5.2

Client Side Connection Parameters

Section Title
Connections
Column Title Function
Specify which port the device is connected to
Port
the FieldServer
Protocol Specify protocol used
Baud* Specify baud rate
Parity* Specify parity
Data_Bits* Specify data bits
Stop_Bits* Specify stop bits
Example
// Client Side Connections
Connections
Port , Protocol , Baud
P8 , nfs2-nca , 9600
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports
available on specific hardware.
, Stop_Bits , Parity
, 1 , None
Page 10 of 23
FS-8700-130 Notifier NCA2-NFS2-3030 Manual
Legal Values
1
P1-P8
nfs2-nca; nca2; nfs2-3030
CRT Port
4800; 9600; 19200; 38400; 57600;
(Vendor limitation)
Printer Port
9600 (Vendor limitation)
None (Vendor limitation)
8 (Vendor limitation)
1 (Vendor limitation)
