Table 15 Chargers On And Current Settings; Table 16 Charge Currents For Calculations - Alpha OutBack Power Radian Series Operator's Manual

Specifications
To calculate the chargers and settings:
Look up the values for A, B, and C.
1.
A = the battery bank's maximum charge current
(in Adc) from the battery manufacturer.
B = the maximum DC output of the appropriate inverter
model. This is taken from Table 16.
C = the maximum AC input of the appropriate inverter
model. This is taken from Table 16.
Select a value for D to be used in the following
2.
calculation.
D = the Charger AC Limit setting. This value must be
12 or higher. (See page 61.) A higher value uses fewer
chargers and turns off all others. A lower value, or 12,
leaves more chargers on.
3.
Perform the following calculation.
A
(C) ÷ D = E
B
E = the number of chargers to use. This number
should be rounded down in all cases.
4.
Adjust the master inverter's Charger AC Limit setting
to equal D.
Turn off the chargers for all inverters that exceed E.
5.
In a system stacked on the HUB communications
manager, chargers on higher-numbered ports
should be turned off first. Chargers should be
turned off by setting the Charger Control menu item
to Off. (See the menu tables beginning on page 63 to
locate this command in the menu structure.)
Table 16
Model Maximum DC Output (sent to battery)
GS4048A 57.5 Adc
GS8048A 115 Adc
62
Charge Currents for Calculations
Maximum AC Input (used from source)
15 Aac
30 Aac
Table 15 Chargers On
and Current Settings
Max GS4048A
Charge
Aac On Set Aac On Set
Adc
40 10 1 10
60 15 1 15
80 20 1 15
100 26 2 12
120 31 2 15
140 36 3 12
160 41 3 13
180 47 3 15
200 52 4 13
220 57 4 14
240 62 4 15
260 67 5 13
280 73 5 14
300 78 5 15
335 87 6 14
370 96 6 15
400 104 7 14
435 113 8 14
470 122 8 15
500 130 9 14
535 139 9 15
570 148 10 14
600 156 10 15
640 --- --- ---
680 --- --- ---
720 --- --- ---
760 --- --- ---
800 --- --- ---
840 --- --- ---
880 --- --- ---
920 --- --- ---
960 --- --- ---
1000 --- --- ---
1050 --- --- ---
1100 --- --- ---
1150 --- --- ---
GS8048A
10 1 10
15 1 15
20 1 20
26 1 26
31 1 30
36 2 18
41 2 20
47 2 23
52 2 26
57 2 28
62 2 30
67 3 22
73 3 24
78 3 26
87 3 29
96 4 24
104 4 26
113 4 28
122 4 30
130 5 26
139 5 27
148 5 29
156 6 26
167 6 27
177 6 29
187 7 26
198 7 28
208 7 29
219 8 27
229 8 28
240 8 30
250 9 27
260 9 28
273 9 30
287 10 28
300 10 30
