Specifications
Table 12
Specification
DC Maximum Input Voltage
DC Input Power (continuous)
DC Input Max. Current (continuous full power)
DC Input Maximum Current (surge)
DC Input Maximum Current (short-circuit)
Battery Charger Maximum AC Input
Battery Charger Maximum DC Output
DC Output Voltage Range (charging)
Auxiliary Output
Auxiliary Relay

Mechanical Specifications

Table 13
Specification
Inverter Dimensions (H x W x D)
Shipping Dimensions (H x W x L)
Inverter Weight
Shipping Weight
Accessory Ports
Non-volatile Memory
Neutral-Ground Bond Switching
Chassis Type
58
Electrical Specifications for Radian Models
GS8048A
68 Vdc
9.5 kVA
200 Adc
424.2 Adc
8975 Adc
30 Aac at 240 Vac
115 Adc
44 to 68 Vdc
0.7 Adc at 12 Vdc
10 A at 250 Vac or 30 Vdc
Mechanical Specifications for Radian Models
GS8048A
28 x 16 x 8.75"
(71.1 x 40.6 x 22.2 cm)
14.5 x 21 x 34.5"
(36.8 x 53.3 x 87.6 cm)
125 lb (56.8 kg)
140 lb (63.5 kg)
RJ11 (batt temp) and
RJ45 (remote)
Yes
No
Vented
GS4048A
68 Vdc
4.8 kVA
100 Adc
212.1 Adc
4488 Adc
15 Aac at 240 Vac
57.5 Adc
44 to 68 Vdc
0.7 Adc at 12 Vdc
10 A at 250 Vac or 30 Vdc
GS4048A
28 x 16 x 8.75"
(71.1 x 40.6 x 22.2 cm)
14.5 x 21 x 34.5"
(36.8 x 53.3 x 87.6 cm)
82 lb (37.2 kg)
89 lb (40.3 kg)
RJ11 (batt temp) and
RJ45 (remote)
Yes
No
Vented
900-0161-01-01 Rev B
