- Page 1 Caden Fire Table Installation Instructions for Caden Fire Pit Table CAD-1224 outdoorrooms.com...
-
Page 2: Table Of Contents
IMPORTANT Please consult your Crystal Fire Plus instruction manual for detailed instructions and important information related to the burner installation including: lighting and operating instructions, safety information, and proper tightening of connections with two wrenches. DO NOT ATTEMPT TO INSTALL CRYSTAL FIRE PLUS BURNER WITHOUT CONSULTING THE CRYSTAL FIRE OWNER’S MANUAL. -
Page 3: About Your Fire Table
ABOUT YOUR FIRE TABLE A. REQUIRED TOOLS • Utility Knife - To cut and remove packaging • 2 Open Ended Wrenches - To secure gas connections • Phillips Screw Driver (Do not use a drill to assemble) - For assembly •... -
Page 4: Assembly Instructions
ASSEMBLY INSTRUCTIONS WARNING Exposed edges may be sharp, use leather gloves when removing packaging and handling the base. Do not remove protective cardboard packaging until you have placed the fire pit in its desired location. UNPACKING Do not discard any packaging until assembly is complete and unit is tested. - Page 5 Screw legs onto end panel as shown below. Apply foam gasket to top of panel and legs. FOAM THIS SIDE END PANEL Screw legs onto door frame as shown below. Screw magnet onto door frame. Apply foam gasket to top of door frame and legs. DOOR FRAME SEE DETAIL A FOAM THIS SIDE...
-
Page 6: Top Assembly
TOP ASSEMBLY Screw panel assemblies in steps 2 and 3 onto the top as shown be- low. Loosely tighten screws, final tightening of all screws after com- pleting step 6 of assembly. DOOR FRAME ASSEMBLY END PANEL ASSEMBLY outdoorrooms.com... -
Page 7: Cf-Sparker Assembly
CF-SPARKER ASSEMBLY CF-SPARKER Installation • Locate CF-SPARKER inside of Crystal Fire Plus burner box. • Remove CF-SPARKER cap and hex nut. Insert AAA battery (not included) with + end out. • Install CF-SPARKER into control panel as shown below. CF-SPARKER must be installed BEFORE control valve. -
Page 8: Bottom Component Assembly
BOTTOM COMPONENT ASSEMBLY Screw tank tray onto bottom of the base as shown below. TANK TRAY outdoorrooms.com... -
Page 9: Setting Up Your Burner
SETTING UP YOUR BURNER ATTENTION Read and understand your Crystal Fire Plus owner’s manual before begin- ning burner hookups or using the device. DO NOT USE TEFLON TAPE OR PIPE DOPE ON FLARE FITTINGS. IMPORTANT Please consult your Crystal Fire Plus instruction manual for detailed instructions and important information related to the burner installation including: lighting and operating instructions, safety information, and proper tightening of connections with two wrenches. -
Page 10: Thermocouple Installation
B. THERMOCOUPLE INSTALLATION • Refer to Crystal Fire Plus instruction manual for detailed attachment of thermocouple. • Attach thermocouple to burner valve as shown below. DETAIL A SCALE 0.800 DETAIL B SCALE 0.800 C. ELECTRODE INSTALLATION • Plug both BLACK wires hanging from the burner into the back of the CF-SPARKER. -
Page 11: Propane Tank Installation
ATTENTION D. PROPANE TANK INSTALLATION • With the propane tank valve HAND TIGHTEN, DO NOT USE A WRENCH FOR THIS CONNECTION. and fire pit valve off, attach the propane regulator to the propane tank. • Place tank in tank tray. PROPANE REGULATOR •... -
Page 12: Miscellaneous
4. MISCELLANEOUS WARNING A. FIRE MEDIA INSTALLATION • Scatter all included glass beads, lava DO NOT OPERATE CRYSTAL FIRE rock, or other approved fire media PLUS BURNER WITHOUT INCLUDED evenly across entire burner surface. GLASS BEADS OR OTHER APPROVED FIRE MEDIA. WARNING B. -
Page 13: Operating Instructions
OPERATING INSTRUCTIONS IMPORTANT Before operating your CAD-1224, ensure all gas connections are properly tightened and thoroughly leak checked. Refer to the Crystal Fire Plus manual for information on proper leak checking and other critical safety information. WARNING FIRE OR EXPLOSION HAZARD If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. -
Page 14: Warnings
6. WARNINGS IMPORTANT Please consult your Crystal Fire Plus instruction manual for detailed instructions and important information related to the burner installation including: lighting and operating instructions, safety information, and proper tightening of connections with two wrenches. DO NOT ATTEMPT TO INSTALL CRYSTAL FIRE PLUS BURNER WITHOUT FIRST CONSULTING THE CRYSTAL FIRE OWNER’S MANUAL. - Page 16 Thank you for purchasing an Outdoor GreatRoom Company product! This fire pit was made with pride in the USA. Warranty: Fire pit tables are covered under a 1 year manufacturer’s warranty. Please visit http://www.outdoorrooms.com/product-registration to register your product. 14400 Southcross Drive West • Suite 100 • Burnsville, MN 55306 Toll Free: 1-866-303-4028 •...
