- Page 1 MANUAL ENGLISH EVO 8A Ordercode: D3692 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
EVO 8A Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Overview ..................................5 Back ....................................6 Installation ................................... 7 Set Up and Operation ............................... 7 Names and Functions ............................... -
Page 3: Warning
Your shipment includes: ● DAP Audio 2-way active speaker system EVO 8A, 2 x 80 W ● C8 power cable (1,2 m) ●... -
Page 4: Operating Determinations
EVO 8A ● Avoid ground loops! Always be sure to connect the power amps and the mixing console to the same electrical circuit to ensure the same phase! ● Avoid installing your equipment very near radio or TV sets, mobile phones, etc., as these can cause RF (radio frequency) interference. -
Page 5: Return Procedure
EVO 8A The EVO 8A can be mounted to a wall or placed on a flat stage floor. Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. -
Page 6: Description Of The Device
EVO 8A Description of the device Features ● Input voltage: 230 V AC, 50 Hz ● Speaker system: Active 2-way full range ● Power consumption: 2 x 80 W ● Sensitivity W/m: 92 dB ● LF driver: 8” Woofer ●... -
Page 7: Back
EVO 8A Back Fig. 02 01) LED indicators (OK/CLIP/TEMP/ERROR) 02) Bass control 03) Treble control 04) Speaker connector OUT 05) Power LED indicator 06) Volume control 07) Power switch ON/OFF 08) Fuse 5S1,5A/250V 09) 230V AC C8 power connector IN... -
Page 8: Installation
EVO 8A Installation Remove all packing materials from the EVO 8A. Check that all foam and plastic padding is removed. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty. -
Page 9: Names And Functions
Connect input signal (for example, from a mixer) to the speaker, by means of an RCA cable. Maintenance The DAP Audio EVO 8A requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. -
Page 10: Troubleshooting
04) If all appears to be O.K., plug the unit in again. 05) If you are unable to determine the cause of the problem, do not open the EVO 8A, as this may damage the unit and the warranty will become void. -
Page 11: Dimensions
EVO 8A Dimensions Order code: D3692... - Page 12 ©2019 DAP Audio...
