DO NOT
use or place the transceiver in areas with tem-
peratures below -30°C or above +60°C or, in areas subject
to direct sunlight, such as the dashboard.
AVOID
operate the transceiver without running the vehicle's
engine. The vehicle's battery will quickly run out if the trans-
ceiver is in transmission while the vehicle's engine OFF.
AVOID
placing the transceiver in excessively dusty envi-
ronments.
AVOID
placing the transceiver against walls. This will ob-
struct heat dissipation.
AVOID
the use of chemical agents such as benzine or al-
cohol when cleaning, as they damage the transceiver sur-
faces.
BE CAREFUL!
The transceiver will become hot when
operating continuously for long periods.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not ex-
pressly approved by Icom Inc., could void your authority to operate
this transceiver under FCC regulations.

TABLE OF CONTENTS

IMPORTANT ........................................................................ i
EXPLICIT DEFINITIONS ..................................................... i
CAUTIONS ........................................................................... i
TABLE OF CONTENTS ...................................................... ii
1 PANEL DESCRIPTION ............................................. 1-5
Front panel ............................................................................ 1
Function display .................................................................... 2
Programmable function keys ................................................ 3
2 OPERATION ............................................................. 6-8
Turning power ON ................................................................. 6
Channel selection ................................................................. 6
Receiving and transmitting ................................................... 7
D Transmitting notes .......................................................... 7
D Tx code channel selection .............................................. 8
D Tx code number selection .............................................. 8
D DTMF transmission ........................................................ 8
3 CONNECTION AND MAINTENANCE .................... 9-12
Rear panel and connection ................................................... 9
Unpacking ........................................................................... 10
Mounting the transceiver...................................................... 11
Optional UT-96/UT-105 installation ..................................... 11
Optional OPC-617 installation ............................................. 12
Antenna ............................................................................... 12
Fuse replacement ............................................................... 12
Cleaning ............................................................................. 12
4 OPTIONAL SmarTrunk II™ OPERATION ........... 13-15
SmarTrunk II™ and conventional modes ............................ 13
SmarTrunk II™ operation .................................................... 13
5 OPTIONS .................................................................... 16
ii
