INSTALLATION AND OPERATING INSTRUCTIONS
PORTABLE PRO POOL-AT LIFT
US PATENT NUMBERS: [7,249,386 B2] [5,790,995] [D507,769 S]
400 LB. [181 kg] MAXIMUM CAPACITY (PRO POOL LIFT)
MANDATORY – LEAVE THIS MANUAL WITH LIFT OWNER
1.
READ AND FOLLOW ALL INSTRUCTIONS. LIFT SAFETY CAN ONLY BE ENSURED IF THE
LIFT IS INSTALLED AND OPERATED PROPERLY – AS PER THESE INSTRUCTIONS.
2.
WARNING- TO REDUCE RISK OF INJURY, DO NOT PERMIT CHILDREN TO USE THIS
PRODUCT UNLESS THEY ARE CLOSELY SUPERVISED AT ALL TIMES.
3.
WARNING- DO NOT PERMIT CHILDREN TO PLAY ON THIS PRODUCT.
4.
WARNING- NEVER APPLY DIRECT WATER PRESSURE TO ELECTRONIC COMPONENTS.
5.
WARNING - DO NOT USE THE PORTABLE LIFT FOR WATER-DRAFTS OVER 12"
6.
WARNING - NEVER OPERATE THIS LIFT WITH NO WATER (DRY POOL).
7.
WARNING – NEVER OPERATE THIS LIFT WITHOUT THE 14 WEIGHT-PLATES INSTALLED
8.
SAVE A COPY OF THESE INSTRUCTIONS.
AQUA CREEK, LLC 2012
PART #: F-004PPPB-AT1
9889 GARRYMORE LANE
MISSOULA, MT 59808
1-888-687-3552
FAX: 406-549-2602
WARNING
IMPORTANT SAFETY INSTRUCTIONS
TM
DEC 2012
Advertisement
Table of Contents
Related Manuals for Aqua Creek PORTABLE PRO POOL-AT LIFT
Summary of Contents for Aqua Creek PORTABLE PRO POOL-AT LIFT
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS PORTABLE PRO POOL-AT LIFT US PATENT NUMBERS: [7,249,386 B2] [5,790,995] [D507,769 S] 400 LB. [181 kg] MAXIMUM CAPACITY (PRO POOL LIFT) MANDATORY – LEAVE THIS MANUAL WITH LIFT OWNER PART #: F-004PPPB-AT1 9889 GARRYMORE LANE MISSOULA, MT 59808...
-
Page 2: Table Of Contents
PORTABLE PRO POOL-AT LIFT TABLE OF CONTENTS PAGE DESCRIPTION PACKING LIST PORTABLE LIFT: ASSEMBLY INSTRUCTIONS PRO POOL LIFT: ASSEMBLY INSTRUCTIONS 24V BATTERY SYSTEM: OPERATING-INSTALLING BATTERY MAINTENANCE PORTABLE LIFT: OPERATING INSTRUCTIONS 9-11 PRO POOL HEADREST (OPTIONAL) 12-13 CARE OF YOUR LIFT... -
Page 3: Description
PORTABLE PRO POOL LIFT-AT PACKING LIST: (SEE FIGURE 1) 1. PORTABLE MAIN FRAME W/ WHEELS 2. WEIGHT STACK COVER W/ HANDLE 3. WEIGHTS (14) 4. HARDWARE BAG 5. MOUNTING HARDWARE (PORTABLE KIT ONLY) HARDWARE BAG – PORTABLE KIT PART USE / LOCATION ITEM # QTY. -
Page 4: Portable Lift: Assembly Instructions
PORTABLE LIFT - ASSEMBLY INSTRUCTIONS 1. Begin by placing the parts from the previous page at or near to the desired poolside location. 2. Stack 14 supplied round weight plates on the portable platform. To ensure proper alignment stack 3 to 4 plates, check alignment by temporarily putting the cover on, remove the cover and then stack 3 to 4 more plates. -
Page 5: Pro Pool Lift: Assembly Instructions
PRO POOL LIFT - ASSEMBLY INSTRUCTIONS Attach Seat belt to the seat as shown. Plug the handset cable into the large handset socket on the bottom of the control box. Be sure you press the cord end firmly into the socket until you are sure it is all of the way into the socket. - Page 6 24V BATTERY SYSTEM OPERATING AND INSTALLATION INSTRUCTIONS WALL MOUNT CHARGER CONTROL BOX & HANDSET REMOTE 24 V SEALED BATTERY The Pro Pool Lift Battery system comes with a 24v sealed rechargeable battery, wall mount charging unit (with mounting bracket), control box, and a waterproof handheld controller.
