ICP DAS USA UA-2241M Quick Start

UA-2200 Series Quick Start

English / v1.0 / Apr. 2019

What's in the box?

The shipping package contains this document and the following

items:

MicroSD 卡

CA-0910

UA-2241M

Cable

Pin Terminalx 16

Screw Driver

[Technical Support]

UA Series User Manual:

http://ftp.icpdas.com/pub/cd/UA-

Series/user_manual/UA-5231_UA-2241

ICP DAS Website: http://www.icpdas.com

Technical Support E-Mail: service@icpdas.com

UA-5200 Series Quick Start

Table of Contents

Need help?

Do you have a question about the UA-2241M and is the answer not in the manual?

Page 1 UA-2200 Series Quick Start English / v1.0 / Apr. 2019 What’s in the box? The shipping package contains this document and the following items: MicroSD 卡 CA-0910 UA-2241M Cable Pin Terminalx 16 Screw Driver [Technical Support] UA Series User Manual: http://ftp.icpdas.com/pub/cd/UA- Series/user_manual/UA-5231_UA-2241 ICP DAS Website: http://www.icpdas.com...
Page 2 Preparations for Devices 1. Power Supply: +12 ~ +48 VDC (Ex: DP-665) 2. Ethernet Hub or Switch (Ex: NS-205) 3. PC/NB: Can connect to the network and set the network Hardware Connection Connect the UA-2200 with the RJ-45 Ethernet port to an Ethernet hub/switch and PC.
Page 3 Network Connection Factory Default Settings of UA-2200 192.168.255.1 IP LAN1 Assign UA-2200 LAN2 10.0.0.1 a new IP setting Network 255.255.0.0 Netmask according to your case. 192.168.1.1 Gateway root Username After login, Account change your icpdas Password password ASAP. root Username (Refer User Web UI...
Page 4 http://192.168.255.1 Type in the URL address. Use default root/root Web UI username/password to login the system. Click【System Setting】【Network Setting】【Network Setting(LAN1)】to change the IP setting by user network. Save the IP setting, restore the PC original IP settings, and type the new IP in the browser as step-3 to login the Web UI of UA-2200.
