5. Mark Hole Locations
Lift the range hood into place and insert the mounting bracket
tabs through the slots in the back of the range hood.
45˚+
90˚
C
D
Hold the range hood firmly in place with one hand and
bend each mounting tab (A) upward approximately 90°.
OPTIONAL: Mark the hole in each mounting tab.
Mark the hole at the power supply knockout (B).
For a top vented installation: Mark the 4 vent hole
locations (C) on the top of the range hood.
For a rear vented installation: Mark the 4 vent hole
locations (D) on the rear of the range hood.
OPTIONAL: Mark the hole in each mounting tab.
Remove the range hood and set it aside.
8
A
A
B
C
D
6. Mark and Cut Vent Opening
3
/
" x 10" (8.3 x 25.4 cm) Rectangular Vent System
1
4
Using a
/
" (13 mm) drill bit, drill a hole in each of the dots
1
2
marked previously on either the wall or upper cabinet. Using
the outside edges of the holes, mark the vent opening.
Using a jigsaw or keyhole saw, cut the vent opening.
7. Drill Electrical Opening
Using a 1
/
" (3 cm) drill bit, drill the hole in the dot
1
4
marked previously at the electrical strain relief.
OPTIONAL: Using a
/
" (3 mm) drill bit, drill pilot holes
1
8
for the dots marked previously at each mounting tab
at an approximate 45° angle in an upward direction.
