9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2017 Aqua Creek Products All Rights Reserved
US PATENT NUMBER: [D507,769 S] [7,249,386 B2]
450 LB. [204 kg] MAXIMUM WEIGHT CAPACITY
LEAVE THIS MANUAL WITH LIFT OWNER
Lift safety can only be ensured if the lift is installed and
operated according to these instructions.
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
ADA COMPLIANT
READ CAREFULLY
Pro Pool-AT
Pool Lift
PART #: F-004PLBNA-AT1
MANDATORY
Read and follow all instructions.
1
Revised 1/5/17
Advertisement
Table of Contents
Related Manuals for Aqua Creek Pro Pool-AT
Summary of Contents for Aqua Creek Pro Pool-AT
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
-
Page 2: Table Of Contents
5. SAFETY BELT 6. ANCHOR JIG PLATE (IF ORDERED WITH ANCHOR) 7. ANCHOR INSERT BAG - SET OF 4 (IF ORDERED WITH ANCHOR) 8. HARDWARE BAG (IF ORDERED WITH ANCHOR) Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17... - Page 3 THE MINIMUM 14.5" SETBACK. WHEN SETBACK 16" 19" THE CD-SPACE **14.5" STARTS 34" FROM THE POOL WALL. (SETBACK + 15") **NOTE: THE MAXIMUM POOL WALL SETBACK IS 19" FIGURE 1 Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17...
-
Page 4: Anchor Installation: Core-Drill Retro-Fit
You may need to saw cut a portion of your deck. See “Saw Cutting Retro-Fit Instructions” on page 6. Remove the nuts and the black protective coverings from the threaded anchor inserts. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17... - Page 5 Once the epoxy has set up, remove the hardware and the anchor jig plate. Your lift is now ready to be mounted to the anchoring system. The anchor jig plate may be recycled or used to install other anchors. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17...
-
Page 6: Anchor Installation: Saw-Cut Retro-Fit
9. Pour concrete and fi nish the pool deck surface. SEE FIGURE A 10. Once the concrete has cured, the lift is ready to be mounted to the anchoring system. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17... - Page 7 SLAB (4" MIN EMBED) system. *SETBACK DIMENSIONS ARE FOR FLAT DECK APPLICATIONS. FOR SLOPED DECKS OR OTHER FEATURES, CONTACT AQUA CREEK BEFORE INSTALLATION. FIGURE C Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17...
-
Page 8: Pro Pool-At Lift Assembly Instructions
1. Attach seat belt to the seat. SEE FIGURE D FOR EASY ACCESS 2. Install the Pro Pool-AT pool lift onto the four (4) anchors using the supplied 1/2 inch x 1 1/2 inches stainless steel hex-head bolts and 1/2 inch stainless steel flat washers. -
Page 9: Basic Troubleshooting
Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17... -
Page 10: Proper Care Of Pool & Spa Lifts
3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts contact Aqua Creek direct at Toll free: (888) 687-3552 Copyright © 2017 Aqua Creek Products All Rights Reserved... -
Page 11: Pro Pool-At Parts List
316 SS NUT, 316 SS, NYLOCK, NN 5/16 COVER, ACTUATOR, WATER 5/16”-18 F-45ACB-C RESISTANT BOLT, 18-8 SS, 3/8 X 1 BS 3/8 X 1-3/4 18-8 3/4 SHOULDER, 5/16- 18 THREAD Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17... - Page 12 M5 LPCS CONTROL BOX SCREW BAJ1-U022-00 24 VOLT LINAK BATTERY 340643-00 LA-34 LINAK ACTUATOR BH 3/8 X 1 3/4 3/8 X 1 3/4 HEX BOLT NN 3/8 3/8-16 NYLOCK NUT Copyright © 2017 Aqua Creek Products All Rights Reserved Revised 1/5/17...
-
Page 13: Warranty
Non-payment for product to Aqua Creek may void warranty. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. - Page 14 Pro Pool, Ranger, Ambassador, Patriot, Portable Pro Pool F-043SCH Patriot F-120PPC Ranger/Pro Pool Ambassador/Patriot F-044SCH Ranger/Pro Pool/ Portable Pro Pool Ambassador F-914STC Ambassador F-40220-AT1 Wood Deck (Pro Pool/Ranger Only) F-004PLBAP Ranger/Pro Pool + Transport Cart F-004PLBAPV Ranger Lift w/ Vito Controls F-920SAP Ambassador + Transport Cart F-12PPAP...
