9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2019 Aqua Creek Products All Rights Reserved
Ambassador Reverse
US PATENT NUMBER: [D507,769 S] [7,249,386 B2]
300 LB. [136 kg] MAXIMUM WEIGHT CAPACITY
Lift safety can only be ensured if the lift is installed and
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
ADA COMPLIANT
READ CAREFULLY
Pool Lift
PART #: F-PPXRD-R-03
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
Read and follow all instructions.
operated according to these instructions.
1
Revised 6/18/19
Advertisement
Related Manuals for Aqua Creek Ambassador
Summary of Contents for Aqua Creek Ambassador
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
-
Page 2: Table Of Contents
2. 24V VITO BATTERY 3. VITO BATTERY CHARGER 4. VITO HANDSET 5. SAFETY BELT 6. VITO BATTERY TEST CABLE 7. ANCHOR JIG PLATE & HARDWARE (IF ORDERED WITH ANCHOR) Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19... - Page 3 12" 62" CHAIR C L 2 " 16" (ADA REQ'D MIN) DECK *NOTE: 22 1/2" IS THE POOL WALL MINIMUM SETBACK. 38" IS THE MAXIMUM FIGURE 1 LIFT SETBACK. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19...
-
Page 4: Anchor Installation: Core-Drill Retro-Fit
NOTE: We recommend using masking tape around the holes on the bottom of the anchor jig plate to help prevent the anchor plate from being accidentally epoxied to the pool deck. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19... - Page 5 OBSTRUCTION) LIFT OUTLINE USE JIG-PLATE (LARGER HOLES) USE JIG-PLATE TO MARK LOCATIONS ASSEMBLY FOR TEST-FITTING AND TO HOLD ANCHORS IN PLACE AS EPOXY CURES FIGURE 3 Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19...
-
Page 6: Anchor Installation: Saw-Cut Retro-Fit
10. Once the concrete has cured, the lift is ready *SETBACK DIMENSIONS ARE FOR FLAT DECK APPLICATIONS. FOR SLOPED DECKS OR OTHER FEATURES, CONTACT AQUA CREEK BEFORE INSTALLATION. to be mounted to the anchoring system. FIGURE 5 Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19... - Page 7 680.26) SEE FIGURE 5, PAGE 6 6. Pour your concrete and fi nish the pool deck surface. 7. Once the concrete has cured the lift is ready to be mounted to the anchoring system. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19...
- Page 8 1. Attach seat belt to the seat. SEE FIGURE 7 FOR EASY ACCESS 2. Install the Ambassador pool lift onto the three (3) anchors using the supplied 1/2 inch x 1 1/2 inches stainless steel hex-head bolts and 1/2 inch stainless steel washers.
- Page 9 Installation Instructions The Aqua Creek legrest assembly is designed to fi t under the chair and is installed inside the 2” square tubing that supports the chair from underneath. To install the legrest; 1. Insert the legrest assembly into the 2 x 2 square tubing that supports the chair until the plastic insert of the legrest assembly sits fl ush against the end of the 2 x 2 tube.
-
Page 10: Basic Troubleshooting
Note: If you feel your lift is malfunctioning due to a faulty battery or connections, contact Aqua Creek Products for a testing kit. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19... -
Page 11: Battery Test Cable Instructions
ONLY FOR CHECKING THE BATTERY VOLTAGE! The Aqua Creek 24V battery has a cable and connector for connecting to the control box or to the battery charger. The battery connector is not suitable to check the battery voltage, as it is very hard to probe the connector without shorting-out the battery, which will cause damage. -
Page 12: Pinch Point Locations
Pinch Point Locations CAUTION! PINCH POINT AREA! Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19... -
Page 13: Proper Care Of Pool & Spa Lifts
3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts, contact Aqua Creek Products Toll free: (888) 687-3552 Copyright © 2019 Aqua Creek Products All Rights Reserved... - Page 14 5/16”-18 F-45ACB-C RESISTANT BOLT, 18-8 SS, 3/8 X 1 BOLT, 316 SS, 1/2” X 1 3/4” BS 3/8 X 1-3/4 18-8 3/4 SHOULDER, 5/16- PPB-CCB-10 FHSCS, CUSTOM 18 THREAD Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 6/18/19...
- Page 15 Aqua Creek may void warranty. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. Within thirty (30) days after receipt of a written warranty claim by Aqua Creek, and barring any unforeseen delays, the place of purchase will be notified of Aqua Creek’s decision regarding the claim.
