Aqua Creek Patriot-AT F-12PPL-HD-AT2 Installation And Operating Instructions Manual

Portable pool lift
Hide thumbs

Advertisement

Quick Links

INSTALLATION AND OPERATING INSTRUCTIONS
PATRIOT-AT
PART NUMBER: F-12PPL-HD-AT2
U.S. PATENT NUMBERS: [7,249,386 B2] [5,790,995] [D507,769 S]
450 LB. [204 kg] MAXIMUM CAPACITY (PRO POOL LIFT)
MANDATORY – LEAVE THIS MANUAL WITH LIFT OWNER
9889 GARRYMORE LANE
MISSOULA, MT 59808
1-888-687-3552
FAX: 406-549-2602
1.
READ AND FOLLOW ALL INSTRUCTIONS. LIFT SAFETY CAN ONLY BE ENSURED IF THE
LIFT IS INSTALLED AND OPERATED PROPERLY – AS PER INSTRUCTIONS.
2.
WARNING- TO REDUCE RISK OF INJURY, DO NOT PERMIT CHILDREN TO USE THIS
PRODUCT UNLESS THEY ARE CLOSELY SUPERVISED AT ALL TIMES.
3.
WARNING- DO NOT PERMIT CHILDREN TO PLAY ON THIS PRODUCT.
4.
WARNING- NEVER APPLY DIRECT WATER PRESSURE TO ELECTRONIC COMPONENTS.
5.
WARNING – DO NOT OPERATE THIS LIFT IF THE DECK-TO-WATER DISTANCE IS OVER 12".
6.
WARNING – DO NOT OPERATE THIS LIFT UNDER LOAD IN A DRY POOL (NO WATER).
7.
WARNING – DO NOT OPERATE THIS LIFT WITHOUT THE 10 WEIGHT-PLATES INSTALLED.
8.
WARNING – FOR SAFETY REASONS YOU SHOULD NEVER SWIM ALONE!
9.
SAVE A COPY OF THESE INSTRUCTIONS.
©AQUA CREEK PRODUCTS, 2012
TM
PORTABLE LIFT
WARNING
IMPORTANT SAFETY INSTRUCTIONS
DEC 2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the Patriot-AT F-12PPL-HD-AT2 and is the answer not in the manual?

Questions and answers

Related Manuals for Aqua Creek Patriot-AT F-12PPL-HD-AT2

Summary of Contents for Aqua Creek Patriot-AT F-12PPL-HD-AT2

  • Page 1 WARNING – DO NOT OPERATE THIS LIFT UNDER LOAD IN A DRY POOL (NO WATER). WARNING – DO NOT OPERATE THIS LIFT WITHOUT THE 10 WEIGHT-PLATES INSTALLED. WARNING – FOR SAFETY REASONS YOU SHOULD NEVER SWIM ALONE! SAVE A COPY OF THESE INSTRUCTIONS. ©AQUA CREEK PRODUCTS, 2012 DEC 2012...

  • Page 2: Table Of Contents

    PATRIOT-AT PORTABLE LIFT TABLE OF CONTENTS PAGE DESCRIPTION ADA INSTALLATION GUIDELINES PATRIOT-AT PORTABLE PACKING LIST PATRIOT-AT PORTABLE ASSEMBLY INSTRUCTIONS FIXING-ANCHOR INSTALLATION INSTRUCTIONS INSTALLING THE FIXING BOLT TRANSPORTING & USING THE PATRIOT-AT PORTABLE 24V BATTERY OP & INSTALL INSTRUCTIONS BATTERY MAINTENANCE PRO POOL-AT LIFT OPERATING INSTRUCTIONS CARE OF YOUR LIFT...
  • Page 3 INSTALLATION: ADA GUIDELINES ADA REQUIREMENTS: The PATRIOT-AT portable lift is designed and manufactured to be 100% ADA compliant. But for the installed lift to be 100% compliant the installation must meet the requirement for CLEAR DECK SPACE as shown in the diagram to the left. To be compliant, install the lift at 16 inches [406mm] minimum from the pool edge to the centerline of the seat, and make sure the deck has the required CLEAR DECK SPACE as shown.
  • Page 4 THE PATRIOT-AT PORTABLE LIFT WARNING 1. NEVER OPERATE THIS LIFT IF THE POOL DECK TO WATER LEVEL EXCEEDS 9” 2. BEFORE OPERATING THE LIFT THE CONCRETE WEIGHTS MUST BE INSTALLED AS PER THESE INSTRUCTIONS. (SEE PAGE 5). 3. IMMEDIATELY PUT THE BATTERY ON THE CHARGER AND CHARGE THE 24V BATTERY FOR 24 HOURS BEFORE INITIAL USE.
  • Page 5 PATRIOT-AT2 ASSEMBLY INSTRUCTIONS 1. Begin by placing the parts from the previous page at or near to the desired poolside location. 2. Stack 10 supplied weight plates on the portable platform. To ensure proper alignment stack 3 to 4 plates, check alignment by temporarily putting the cover on, remove the cover and then stack 3 to 4 more plates.

  • Page 6: Fixing-Anchor Installation Instructions

    FIXING-ANCHOR INSTALLATION INSTRUCTIONS: TOOLS REQUIRED: CORE-DRILLING RIG TAPE MEASURE 1-1/4” DIAMETER CORE-DRILL MARKING PEN STEP 1] Use the diagram below to determine the location of the FIXING ANCHOR. Make sure to allow for the clear deck space as shown. STEP 2] Mark the location for the 1-1/4” x 4” deep anchor hole. Drill a 1-1/4” diameter, 4”...

