SportsArt Fitness G845 Owner's Manual

Hide thumbs

Table of Contents

Quick Links

Download this manual

G845 OWNER'S MANUAL CONTENTS

1. INTRODUCTION ..............................................................................

2. SAFETY PRECAUTIONS ................................................................

3. LIST OF PARTS ...............................................................................

4. ASSEMBLE THE PRODUCT ..........................................................

STEP 1 Install the Frame ....................................................................

STEP 2 Install the Glide Rail ...............................................................

STEP 3 Install the Pedestal Covers ....................................................

STEP 4 Install the Foot Pedals ..........................................................

STEP 5 Level the Product ...................................................................

STEP 6 Move the Product into Place ..................................................

STEP 7 Level the Product ...................................................................

STEP 8 Install the Power Cord ...........................................................

STEP 9 Beware of Moving Parts ........................................................

5. UNDERSTAND THE G845 DISPLAY ..............................................

DISPLAY Overview ..............................................................................

DISPLAY Specifications .......................................................................

DISPLAY Windows ............................................................................... 24

DISPLAY Keys ...................................................................................... 24

6. OPERATE THE PRODUCT .............................................................

OPERATION Quick Start .....................................................................

OPERATION Start a Workout Program ...............................................

OPERATION Display ...........................................................................

OPERATION Pause ............................................................................

OPERATION Cool Down .....................................................................

OPERATION Review Summary ...........................................................

OPERATION Idle Mode .......................................................................

OPERATION Workout Programs .........................................................

OPERATION User Preferences and Component Versions...................

7. ABOUT HEART RATE DETECTION ................................................

HEART RATE Telemetry ......................................................................

HEART RATE Contact .........................................................................

8. GUIDELINES FOR EXERCISE .......................................................

9. ACCESSORIES ...............................................................................

ACCESSORIES Entertainment Cap ....................................................

ACCESSORIES MYE Wireless TV Audio_Channel Receivers ...........

10. MICRO INVERTER .......................................................................

MICRO INVERTER Important Safety Instructions ...............................

MICRO INVERTER Cautionary Messages ..........................................

MICRO INVERTER Electronic Specifications ......................................

MICRO INVERTER Circuit Board & Product Settings .......................... 42

11. MAINTENANCE .............................................................................

MAINTENANCE Messages .................................................................. 43

MAINTENANCE Lubrication Procedure ............................................... 44

MAINTENANCE Cleaning the Glide Rails ............................................ 46

MAINTENANCE How to Replace a Fuse ............................................. 47

MAINTENANCE Schedule ...................................................................

MAINTENANCE Task List (Elliptical Trainers) .....................................

MAINTENANCE One-Year Maintenance Log ......................................

MAINTENANCE Electronics Block Diagram ........................................

Table of Contents

Need help?

Do you have a question about the G845 and is the answer not in the manual?

