5.5 Emergency stop/reset operation

To make an emergency stop or to reset the inverter, follow these steps. An emergency
stop can be made when operation is performed with the terminal board (parameter
CMOd=0, 2, 3 or 4).
1
Press the [STOP/RESET] key, which displays
the blinking code "EOFF" in the upper right
corner of the window.
2
Then press the [STOP/RESET] key again.
The Emergency Stop window appears and the
blinking code "E" is displayed.
3
Then press the [STOP/RESET] key again.
The Trip window appears and the blinking code
"CLr" is displayed in it.
4
Last of all, press the [STOP/RESET] key once
again to reset the inverter.
5. Operation in Top View Mode
FWD 60.0 Hz
Quick
FWD 60.0 Hz
Quick
FWD 60.0 Hz
Quick
5-6
Top View Mode EOFF
RUN
60.0
Hz
Emergency stop?
Lng ---
Top View Mode
Trip
E
Emergency stop
Lng ---
Top View Mode
Trip
CLr
Trip reset? (STOP-Key)
Lng ---