-
Page 7: Battery Maintenance
BATTERY MAINTENANCE 1. RECHARGE THE BATTERY AS OFTEN AS POSSIBLE. The battery power unit is a sealed lead acid battery pack. Frequent recharges will prolong the battery life and maintain a high cold amperage capacity. THE BATTERY CAN BE STORED ON THE CHARGER WHEN NOT IN USE. -
Page 8: Portable Lift Operating Instructions
PORTABLE LIFT OPERATING INSTRUCTIONS: NOTE: CHECK ALL NUTS & BOLTS FOR TIGHTNESS AND FOR WORN PARTS BEFORE EACH USE. NEVER OPERATE THE LIFT WITH THE ARMRESTS FLIPPED UP. NEVER OPERATE THE LIFT WITH A WATER-DRAFT OVER 12”, OR IN A DRY POOL. PLACE THE LIFT WITH DECK TO POOL DEPTH OF 44”... - Page 9 THE (OPTIONAL) HEADREST ASSEMBLY The HEADREST ASSEMBLY attaches directly to the chair assembly, and is adjustable for optimum comfort. The components of the HEADREST ASSEMBLY are shown below, along with the chair to show how it attaches. The wing-nuts allow for quick adjustment without having to remove the assembly from the chair.
- Page 10 INSTALLING THE HEADREST PAD The ADJUST BRACKET must be removed from the assembly to install or remove the HEADREST PAD. When installing the pad; thread the bracket through the top loops first and then press the flaps together (hooks & loops fastener) to complete the installation. To remove the pad, reverse this procedure.
- Page 11 ASSEMBLY is now ready to adjust and use. NOTE: The INTEGRATED HEADREST ASSEMBLY will work on all 2 generation 18” wide Aqua Creek Products’ chairs*. The 18” chair comes standard on all Aqua Creek Products’ Scout , Ranger , Pro Pool and Patriot pool lifts.
-
Page 12: Care Of Your Lift
Routine cleaning is an absolute necessity to ensure the integrity of the lift. Note that the Aqua Creek Pool Lift should not be stored in a pump room or in a storage room where pool chemicals are kept. Storing the lift near pool chemicals may cause rusting and other damage to occur. - Page 13 If the lift is used MONTHLY follow the same steps as above. Also check the nuts and bolts to make sure they are securely fastened (this is always a good idea, no matter how often or infrequently the lift is used). Also make sure to store the battery on the charger and not on the lift.
-
Page 14: Troubleshooting Guide
TROUBLESHOOTING GUIDE Before troubleshooting make sure the battery is fully charged. If the lift doesn’t move when the handset button is pressed: When you can’t get the lift to move check the following things: 1. Make sure the battery is fully charged: A. - Page 15 If the battery is fully charged and the lift is not moving then: 2. Check all cords: A. Check that the cords are properly plugged in. Start by unplugging the remote and the actuator cord from the control box. Once these cords are removed check the ends for corrosion or damage.
- Page 16 If the lift stops moving over the water and is stuck: 4. Then try pushing the emergency button: A. If the lift gets stuck out over the water use a pen or pencil tip and stick it into the emergency button on the front of the control box to retract the lift.
- Page 17 PRO POOL LIFT: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 PPB-100-20 PP-AT BASE ASSEMBLY 1 PPF-200-10 PP-AT MAIN FRAME ASSEMBLY 1 A-2012ARM-R1 CHAIR ARM ASSY 1 A-2012SRS-R1 PRO POOL SEAT SUPPORT, REV 1 1 L-2014FBL-PAT R2 PP-AT CONTROL ARM 1 A-8980PPAF-AT2 PRO POOL-AT ACTUATOR ASSY, R1 1 SA-0904CA-A...
-
Page 18: Seat Assembly Parts List
SEAT ASSEMBLY: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 P-901 CHAIR, BLUE ROTOMOLDED (18" WIDE) 2 P-2100FLA-A ARMREST TUBE 1 P-1208HSB HANDSET BRACKET, HDPE 2 RUBBER HAND GRIPS RUBBER HAND GRIPS, BLACK 2 SCREW, #12 X3/4 FHSMS #12 X3/4" FLAT-HD SHEET-METAL SCR SS 4 FLAT WASHER, 1/4 SS 1/4"... - Page 19 AT-PORTABLE BASE ASSEMBLY ITEM # PART NUMBER DESCRIPTION SA-0904PPPF-AT PORTABLE-AT MAIN FRAME ASSEMBLY SA-004PPPH PORTABLE HOOD ASSEMBLY 5.00008.451 8" RUBBER WHEEL, DELRIN BEARING LOCK COLLARS 3/4" SS 3/4" LOCK COLLAR, S.S. 2NF100SA 4" SWIVEL CASTER, S.S. WPS-50 50LB WEIGHT PLATE, IRON P-0909PCA CASTER ADAPTER ASSEMBLY NYLOCK, 1/4 SS...
- Page 20 EXCEED THE RATED LIFTING CAPACITY OF 400 POUNDS [181 kg] FOR THE PRO POOL PORTABLE. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect.