Questions and answers

Summary of Contents for SportsArt Fitness G845

Page 1: Table Of Contents
STEP 6 Move the Product into Place ..........STEP 7 Level the Product ..............STEP 8 Install the Power Cord ............STEP 9 Beware of Moving Parts ............5. UNDERSTAND THE G845 DISPLAY ..........DISPLAY Overview ................DISPLAY Specifications ............... DISPLAY Windows ................24 DISPLAY Keys ..................
Page 2: Introduction
1. INTRODUCTION Congratulations on your purchase of one of the finest exercise products on the market today, the SportsArt G845 Elliptical trainer. Constructed of high quality materials and designed for years of reliable usage, this product was made to become an integral part of your commercial fitness venue.
Page 3: Safety Precautions
2. SAfETy PRECAUTIONS Your SportsArt elliptical trainer was designed and built for optimum safety. However certain precautions apply whenever you use your elliptical trainer. Please read the entire manual before assembly and operation. Also, please note the following safety precautions: ●...
Page 4 2. SAfETy PRECAUTIONS (CONTINUED) ● This elliptical trainer is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of this elliptical trainer by a person responsible for their safety.
Page 5 2. CONSIGNES DE SéCURITé • Votre elliptique SportsArt a été conçu et fabriqué afin d’assurer une sé- curité optimale. Cependant certaines précautions s’appliquent chaque fois que vous utilisez votre tapis de course. • Lisez entièrement le manuel avant l’assemblage et l’utilisation. Veuillez aussi noter les consignes de sécurité...
Page 6 2. CONSIGNES DE SéCURITé (SUITE) ATTENTION Si vous ressentez une douleur ou si vous avez une sensation anormale, ARRÊTEZ VOTRE ENTRAÎNEMENT et consultez immédiatement votre médecin. Entraînez-vous à votre niveau d’exercice recommandé. NE PAS s’entraîner jusqu’à l’épuisement. Avant de commencer un programme d’exercice, vous devriez consulter votre médecin.
Page 7: List Of Parts
3. LIST Of PARTS Assembly Parts Qty. No. Qty. Name Name Main frame Support tube, left Stationary handlebar Support tube, right Pedestal covers, left A10 Foot pedals and right Stationary handlebar A11 Hardware kit cover, left Stationary handlebar A12 Glide rail covers cover, right Right roller cover A13 Power cord...
Page 8 3. LIST Of PARTS (CONTINUED) Components in the Hardware Kit Name Qty. Specification Notes Mushroom top inner hex screw M10*P1.5*L25 Serrated washer D20*d10.2*t2.0 Secondary guide roller bolt D9.96*L54 Self-lubricating bushing Secondary guide roller D23*L45 12 Stride adjustment linkage cover Hex nut M10*P1.5 Stopper Ø30-30...
Page 9: Assemble The Product
4. ASSEMBLE THE PRODUCT Follow instructions below to assemble this product. Note that in this manual the words “left” and “right” are used to refer to the product and its parts. As such, these designations correspond to the “left” and “right” sides of a person in position to exercise on this product.
Page 10 STEP 1 Install the frame (Continued) (e) A: Once slip the glide rail into (Part A), then place the pedal carriage lightly on the glide rail support (Part B). Connect the guide roller on the bottom of the glide rail. (Please note the direction to insert the screw is from outside to inside) B: Unsecure the bolts (32) (33) from the left/right roller covers (A6) (A7) and then put the the left/right roller covers (A6) (A7) place and secure...
Page 11 STEP 1 Install the frame (Continued) (f) Put the stride linkage in place and use the bolt (34) and washer to secure it onto the stride support assembly and then press the stride adjustment linkage covers (12) into place as shown below. Complete steps (d), (e), and (f) on the other side of the unit too.
Page 12 STEP 1 Install the frame (Continued) (g) Secure stopper (13) on the front, bottom of both glide rails and then remove the unit from the lower box.
Page 13 STEP 1 Install the frame (Continued) (h) (1) Loosely secure bolts (35) (36) A and B on both support tube (A8) (A9). At this point, donot tighten these bolts. (2) With hardware (37) shown in illustration I, secure the stationary handlebar (A2) at both sides and then tighten bolts (35) (36) at area A and B.
Page 14: Step 2 Install The Glide Rail
