Electrical Specifications

NOTE
: Items qualified with "default" can be manually changed using the system display.
Table 12
Specification
Continuous Output Power at 25°C
Continuous AC Output Current at 25°C
AC Output Voltage (default)
AC Output Frequency (default)
AC Output Type
AC Waveform
Typical Efficiency
CEC Weighted Efficiency
Total Harmonic Distortion (maximum)
Harmonic Distortion (maximum single voltage)
AC Output Voltage Regulation
Appliance Protective Class (IEC)
Power Factor
Inrush Current
AC Maximum Output Current (1 ms peak)
AC Maximum Output Current (100 ms RMS)
AC Overload Capability (100 ms surge)
AC Overload Capability (5 second)
AC Overload Capability (30 minute)
AC Maximum Output Fault Current and Duration
Power Consumption (idle) – Invert mode, no load
Power Consumption (idle) – Search mode
Power Consumption – Off
AC Input Voltage Range
AC Input Frequency Range
AC Input Current (maximum continuous)
Grid-Interactive Voltage Range (default)
Grid-Interactive Frequency Range (default)
DC Input Voltage (nominal)
DC Input Voltage Range
900-0161-01-01 Rev B
Electrical Specifications for Radian Models
GS8048A
8000 VA
33.3 Aac
120/240 Vac
60 Hz
Split-phase
True Sinewave
93%
92.5%
< 5%
< 2%
± 2%
Class I
–1 to 1
None
100 Aac @240 Vac
70.7 Aac @240 Vac
16.97 kVA
12.0 kVA
9.0 kVA
109 Aac for 0.364
seconds
34 watts
10 watts
4 watts
(L1 or L2) 85 to 140 Vac
54 to 66 Hz (60-Hz setting)
45 to 55 Hz (50-Hz setting)
50 Aac
(L1 or L2) 106 to 132 Vac
59.3 to 60.5 Hz
48 Vdc
40 to 64 Vdc

Specifications

GS4048A
4000 VA
16.7 Aac
120/240 Vac
60 Hz
Split-phase
True Sinewave
93%
92.5%
< 5%
< 2%
± 2%
Class I
–1 to 1
None
50 Aac @240 Vac
35.35 Aac @240 Vac
8.48 kVA
6.0 kVA
4.5 kVA
54.5 Aac for 0.364
seconds
34 watts
10 watts
4 watts
(L1 or L2) 85 to 140 Vac
54 to 66 Hz (60-Hz setting)
45 to 55 Hz (50-Hz setting)
50 Aac
(L1 or L2) 106 to 132 Vac
59.3 to 60.5 Hz
48 Vdc
40 to 64 Vdc
57
