OSD Menu Tree

NOTE : The function setting can be adjusted with both switch (OSD joystick) and remote control through RS485 or UTC.
In case of camera without OSD joystick, it can be adjusted with coaxial (UTC) only.
EXPOSURE
LENS

MANUAL / AUTO

BACKLIGHT OFF / HME / BLC / WDR
DRC OFF / LOW / MIDDLE / HIGH
DEFOG OFF / ON
AGC 0 ~ 10
STARLIGHT OFF / x2 ~ x32
3D DNR
OFF / LOW / MIDDLE / HIGH
EXIT JUMP
COLOR
WHITE BAL. AUTO / AUTO-EX / PRESET
/ MANUAL
COLOR GAIN 0 ~ 20
EXIT JUMP
DAY & NIGHT
MODE
AUTO / COLOR / BW / EXTERN
CDS THRES 0 ~ 20
CDS MARGIN
0 ~ 20
EXTERN SW
LOW / HIGH
EXT LED
OFF/ AUTO
DELAY LOW / MIDDLE / HIGH
SMART IR
0 ~ 20
EXIT JUMP
FUNCTION
SHARPNESS 0 ~ 10
GAMMA 0.45 ~ 0.75
MIRROR OFF / ON
FLIP OFF / ON
EXIT JUMP
MOTION
MOTION OFF / ON
DET WINDOW
DET TONE 0 ~ 4
MDRECT FILL OFF / ON
SENSITIVITY 0 ~ 10
MOTION OSD OFF / ON
TEXT ALARM OFF / ON
SIGNAL OUT OFF / ON
EXIT JUMP
PRIVACY
PRIVACY OFF / ON
ZONE NUM 0 ~ 15
ZONE DISP OFF / ON
H-POS 0 ~ 59
V-POS 0 ~ 33
H-SIZE 0 ~ 60
V-SIZE 0 ~ 34
Y LEVEL 0 ~ 20
CB LEVEL 0 ~ 20
CR LEVEL 0 ~ 20
TRANS 0 ~ 3
EXIT JUMP
SETUP
COMMUNICA
CAM TITLE OFF / RIGHT UP / LEFT DOWN
IMAGE RANGE FULL / COMP / USER
FREQ 50Hz / 60Hz
LANGUAGE ENG/ CHN/ CHN(S)/ JPN / KOR
INITIAL OFF / ON
EXIT JUMP
EXIT
SAVE & EXIT
EXIT
The contents might be different some products.
