9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2016 Aqua Creek Products All Rights Reserved
24V Solar Charger
Lift safety can only be ensured if the lift is installed and
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER apply direct water pressure to the electronics
• NEVER use the lift with a dry pool
READ CAREFULLY
Instructions
PART #: F-043SCH
(Patriot Solar Charger Kit)
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
Read and follow all instructions.
operated according to these instructions.
1
Revised 12/13/16
Advertisement
Related Manuals for Aqua Creek F-043SCH
Summary of Contents for Aqua Creek F-043SCH
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
- Page 2 Patriot pool lift as shown on page 4. The solar charger comes partially assembled. Before mounting the solar charger to the Patriot lift, you will need to assemble the solar charger as shown on the next page. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
-
Page 3: Unpacking And Assembly
Install the 2nd fl at washer and the Nylock nut on the opposite side, and tighten until snug. The Solar Charger is now ready to install on your pool lift. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16... - Page 4 STEP 4: Run the BATTERY CABLE behind the main frame and up the ACTUATOR FRAME. The CONNECTOR is on the CONTROL BOX (see INSTALLING THE CHARGE CONNECTOR). Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 5 The Charge Connector”. NOTE: Removing the plastic disk voids the warranty of the control box! A new solar charger ready control box can be purchased, if you do not wish to void your control box warranty. Contact Aqua Creek for additional information.
- Page 6 REMOVE THE COVER AND PLACE ON TABLE RIGHT-SIDE UP: NOTE POSITION OF EMERGENCY-SWITCH CAP USE A “TORX” T10 DRIVER TO REMOVE THE THREE (3) SCREWS FROM THE CONTROL BOARD Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 7 Control Box Modification Instructions REMOVE THE CONTROL BOARD FROM THE CONTROL BOX USE SCREWDRIVER, AND MALLET IF NECESSARY, TO PUNCH-OUT AND REMOVE PLASTIC-DISC ON 24V INPUT/OUTPUT PORT Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 8 PLACE THE CONTROL BOARD BACK IN PLACE INSIDE THE CONTROL BOX RETURN THE THREE (3) SCREWS TO SECURE REPLACE THE EMERGENCY-SWITCH CAP WITH THE CONTROL BOARD BACK IN PLACE “ARROW” POINTING DOWN AS SHOWN Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 9 Control Box Modification Instructions PUT COVER ON AND REINSTALL SCREWS TEST EMERGENCY-SWITCH WITH DRIVER, LISTEN FOR “CLICK” Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 10 NOTE: The BATTERY CABLE must be run along the main frame as shown so it follows the lift as it goes down into the water. Run the lift up and down to make sure the cable has been installed properly. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 11 The 24V Solar Charger will continue to charge the battery, even as the lift is being used. So once the 24V Solar Charger has been installed it will function without any need for adjustment. The user should check the indicators periodically to make sure it is working. Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
-
Page 12: Battery Maintenance
Do NOT expose the battery to long periods of direct sunlight. Heat will shorten your battery life. Optimum operating temperature is below 20 degrees Celsius (68 degrees F.) Aqua Creek recommends a battery cover be used with solar chargers since the battery is left on the lift at all times. - Page 13 GROMMET, CHARGER, 5/16 ID X 1/2 PAT-PMB-00 SOLAR CHARGER MOUNTING BRACKET P-TPTR12 THREAD PROTECTOR, 1/2” OD X 2” 450 DEGR SILICON, BLISTER PACKET, 450 DEGREE ANTI SIEZE, PACKET, .75 ANTI SIEZE, PACKET, 5 GRAMS Copyright © 2016 Aqua Creek Products All Rights Reserved Revised 12/13/16...
- Page 14 Aqua Creek, all warranties are void. To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect.
