- Page 1 MANUAL ENGLISH Net-8/3 Ordercode: 50809 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
8. Set Display ................................15 9. User Preset ................................16 10. Set Default ................................16 11. Version .................................16 Maintenance ..................................17 Replacing the Fuse ..............................17 Troubleshooting ................................17 No Light ..................................17 No Response to DMX..............................17 Product Specifications ..............................19 Dimensions ..................................20 Notes ....................................21 Order code: 50809... -
Page 3: Warning
Please consider that damages caused by manual modifications to the device are not subject to warranty. This device contains no user-serviceable parts. Refer servicing to qualified technicians only. Order code: 50809... - Page 4 ● If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER NULL YELLOW/GREEN GREEN GREEN EARTH Make sure that the device is always properly connected to the earth! Improper installation can cause serious injuries and/or damage of property! Order code: 50809... -
Page 6: Return Procedure
After this period complaints will not be handled anymore. Complaints will only then be considered if the client has so far complied with all parts of the agreement, regardless of the agreement of which the obligation is resulting. Order code: 50809... -
Page 7: Description Of The Device
Description of the device Features The Showtec Net-8/3 node is a cutting-edge network routing device which converts ArtNET to DMX-512 and DMX-512 to ArtNet. A maximum of 4096 channels can be transmitted over a single CAT5. This makes the Net-8/3 suitable for small and large-scale events. The NeT-8/3 embeds a built-in network switch to be used as an ethernet repeater as well as 8 isolated DMX-512 universes which can be used as an input or output. -
Page 8: Backside
Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Order code: 50809... -
Page 9: Control Modes
Do not supply power before the whole system is set up and connected properly. 06) Set the IP address of your laptop/PC to 2.0.0.1 and the Net’s to 2.0.0.2. Setup Net-8/3 with Laptop/PC Fig. 03 Note: Link all cables before connecting electric power Order code: 50809... -
Page 10: Setup Net-8/3 With Lighting Controller
Do not supply power before the whole system is set up and connected properly. 06) Set the IP address of your lighting controller to 2.0.0.1 and the Net’s to 2.0.0.2. Setup Net-8/3 with Lighting controller Fig. 04 Note: Link all cables before connecting electric power Order code: 50809... -
Page 11: Fixture Linking
CAT-5 cable 7,6 mm Matte blue PVC. Ordercode FL55150 (1,5 m), FL553 (3 m), FL556 (6 m), FL5510 (10 m), FL5515 (15 m), FL5520 (20 m). ● CAT-6 cable (recommended for best data transfer). Ordercode FL563 (3 m), FL566 (6 m), FL5610 (10 m), FL5615 (15 m), FL5640 (40 m). Order code: 50809... -
Page 12: Control Panel
This menu shows the device’s ID. For more information see “6.Set Device ID” on page 15. This menu shows the device’s IP address. For more information see “3.Set IP Address” on page 13). ● Press the LEFT button to enter the main menu. Order code: 50809... -
Page 13: Main Menu Options
04) Press the RIGHT button to confirm. 05) If you select ENABLE, the network switch will automatically provide an IP address to the device. 06) If you select DISABLE, you will have to set the IP address manually. Order code: 50809... -
Page 14: Set Ip Address
01) Press the LEFT button to enter the main menu. 02) Press the UP/DOWN buttons to select SET DMX PORT and press the RIGHT button to open the submenu. The display shows: 03) Press the UP/DOWN buttons to scroll through the ports 1–8. Order code: 50809... - Page 15 07) Press the UP/DOWN buttons to change the values. 08) Press the RIGHT button to confirm. 09) Press the LEFT button to go to the previous submenu. 10) Press the LEFT button again to return to the main menu. Order code: 50809...
-
Page 16: Set Device Id
02) Press the UP/DOWN buttons to select SET DISPLAY and press the RIGHT button to open the submenu. The display shows: 03) Press the UP/DOWN buttons to choose NORMAL or INVERSION. 04) Press the RIGHT button to confirm. 05) If you select INVERSION, the display will be horizontally flipped. Order code: 50809... -
Page 17: User Preset
05) If you choose YES, the device will be reset and the factory default settings will be restored. 11. Version 01) Press the LEFT button to enter the main menu. 02) Press the UP/DOWN buttons to select VERSION and press the RIGHT button to open the submenu. The display shows: Order code: 50809... -
Page 18: Maintenance
04) The electric power supply cables must not show any damages or material fatigue. The Showtec Net-8/3 requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply and then wipe the cover with a damp cloth. Wipe the front glass panel clean with glass cleaner and a soft cloth. - Page 19 3 in the fixture that behaves erratically ● Check the user manual of the LEDs/lamp damaged defective fixture The power supply settings do not ● Disconnect fixture. Check settings match local AC voltage and and correct if necessary frequency Order code: 50809...
-
Page 20: Product Specifications
Max. ambient temperature t From -5 °C to +40 °C Max. housing temperature t 70 °C Minimum distance: Minimum distance from flammable surfaces: 0,5 m Design and product specifications are subject to change without prior notice. Website: www.Showtec.info Email: service@highlite.com Order code: 50809... -
Page 21: Dimensions
Net-8/3 Dimensions Order code: 50809... -
Page 22: Notes
Net-8/3 Notes Order code: 50809... - Page 23 Net-8/3 Order code: 50809...
- Page 24 ©2020 Showtec...