STEP 2 Install the Glide Rail Follow instructions (a) through (c) to install the glide rail. (a) Move part (A) of the glide rail to the upper left part of the flywheel within the 90-degree indication. Hook the part B onto the glide rail. (b) Turn part B clockwise as shown to a nearly horizontal position of the glide rail covers (A12).
Page 15: Step 3 Install The Pedestal Covers
STEP 3 Install the Pedestal Covers Hold the pedestal covers in place. Use the screw driver provided to tighten the screws (15) into the pedestal covers (A3).
Page 16: Step 4 Install The Foot Pedals
STEP 4 Install the foot Pedals Follow steps (a) through (b) to secure the support tubes. (a) There are rubber pads (A) on the foot pedals (A10). Fold the rubber pad (A) up to access screws. Secure the foot pedals (A10) onto the plate of main frame with screws (38) as shown.
Page 17 STEP 4 Install the foot Pedals (Details) Follow instructions (a) through (c) to install the details of the foot pedals. (a) Make sure the middle nibs on the foot pedals (A10) are firmly placed into the middle holes on the foot pedals (A10). Pull the nibs through the foot pedals (A10) until they fit snugly in place.
Page 18: Step 5 Level The Product
STEP 5 Level the Product Follow steps (a) through (b) to level the product (a) Elliptical trainers must be level for proper operation. Level the elliptical trainer by adjusting the feet as shown (1). Raise or lower the leveling feet as needed.
Page 19: Step 6 Move The Product Into Place
STEP 6 Move the Product into Place There are two techniques for moving this product. (a) One person: Grip the front base of the product and lift upward and then push the product into location for use. Be careful to avoid pinching fingers when setting the product down.
Page 20: Step 7 Level The Product
STEP 7 Level the Product For the user’s safety and the proper functioning of the product, this elliptical trainer must sit level on a flat floor. If necessary, adjust the levelers by following instructions (a) through (c) below. (a) Loosen the leveler nut. (b) Rotate the leveler foot downward so it firmly touches the floor.
Page 21: Step 8 Install The Power Cord
STEP 8 Install the Power Cord (a) First remove screws (39) from the power cord socket on the product. (b) Insert the power cord into place on the product. (c) Secure power cord connector screws (39) and then insert the other end of the power cord (A13) into the appropriate power supply socket in the wall.
Page 22: Step 9 Beware Of Moving Parts
STEP 9 Beware of Moving Parts This product has moving parts that could be a danger to people and animals. During use, do not insert hands or other objects into the stride adjustment slot, the opening in the rear cover, or other areas in which such action might present a hazard.
Page 23: Understand The G845 Display
5. UNDERSTAND THE G845 DISPLAy DISPLAy Overview The G845 elliptical trainer is designed for user convenience. With better feedback about your workout, you get better results. The following explains the display key and window functions. Please read this manual, understand the display functions, and thereby get optimum enjoyment and benefit from this product.
Page 24: Display Specifications
DISPLAy Specifications ● Workout level (resistance level): 1 - 40 ● Stride length: 17 - 29 inch (450 - 730mm) ● Time: 0:00 - 300:00 ● Distance: 0.00 - 9999 km or mile ● Calories: 0 - 9999 kcal ● Stride per minute (SPM): 5 – 120 (Range shown) ●...
Page 25 DISPLAy Keys (Continued) RANDOM – Press this key to select one of an almost endless number of randomly generated workout programs. Each key press, the console will randomly generate a different program. VARI-STRIDE – This workout program automatically changes stride. Exercisers can select maximum stride.
Page 26: Operate The Product
6. OPERATE THE PRODUCT There are two ways to start operating this product, either through the QUICK START mode or through a workout program/goal. OPERATION Quick Start Time, distance and calories will count up. If a workout time limit is activated, time will count down, but distance and calories will count up continuously.
Page 27: Operation Display
OPERATION Start a Workout Program (Continued) ● The CALORIE setting range is from 100 to 9999 kCal, with a default value of 100 kCal. Use ▲/▼ keys to make your selection. Press the ENTER key to confirm your setting and proceed to the age setting. Or press QUICK START key to start this program right away with default age and weight.
Page 28: Operation Pause
