I. INLET GAS LINE SIZING:
The Table below is used to calculate the size (diameter) of the inlet gas line from the building regulator to the fryer manifold.
PIPE
LENGTH
1⁄2"
Feet
(13 mm)
(Meters)
15 62
(4.6) (1.7)
30 43
(9.1) (1.2)
45 35
(13.7) (1.0)
60 30
(18.3)
(0.8)
75
27
(22.9) (0.8)
90 25
(27.4) (0.7)
105
23
(32.0) (0.6)
120 21
(36.6) (0.6)
150 19
(45.7) (0.5)
180 17
(54.9) (0.5)
210 16
(64.0)
(0.4)
240 15
(73.2) (0.4)
270 14
(82.3)
(0.4)
300
14
(91.4) (0.4)
450 11
(137.2) (0.3)
600 10
(182.9) (0.3)
NOTE: 1) FT 3 /HR (M 3 /HR) values may vary due to heating value and specific gravity of gas supplied by local companies.
2) To determine the inlet gas line diameter for the distance between the fryer and main gas regulator, locate the FT 3 /HR (M 3 /HR) of gas required for the fryer and
pipe length and read the pipe diameter on the top row. For example: a 18" PAR-3-HE fryer operating on NATURAL GAS requires 110 FT 3 /HR (3.1 M 3 /HR)
of gas at the fryer's inlet gas manifold. If the fryer bank is located 60 feet from the building gas regulator, a 1" (25mm) diameter gas line MUST be installed
between the manifold and regulator.
J. INLET GAS REQUIREMENTS
VAT SIZE
Model PAR-3-HE
IN MM
18" (457)
NOTE: The flexible gas line used to connect the gas manifold to the building gas supply line must rated for the BTU/Hr (MJ/Hr) for the Fryer.
For example: the BTU/Hr (MJ/Hr) rating for a PAR-3-HE fryer is 110,000 BTU/Hr (116 MJ/Hr) and therefore would require a 3⁄4" diameter
gas line.
The Flexible Gas Line used to connect the gas manifold to the building gas supply line must be rated for the BTU/Hr (MJ/Hr)
designated for the Fryer. Flexible gas lines and their ratings stocked by Ultrafryer Systems are listed below:
NUMBER
24-322
24-323
24-456
INLET GAS LINE REQUIREMENTS
PIPE DIAMETERS (inches & (mm equivalents))
Maximum Allowable Flow (Shown in ft
3⁄4" 1" 11⁄4"
(19mm) (25mm) (32mm)
170 350 620
(4.7) (9.8) (17.4)
120 245 430
(3.4) (6.9) (12.0)
98 200 355
(2.7) (5.6) (9.9)
84 175 310
(2.4) (4.9) (8.7)
76 155 275
(2.1) (4.3) (7.7)
70 145 250
(2.0) (4.1) (7.0)
64 132 232
(1.8) (3.7) (6.5)
60 125 215
(1.7) (3.5) (6.0)
54 110 195
(1.5) (3.1) (5.5)
49 100 175
(1.4) (2.8) (4.9)
44 94 165
(1.2) (2.6) (4.6)
43 88 155
(1.2) (2.5) (4.3)
40 83 145
(1.1) (2.3) (4.1)
38 79 138
(1.1) (2.2) (3.9)
31 64 112
(0.9) (1.8) (3.1)
27 56 97
(0.8) (1.6) (2.7)

INLET GAS REQUIREMENTS

MODEL PAR-3-HE-3 GAS FRYERS
GAS VALVE PRESSURE (WC)
GAS TYPE IN
Butane 10.0
Natural 4.0
Propane 10.0
FLEXIBLE GAS LINES STOCKED BY ULTRAFRYER SYSTEMS
DESCRIPTION
3⁄4" (19mm) Diameter Flexible Gas Line (w/quick connect
couplings) 48" (1219mm) long. Connect-It SSGC75-48-UCQ
1" (25mm) Diameter Flexible Gas Line (w/quick connect
couplings) 48" (1219mm) long. Connect-It SSGC100-48-UCQ
11⁄4" (32mm) Diameter Flexible Gas Line (w/quick connect
couplings) 48" (1219mm) long. Connect-It SSGC125-48-UCQ
3 3
/hr (M /hr))
11⁄2" 2"
(38mm) (51mm)
960 2,000
(26.9) (56.0)
680 1,400
(19.0) (39.2)
530 1,150
(14.8) (32.2)
480 1,000
(13.4) (28.0)
430 890
(12.0) (24.9)
395 810
(11.1) (22.7)
370 (750
(10.4) (21.0)
340 700
(9.5) (19.6)
310 630
(8.7) (17.6)
280 570
(7.8) (16.0)
260 530
(7.3) (14.8)
240 500
(6.7) (14.0)
230 470
(6.4) (13.2)
215 440
(6.0) (12.3)
176 360
(4.9) (10.1)
152 315
(4.3) (8.8)
ORIFICE HOLE
MM
SIZE
(254) #36
(102) #16
(254) #32
Page 6 of 61
21⁄2" 3" 4"
(64mm) (76mm) (102mm)
3,500 5,400 11,200
(98.0) (151.2) (313.6)
2,450 3,800 7,900
(68.6) (106.4) (221.2)
2,000 3,200 7,900
(56.0) (89.6) (182.0)
1,760 2,700 5,600
(49.3) (75.6) (156.8)
1,560 2,450 5,000
(43.7) (68.6) (140.0)
1,430 2,260 4,550
(40.0) (63.3) (127.4)
1,300 2,100 4,200
(36.4) (58.8) (117.6)
1,200 1,950 4,000
(33.6) (54.6) (112.0)
1,080 1,750 3,550
(30.2) (49.0) (99.4)
960 1,600 3,200
(26.9) (44.8) (89.6)
890 1,450 3,000
(24.9) (40.6) (84.0)
840 1,350 2,800
(23.5) (37.8) (78.4)
780 1,300 2,650
(21.8) (36.4) (74.2)
750 1,250 2,500
(21.0) (35.0) (70.0)
630 1,000 2,050
(17.6) (28.0) (57.4)
530 860 1,750
(14.8) (24.1) (49.0)
RATING INLET GAS FLOW AT
BTU/HR MJ/HR
3
FT /HR
110,000 (116) 34
110,000 (116) 110
110,000 (116) 44
RATING
BTU/HR (MJ/HR)
225,000 (238)
435,000 (459)
875,000 (924)
STP
3
M /HR
(1.0)
(3.1)
(1.2)
