Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2017 Aqua Creek Products All Rights Reserved
600 LB. [272 kg] MAXIMUM WEIGHT CAPACITY
LEAVE THIS MANUAL WITH LIFT OWNER
Lift safety can only be ensured if installed and operated
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
ADA COMPLIANT
READ CAREFULLY
Titan Lift
Manual
PART #: F-600TLNA
US PATENT NUMBER: [D507,769 S]
MANDATORY
Read and follow all instructions.
according to these instructions.
1
Revised 4/14/17
Advertisement
Table of Contents
Related Manuals for Aqua Creek F-600TLNA
Summary of Contents for Aqua Creek F-600TLNA
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
-
Page 2: Table Of Contents
Titan Assembly Instructions Warranty Titan Components 1. The Titan Main Assembly 2. Control Arm 3. Lifting Arm 4. Seat Arm 5. Footrest 6. Actuator 7. Handset 8. 24V Battery Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 3: Ada Installation Guidelines
Anchor setbacks are based on straight pool/spa walls. Curved pool/spa walls will effect the anchor setback. [122cm] 48" REQUIRED CLEAR DECK [91.4cm] SPACE 36" [30.5cm] 12" [73.7cm] 29" [40.6cm] 16" WATER POOL WALL FIGURE 1 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 4: Anchor Installation: New Construction
You may need to saw cut and remove a portion of an existing pool deck in order to achieve the 11 inch depth footing requirement. Aqua Creek does NOT recommend a core drill installation for this lift. To properly install this anchor, you will need to have a concrete footing comprised of 2500 psi concrete that is 11 inches deep and 4 feet - 4 inches square and reinforced with rebar. -
Page 5: Ada Fixing Insert Installation
TO PREVENT BREAKING THE FIXING BRACKET, DO NOT OVERTIGHTEN! 1/2" X 2" HEX BOLT TITAN 600 1/2" FLAT MAIN ASSEMBLY WASHER LOCKING-PIN POST LOCKING-PIN SLOT DECK FIXING ANCHOR STEP 1 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 6: Titan Assembly Instructions
1/2" X 3" WASHER SHOULDER BOLT 3/8" FLAT 5/16" NYLOCK NUT WASHER CONTROL 5/16" FLAT WASHER 3/8" NYLOCK 3/8" X 2" SHOULDER 3/8" NYLOCK BOLT LIFTING ACTUATOR STEP 2 STEP 3 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 7: Lifting Arm
26 inch [660mm] high wall (with the pull-out legrest). STEP 5 3/8" X 2" SHOULDER BOLT 5/16" FLAT WASHER (3) 5/16" NYLOCK NUT (2) 5/16" X 4 1/2" HEX BOLT Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 8: Footrest
NOT PROPERLY ALIGNED. FOOTREST TUBE. HANDSET CONTROL STEP 6 BATTERY SEAT ASSEMBLY CONTROL QUICK RELEASE FOOTREST TUBE (ADJUSTABLE) STEP 7 Not Seated Seated Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 9: Battery
Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 10: Proper Care Of Pool & Spa Lifts
3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts contact Aqua Creek direct at Toll free: (888) 687-3552 Copyright © 2017 Aqua Creek Products All Rights Reserved... -
Page 11: Titan Parts List
NN 1/4 NUT, 316 SS, NYLOCK, 5/16-18 F-BCC-11 CONTROL BOX/BATTERY COVER WF 5/16 WASHER, FLAT, 5/16, 316 SS BOLT, 316 SS, 5/16-18 X 4 1/2 BH 5/16 X 4 1/2 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 12: Chair & Footrest Parts List
CAP, PLASTIC, 1”X1” SQUARE BB 1/4 X 3 BOLT, 316 SS, 1/4-20 X 3 BHSCS WF 1/4 WASHER, FLAT, 1/4, 316 SS NN 1/4 NUT, 316 SS, NYLOCK, 1/4”-20 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 4/14/17... -
Page 13: Warranty
Non-payment for product to Aqua Creek may void warranty. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. - Page 14 ROTATIONAL LIFT ACCESSORIES COVERS ACCESSORIES & OPTIONS F-450BL-C Scout 2 Lockable Cover F-019CA Cycle Attachment F-450SSC Scout 2 Cover F-105LAR Pull-Out Legrest (use with Solar Charger) F-422PLH-2 Headrest F-720BL-C Revolution/Titan Lockable Cover F-423CS Chest Strap F-720SSC Revolution/Titan Cover F-38SB Seat Belt, Standard (use with Solar Charger) F-806SLS Sling Seat Assembly, Scout 2...
