Courtyard Creations TGS18LA-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
TGS18LA-CS01
2
TGS18LA-CS02
3
62TGS18LAI101

Step 1:

Place the table top (#1) onto a non-abrasive
surface, such as a carpet, with its underside
facing upwards. Fasten the legs (#2) to the
table top (#1) by using bolts (#4) and washers
(#5). keep the bolts loose. See Figure 1.
!
Do not sit or stand on this table.
!
Do not discard any of the packaging until you have checked that you have all the parts and pack
of fittings.
!
Keep children away during assembly. This item contains small parts which can be swallowed by
children. Children should always be under direct adult supervision while using the product.
!
Retain the assembly instructions for future reference.
!
Please quote following FQC NO. when contacting service center.
INTENDED FOR RESIDENTIAL USE ONLY.
TGS18LA
PART Q'TY
TABLE TOP
LEG
SUPPORT
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
-WM
4
17C33A0703001Y4
1 5
17FA05040301-Y4
2 6
1800337004
2 7
17KAA0101----Y4
FIGURE 1
6
4
5
BOLT M6*12
WASHER d6.5*D13*1.0
BOLT CAP
HEX.KEY WRENCH 4MM
6
2
4
5
1
