Rotary Evaporator
LED power
Lift-up key
Speed key
Temperature key
Control knob
Figure 3
Figure 4
Lift-down key
LCD display
Int key
Timer key
Power switch
7
Items
Push the key and then rotate control knob
Speed key
to set the rated speed in the range from 20
Speed
to 280.
Push the key and then rotate control knob
to set the rated temperature in the range
Temperature
from room temperature to 180° C（water:
key Temp
RT~90℃）, press the key for 3s to switch
the heating mode.
Push the key and then rotate control knob
Timer key
to set the rated time in the range from 1
Timer
to 999min.
Push the key and then rotate control knob
Int key Int to set the interval for right-left running in
the range from 1 to 999s.
Clockwise rotate to increase program
values. Rotate anti-clockwise to decrease
Control knob
program values.
Press the knob, switch ON/OFF the unit.
Press the key, the lift goes up. Release the
Lift-up key key the lift stops and remains in that
position.
Lift-down key Press the key, the lift goes down. Release
Descriptions
