The Cove Fire Pit
Installation Instructions for CV-30
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Crystal Fire CV-30WT and is the answer not in the manual?

Questions and answers

Summary of Contents for Outdoor GreatRoom Company Crystal Fire CV-30WT

  • Page 1 The Cove Fire Pit Installation Instructions for CV-30...
  • Page 3: Table Of Contents

    IMPORTANT Contents Please consult your Crystal Fire Burner Owner’s instruction manual for detailed instructions and important information related to Required Tools…………………………….…..2 hooking up your burner, including safety information, proper tightening of connections with two wrenches, and full burner setup Included with your Fire Pit……………….3 and lighting instructions.
  • Page 4: Included With Your Fire Pit

    Included with your Fire Pit CV-BASE with Key Valve Control Panel Key for Key Valve Crystal Fire CF-30 Burner Kit...
  • Page 5: Assembly Instructions

    Assembly Instructions Included with your Fire Pit A. 4 Fasteners 1. First, unscrew the shipping block with a power drill. Discard B. 4 B-Bolts board. It will not be needed for further assembly of this C. 4 C-Bolts product. 2. Remove fire pit base from the crate you received it in. Place D.
  • Page 6: Gas Connections

    Igniter Installation 1. Make sure the valve is in the OFF position before beginning. 2. Remove sparker cap by turning counter-clockwise and insert a AAA battery (not included). Gas Connections Read and understand your Crystal Fire Burner Owner’s manual before beginning burner hookups or using the device. Do not use Teflon tape or pipe dope on flare fittings.
  • Page 7 2. Ensure the correct orifices are installed for the fuel type you are using (see Crystal Fire Burner Owner’s manual included with burner for orifice sizing information). TIGHTEN SECURELY WITH TWO WRENCHES 1. Reach inside the base and attach gas supply line to the input shown below, using a 3/8”...
  • Page 8: Igniter Installation

    Sparker will not operate correctly without an ignition and ground wire attached. Igniter Installation (continued) Sparker will not operate correctly without an ignition and ground wire attached.  Plug both BLACK wires hanging from the burner into the back of the sparker box.
  • Page 9: Glass Installation

    Glass Installation Glass Installation 1. Scatter all the included glass beads evenly onto burner surface. DO NOT OPERATE CRYSTAL FIRE BURNER WITHOUT INCLUDED GLASS BEADS...
  • Page 10 IMPORTANT Please consult your Crystal Fire Burner Owner’s instruction manual for detailed instructions and important information related to hooking up your burner, including safety information, proper tightening of connections with two wrenches, and full burner setup and lighting instructions. DO NOT ATTEMPT TO INSTALL CF-30 BURNER WITHOUT FIRST CONSULTING THE CRYSTAL FIRE BURNER OWNER’S MANUAL.
  • Page 11 Please visit http://www.outdoorrooms.com/warranty-form/ to register your product. Thank you for purchasing an Outdoor GreatRoom Company product! This fire pit was made with pride in the USA. 14400 Southcross Drive West • Suite 100 • Burnsville, MN 55306 Toll Free: 1-866-303-4028 •...
