- Page 1 MANUAL ENGLISH DRX Passive Series V3 Productcode: D3630 D3631 D3632 D3633 D3643 D3644 D3645 D3646 Productname: DRX-8 DRX-10 DRX-12 DRX-15 DRX-10B DRX-12B DRX-15B DRX-18B Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
DRX Passive Series Table of contents Warning ....................................2 Safety Instructions ................................. 2 Connection with the mains............................4 Return Procedure ................................4 Claims ....................................4 Features ....................................5 Accessories ..................................5 Rear Panel Description ..............................6 DRX-1OB/12B/15B SUB/18B SUB ..........................6 DRX-8/10/12/15 ................................ -
Page 3: Warning
DRX Passive Series Warning FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. - Page 4 DRX Passive Series Make sure you don’t use the wrong kind of cables or defective cables. Never remove warning or informative labels from the unit. Only use device indoor, avoid contact with water or other liquids. Please turn off the power switch, when changing the power cord or signal cable, or select the input mode switch.
-
Page 5: Connection With The Mains
DRX Passive Series Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER FASE BLUE BLACK SILVER... -
Page 6: Features
DRX Passive Series Features These series products include passive speaker cabinets and subwoofer. PASSIVE SPEAKERS: 1. DRX-8 2. DRX-10 3. DRX-12 4. DRX-15 SUBWOOFER: 1. DRX-10B 2. DRX-12B 3. DRX-15B 4. DRX-18B These products are design to provide a cost effective high grade solution, and they can be used for all kinds of applications, such as churches, conference center, disco, etc. -
Page 7: Rear Panel Description
DRX Passive Series Rear Panel Description DRX-1OB/12B/15B SUB/18B SUB INPUT: Receive the power coming from an external power amplifier (SPK +1/-1 connected; +2 -2 not connected) THRU: Direct LINK for connecting in parallel a second speaker cabinet (SPK +1/-1 connected; +2 -2 not connected). -
Page 8: Drx-8/10/12/15
DRX Passive Series DRX-8/10/12/15 INPUT: Receive the power coming from an external power amplifier (SPK +1/-1 connected; +2 -2 not connected) THRU: Direct LINK for connecting in parallel a second speaker cabinet (SPK +1/-1 connected; +2 -2 not connected). -
Page 9: Connection Examples
DRX Passive Series Connection Examples Two Passive Subwoofers & Two Passive Satellite Speakers Make your initial connections with all the equipment powered off and ensure that all the main volume controls are turned completely down. Connect one side of the speaker cable to the Output CH 1 / CH 2 to Binding Post of your stereo power amplifier and the other side to the Input socket of your speaker cabinet. -
Page 10: One Passive Subwoofer & Two Passive Satellite Speakers
DRX Passive Series One Passive Subwoofer & Two Passive Satellite Speakers Make your initial connections with all the equipment powered off and ensure that all the main volume controls are turned completely down. Connect one side of the speaker cable to the Output CH 1 / CH 2 to Binding Post of your stereo power amplifier and the other side to the Input socket of your speaker cabinet. -
Page 11: Two Passive Satellite Speakers
DRX Passive Series Two Passive Satellite Speakers Make your initial connections with all the equipment powered off and ensure that all the main volume controls are turned completely down. Connect one side of the speaker cable to the Output CH 1 / CH 2 to Binding Post of your stereo power amplifier and the other side to the Input socket of your speaker cabinet. -
Page 12: Frequency Response Diagram
DRX Passive Series Frequency Response Diagram DRX-10B/12B/15B/18B DRX-10B DRX-12B DRX-15B DRX-18B... -
Page 13: Drx-8/10/12/15
DRX Passive Series DRX-8/10/12/15 DRX-8 DRX-10 DRX-12 DRX-15... -
Page 14: Connection Cables
DRX Passive Series Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 15: Technical Specifications
DRX Passive Series Technical Specifications Model DRX-10B System Type 10" Reflex Subwoofer Continuous Power 250W Peak Power 500W Transducer Low 10" Woofer, 2.5"voice coil, with double ventilation SPL at 1m Max 121dB Impedance 8Ω Frequency Response 55Hz-500Hz (-6dB) Connector 2*Speakon 1+,1- (2+,2- N/C) MDF cabinet, glued and reinforced, resistant black paint;... -
Page 16: Drx-15B
DRX Passive Series Model DRX-15B System Type 15" Reflex Subwoofer Continuous Power 300W Peak Power 600W Transducer Low 15" Woofer, 2.5"voice coil, with double ventilation SPL at 1m Max 124dB Impedance 8Ω Frequency Response 45Hz-400Hz (-6dB) Connector 2*Speakon 1+,1- (2+,2- N/C) MDF cabinet, glued and reinforced, resistant black paint;... -
Page 17: Drx-8
DRX Passive Series Model DRX-8 System Type 2-Way Vented Passive Speaker cabinet Continuous Power 100 Watts Peak Power 200 Watts 50°H x 50°V Horn Coverage Speaker Sensitivity (1W.1m) 90 dB SPL ±3dB Max SPL: 113dB at 1m Frequency Response 68Hz~20kHz (- 6dB) Impedance 8Ω... -
Page 18: Drx-12
DRX Passive Series Model DRX-12 System Type 2-Way Vented Passive Speaker cabinet Continuous Power 150 Watts Peak Power 300 Watts Horn Coverage 50°H x 50°V Speaker Sensitivity (1W.1m) 95.6 dB SPL ±3dB Max SPL: 120.3dB at 1m Frequency Response 55Hz~20kHz (- 6dB) Impedance 8Ω... -
Page 19: Troubleshooting
DRX Passive Series Troubleshooting This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit operates properly, do not carry out following steps. - Page 20 ©2021 DAP Audio...
