will be notified of Aqua Creek’s decision regarding the claim.
