Introduction Introduction
Thank you for purchasing a LCD remote keypad (RKP004Z) designed specifically for
Toshiba VF-AS1/PS1 series industrial inverters.
The use of this LCD remote keypad (also referred to as the unit, the product and the
remote keypad) equipped with a high-resolution liquid crystal display with back lighting
makes it easier to set parameters or monitor the operation.
The unit can be mounted easily on an inverter's operation panel, and on a board by
means of an optional attachment. Moreover, using the unit along with a dedicated
interconnect cable makes it possible to operate the inverter by remote control.
This instruction manual mainly explains how to use the keys on the LCD remote keypad.
For details of parameters available, refer to the instruction manual included with your
inverter.
● Never connect the unit to any inverter other than a VF-AS1/PS1 series
inverter or any communications device. Do not use any cable other than
an optional interconnect cable designed specifically for the unit.
Prohibited
Failure to observe this might cause the unit to break down and result in
an electric shook or fire.
Explanation of model code
RKP 004
Check product purchase
Before using the unit, make sure all the following items are packaged with the
product.
Z - 3
Revision No.
Cable length (Z: No cable)
Optional LCD keypad
Optional remote keypad
Product (remote keypad)
(RKP004Z)
Warning
Instruction Manual (1)
ⅰ
This manual