  • Page 7: Installing The Fixing Bolt

    INSTALLING THE FIXING BOLT: When the FIXING-BOLT is utilized to ensure proper placement of the portable lift the following procedure should be used when placing the unit in position on the deck. STEP 1: Roll the portable cart over the installed anchor. Look straight down through the FIXING BAR to align the anchor with the FIXING BAR.
  • Page 8 TRANSPORTING & USING THE PATRIOT-AT LIFT: The Patriot-AT Lift has been designed to make transporting and using the lift as simple as possible. The design makes the lift 100% ADA compliant by providing two separate operating modes; one for transporting the lift and one for using it. DO NOT ATTEMPT TO USE THE LIFT WHILE IN THE TRANSPORT MODE! MODES OF OPERATION: 1] TRANSPORT MODE: In this mode the lift is on top of the portable cart and the...
  • Page 9 RETURNING THE LIFT TO TRANSPORT MODE: To move the lift after use, reverse the steps above as follows: 1) Tilt the lift back and down until the lower wheels are at the cart level. 2) Roll the lift back and onto the cart. Roll all the way back to the end of the guide frames (see close-up detail).
  • Page 10 24V BATTERY SYSTEM OPERATING AND INSTALLATION INSTRUCTIONS WALL MOUNT CHARGER CONTROL BOX 24V SEALED BATTERY & HANDSET REMOTE The Patriot-AT Lift comes with a 24v sealed rechargeable battery, wall mount charging unit (with mounting bracket), control box, and a waterproof handheld controller. The control box is mounted to the Patriot-AT Lift has a plug-in socket for both the...

  • Page 11: Battery Maintenance

    BATTERY MAINTENANCE 1. RECHARGE THE BATTERY AS OFTEN AS POSSIBLE. The battery power unit is a sealed lead acid battery pack. Frequent recharges will prolong the battery life and maintain a high cold amperage capacity. 2. Do NOT expose the battery to freezing temperatures. 3.
  • Page 12 PRO POOL LIFT OPERATING INSTRUCTIONS: NOTE: CHECK ALL NUTS & BOLTS FOR TIGHTNESS AND FOR WORN PARTS BEFORE EACH USE. NEVER OPERATE THE LIFT WITH THE ARMRESTS FLIPPED UP. WARNING! FOR SAFETY REASONS YOU SHOULD NEVER SWIM ALONE! The Pro Pool Lift should always be in the full up or deck position before a user attempts to transfer into the chair.

  • Page 13: Care Of Your Lift

    CREEK PRODUCTS LLC. 1-888-687-3552. CARE OF YOUR LIFT Aqua Creek Pool Lift should not be stored in a pump room or in a storage room where pool chemicals are kept. Storing the lift near pool chemicals may cause rusting and other damage to occur.
  • Page 14 If the lift is used MONTHLY follow the same steps as above. Also check the nuts and bolts to make sure they are securely fastened (this is always a good idea, no matter how often or infrequently the lift is used). Also make sure to store the battery on the charger and not on the lift.
  • Page 15 TROUBLESHOOTING GUIDE Before troubleshooting make sure the battery is fully charged. If the lift doesn’t move when the handset button is pressed: When you can’t get the lift to move check the following things: 1. Make sure the battery is fully charged: A.
  • Page 16 If the battery is fully charged and the lift is not moving then: 2. Check all cords: A. Check that the cords are properly plugged in. Start by unplugging the remote and the actuator cord from the control box. Once these cords are removed check the ends for corrosion or damage.
  • Page 17 If the lift stops moving over the water and is stuck: 4. Then try pushing the emergency button: A. If the lift gets stuck out over the water use a pen or pencil tip and stick it into the emergency button on the front of the control box to retract the lift.
  • Page 18 PATRIOT-AT2 INTEGRATED LIFT: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 RAT-200-20 REBEL-AT ROLL-BASE ASSY 1 PPF-200-10 RANGER-AT FRAME ASSY 1 A-2012ARM-R1 PORTABLE CHAIR ARM ASSY 1 A-2012SRS-R1 PRO POOL SEAT SUPPORT 1 L-2014FBL-PAT-R2 RANGER-AT CONTROL ARM 1 A-8980PPAF-AT2 PRO POOL-AT ACTUATOR FRAME 1 SA-0904CA-A 18"...

  • Page 19: Seat Assembly: Parts List

    SEAT ASSEMBLY: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 P-901 CHAIR, BLUE ROTOMOLDED (18" WIDE) 2 P-2100FLA-A ARMREST TUBE 1 P-1208HSB HANDSET BRACKET, HDPE 2 RUBBER HAND GRIPS RUBBER HAND GRIPS, BLACK 2 SCREW, #12 X3/4 FHSMS #12 X3/4" FLAT-HD SHEET-METAL SCR SS 4 FLAT WASHER, 1/4 SS 1/4"...
  • Page 20 PATRIOT-AT2 PORTABLE CART: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 RAT-110-00 AT CART TRAY 1 RATWM-120-00 AT CART WELDMENT A 1 RATWM-130-00 AT CART WELDMENT B, 2-ANC 1 P-0138PBP-REVA2 PORTABLE CART BASEPLATE 2 P-0138PCPS-REVB PORATBLE CART PLASTIC SLIDE 1 P-0138PCPG-REVB PORTABLE CART SIDE GUARD, PLASTIC 2 A-0138GFA-REVC...

  • Page 21: Warranty

    LIFT. NEVER OPERATE THE LIFT UNDER LOAD IN A DRY POOL (WITH NO WATER IN THE POOL). To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect.