OPERATION Pause In Workout mode, press <STOP/PAUSE/HOLDTO RESET> key to pause the program. The data display will show messages “PAUSED” and “PRESS QUICK START TO RESUME”. All the workout data will stop accumulating and remain at the current values. If no operations in 50 second, enter idle mode.
Page 29: Operation Workout Programs
OPERATION Workout Programs The following explains features of the workout programs. MANUAL This program allows you to manually control resistance. In manual mode, simply press WORKOUT LEVEL ▲/▼ keys to control resistance, or STRIDE ▲/▼ keys to control stride length. INTERVAL There are three interval programs: INTERVAL1:1, INTERVAL1:2, INTERVAL 2:2.
Page 30 OPERATION Workout Programs (Continued) During program setting, you may press QUICK START to start the program right away. The maximum stride length can be adjusted during exercising by pressing STRIDE ▲/▼ keys. fIT TEST The FIT TEST program is designed for physical fitness assessments. The program is set with a time limit;...
Page 31: Operation User Preferences And Component Versions
OPERATION Workout Programs (Continued) If CUSTOM HR is selected, the target heart rate will need to be set first. The range is 84 - 199bpm with default value of 120bpm. The display will show “TARGET HR - XXX” for setting. Press ▲/▼ key to adjust the setting. Press ENTER key to confirm and start the program.
Page 32 OPERATION User Preference & Component Version (Cont.) LANGUAGE a. The display will show the current country selected, such as “US”. Note: After 4 seconds, it will display “XX MILE H>H” or “XX KM H>H” (XX represents the country code) b. Press ▲/▼ keys to change the country. Press the ENTER key to confirm the selection.
Page 33: About Heart Rate Detection
7. ABOUT HEART RATE DETECTION Heart rate detection functions are selected at the time of purchase. Not every product has every type of heart rate detection. The following explains factors that influence the performance of two of the most common types of heart rate detection devices.
Page 34: Guidelines For Exercise
Note that in dry areas in particular, static electricity can interfere with unit operation and shock people. To discharge static electricity from your body, touch something else before touching metal on the product. 8. GUIDELINES fOR EXERCISE HOW HARD SHOULD I EXERCISE? Studies show that to benefit from aerobic exercise, people need to maintain a certain heart rate during their workouts.
Page 35: Accessories
9. ACCESSORIES There are accessories attached to this console; some are standard and some are optional. The following explains the details of each accessory and its function. USB CHARGER (Standard) The USB charger will provide 5V 500mA voltage for the smart phone or other devices charging.
Page 36: Accessories Entertainment Cap
9. ACCESSORIES (CONTINUED) Entertainment Cap (a) RFID member card slot: work with both optional SA WELL+ and ECOFIT member cards. (Not available yet.) (b) Bluetooth/WIFI connection button: press this button to pair the smart phone SA WELL+ App. (c) USB port: this port is used for device charging as well as optional data transferring.
Page 37: Accessories Mye Wireless Tv Audio_Channel Receivers
9. ACCESSORIES (CONTINUED) MyE Wireless TV Audio_Channel Receivers: If your equipment has been installed MYE Wireless TV Audio_Channel Receivers, the display must has Channel Keys. Please make sure your equipment is with the correct sticker as below. (a) None Treadmill (Bike, Elliptical and Stepper...etc.) Left display: Without Channel Keys.
Page 38 9. ACCESSORIES (CONTINUED) MyE Wireless TV Audio_Channel Receivers fuctions: 1. The receiver has two kinds of module as below. (Note: MyE Wireless TV Audio_Channel Receivers and Module not provided.) (1). MC3R-9(900MHZ) must work with MYE Wireless TV Audio_Channel Receivers MWTD-S9. (2).
Page 39: Micro Inverter
10. MICRO INVERTER MI-250 MICRO INVERTER Important Safety Instructions CAUTION These servicing instructions are for use by qualified personnel only. To reduce the risk of electric shock, do not perform any servicing other than that specified in the operating instructions unless you are qualified to do so. PRUDENCE! Ces instructions d’entretien sont uniquement destinées à...
Page 40 MICRO INVERTER Cautionary Messages (Continued) WARNING Power fed from more than one source. Each circuit must be individually disconnected before servicing. Do not remove cover until 5 minute after disconnecting all sources of supply. AVERTISSEMENT! L’alimentation provient de plus d’une śource. Chaque circuit doit étre coupé avant toute intervention de dépannage.
