Courtyard Creations TGS64SW-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
TGS64SW-CS01
2
TGS64SW-CS02
TGS64SW-CS03
3
4
62TGS64SWY101
17C17A0403001Y4
5
You will need the following tools:
- Phillips Screwdriver (Not Included)
- Hex. Key Wrench (See Part #11)
Attention:
Make sure that each bolt needed for all steps match the
corresponding figure to ensure proper assembly.

Step 1:

Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Insert the legs (#2) and supports (#3) into the plastic
holders on the table top (#1) rim. Fasten them together
by using screws (#5). See Figure 1.
!
Do not sit or stand on this table.
!
A weighted umbrella base must be used when using an umbrella with this table.
!
Do not discard any of the packaging until you have checked that you have all the parts and pack
of fittings.
!
Keep children away during assembly. This item contains small parts which can be swallowed by
children. Children should always be under direct adult supervision while using the product.
!
Retain the assembly instructions for future reference.
!
Please quote following FQC NO. when contacting service center.
INTENDED FOR RESIDENTIAL USE ONLY.
TGS64SW
PART Q'TY
TABLE TOP
LEG
SUPPORT
CENTER
CONNECTOR WITH RING
SCREW ST4.2*12
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
-WM
6
17C33A0709001Y4
1 7
17C01A0709001Y4
4 8
17FA05040301-Y4
2 9
1800337004
10
1800337001
1
6 11
17KAA0101----Y4
FIGURE 1
2
BOLT M6*25
BOLT M6*25
WASHER d6.5*D13*1.0
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
2
2
2
3
3
1
COURTYARD CREATIONS INC.
4
4
8
4
4
1
5
