Net-2 Panel, 3-pin
Changing the Password
To change the password, proceed as follows:
01) Log in with your current password.
02) Enter the new password in the New Password field.
03) Click Apply to save the changes.
Do not lose your password. Once it is lost, it cannot be retrieved.
Updating the Firmware
The firmware of the Net-2 Panel can be updated via the web interface. You can download the update
from the product's page on www.Showtec.info.
01) Click Choose File and browse to the location where the firmware update file is saved.
02) Select the file.
03) Click Open on the dialog box to confirm the selection.
04) Click Upload File to start the firmware update process.
05) Follow the instructions on the browser to complete the update.
Note: It can take up to 20 seconds to update the firmware. Do not click any buttons before the update is
complete.
After completion of the firmware update, reset the Net-2 Panel to factory defaults. When you update the
firmware, all previously configured settings will be lost.
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and must
not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) The electric power supply cables must not show any damages or material fatigue.
The Showtec Net-2 Panel requires almost no maintenance. However, you should keep the unit clean.
Disconnect the mains power supply and then wipe the cover with a damp cloth. Wipe the front glass
panel clean with glass cleaner and a soft cloth. Do not use alcohol or solvents. Do not immerse in liquid.
Keep connections clean. Disconnect electric power, and then wipe the DMX connections with a damp
cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric power.
Order code: 50812/50814