Page 41: Micro Inverter Electronic Specifications
MICRO INVERTER Electronic Specifications Input Data(3 Phase AC) 3 Phase permanent-magnet Input power source generator Maximum input voltage 140V(line-to-line voltage) Nominal operating voltage range 55-125V(line-to-line voltage) Maximum input current 7A(line current) Output Data(single phase AC) Maximum continuous output power 220W Output power factor rating >0.9 120VAC(105.6-132.0V) (for USA)
Page 42: Micro Inverter Circuit Board & Product Settings
MICRO INVERTER Circuit Board & Product Settings frequency setting: MI-250 can detect the frequency automatically without setting. Connecting to grid power: After MI-250 is installed into Green System products, the power can be linked to grid power through product power cord, as shown in the following figure.
Page 43: Maintenance
11. MAINTENANCE Maintenance topics are presented below in the following order: error messages, lubrication the seat carriage, maintenance schedule, task list, one-year maintenance log, and electronics block diagram. MAINTENANCE Error Messages ERROR_1_x, ERROR_2_x, ERROR_3_x, ERROR_4_x, ERROR_5_x, ERROR_6_x, ERROR_7_x and ERROR_8_x. Error messages will appear on the display when the Micro Inverter detects an abnormality.
Page 44: Maintenance Lubrication Procedure
MAINTENANCE Error Messages (Continued) ERR0R_8_x Error messages will appear on the display when the Micro Inverter or stride- length drive board communication is abnormal. Error code explanations follow: ERROR_8_1_: When power on, the communication to the Micro Inverter is abnormal. ERROR_8_2_: When power on, the communication to the Micro Inverter is normal, however an abnormality occurs during operation.
Page 45 MAINTENANCE Lubrication Procedure (Continued) Please follow instructions (a) through (e) to lubricate the stride motor (a) Push in at point A, and slide upward to remove the lubrication hole cover as (1) (2) shown. (Note that point A provides the best contact surface on the lubrication hole cover.) (b) During Banner mode, the message shows “SELECT A PROGRAM”, press STRIDE ▲...
Page 46: Maintenance Cleaning The Glide Rails
MAINTENANCE Cleaning the Glide Rails Clean the both left and right glide rails daily as follows: (a) Use a clean, lint-free cloth to wipe dust and debris off the glide rails. (b) Operate the product to inspect it and to determine where dirt might remain on the glide rails.
Page 47: Maintenance How To Replace A Fuse
MAINTENANCE How to Replace a fuse If electrical current becomes too high, the fuse breaks. This protects the product. To replace a fuse, follow instructions (a) through (g) below. (a) Press the fuse cap inward. using a tool. (b) Turn the fuse cap counterclockwise. (c) The fuse cap springs out.
Page 48: Maintenance Schedule
MAINTENANCE Schedule Area Week Month Quarter year Notes Exterior Clean Inspect and Screws secure loose parts Glide Wipe away dirt rail and debris. Apply silicone Rollers lubricant. Stride Apply bearing grease. motor Lubricate with Cushion original 66A lubricant.
Page 49: Maintenance Task List (Elliptical Trainers)
MAINTENANCE Task List (Elliptical Trainers) Like cars, fitness products require maintenance. Regular maintenance extends product life, and failure to maintain products can void the manufacturer’s warranty. Copy the maintenance log sheet, and record maintenance work for each fitness product. Daily tasks 1.
Page 50: Maintenance One-Year Maintenance Log
MAINTENANCE One-year Maintenance Log Facility:_______________________ Supervisor:____________________ Product model number:__________ Serial number:_________________ Start date: ____________________ End date:_____________________ Daily Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Week 22-28 Completed Daily Tasks Week 29-35 Week 36-42 Week 43-49 Week 50-52 Completed Weekly Tasks Weeks 1-7 Weeks 8-14 Weeks 15-21 Weeks 22-28...
Page 51: Maintenance Electronics Block Diagram
MAINTENANCE Electronics Block Diagram RFID Board USB Board Control Board Continua Adapter Board Option CSAFE Board SA WELL+ Connection key HRC Board iPod Audio Board Head Phone Board Option Workout Level Switch Stride length Switch HTR Board Contact HTR plates Stepper motor INCL Board Drive Board...
