ULTRAFRYER GAS FRYER MODEL F-P25-14 / 18 / 20 / 24 OPERATION INSTRUCTIONS WARNING FOR YOUR SAFETY Improper Installation, adjustment, alteration, service, or main- Do not store or use gasoline or other flammable vapors or tenance can cause property damage, injury, or death. Read the liquids in the vicinity of this or other appliance.
Page 2
PREFACE This Manual was written and published by the Engineering Department, Ultrafryer Systems for use by personnel who will operate a Model P25 Gas Fryer in a commercial cooking environment. This appliance is intended for professional use and is to be operated by qualified personnel.
Ultrafryer Systems for first year failures only. The cost of labor to install the replacement vat will be covered by Ultrafryer Systems for vats, which fail within twelve (12) months from the date of initial start up. Labor for vat replacements after the first year is the responsibility of the owner.(2) Vats that fail within the second through fifth year will be...
B. SAFETY The major safety concern associated with the Ultrafryer Gas Fryer is burns from hot shortening. In order to prevent serious burns, good housekeeping habits are required. The floor in front of and the area around the fryer should be kept clean and dry.
E. OPERATING CONTROLS LOCATION MODEL PAR25 GAS FRYER Gas Regulator and Shutoff Valve High Limit Burner Docking Connection Main Drain Valve PN 30A169 rev Jan2008...
W.C. ; minimum inlet gas required, orifice size; and type of gas. This data is essential for proper identification when communicating with ULTRAFRYER SYSTEMS or requesting special parts or information. The rating plate is located on the inside of the Service Access door.
The Flexible Gas Line used to connect the gas manifold to the building gas supply line must be rated for the BTU/Hr (MJ/Hr) designated for the Fryer. Flexible gas lines and their ratings stocked by Ultrafryer Systems are listed below:...
A. GENERAL: Safe and satisfactory operation of a Model PAR25 gas fryer depends on its proper installation. Installation must conform to local codes or, in the absence of local codes, with the current National Fuel Gas Code ANSI Z223.1 (latest edi- tion).
NOTE: CONNECT-IT inc. 3⁄4" (19mm), 1" (25mm) and 1 1⁄4" (32mm) flexible gas hose 4 feet long (1219mm) with a quick disconnect coupling on one end is available from Ultrafryer Systems under PN 24322 (3⁄4" (19mm) hose), PN 24323 (1" (25mm) hose) and PN 24456 (1 1⁄4" (32mm) hose). These hoses are euipped with a fusible link, which melts at 361°F (183ºC) that will SHUT OFF the gas supply when it melts.
D. GAS CONNECTION: The gas supply (service) line must be the same size or greater than the inlet line of the appliance. THE GAS SUPPLY LINES MUST BE SIZED TO ACCOMMODATE ALL THE GAS FIRED EQUIPMENT THAT MAY BE CONNECTED TO THAT SUPPLY.
F. Cooking Computers All fryers from Ultrafryer are shipped with the applicable manual for the cooking computer or computers that are specific to that fryer. The following list shows the cooking computer types and their related manuals. NOTE: The appearance of a given cooking computer’s control panel may vary slightly depending upon the style of fryer on which the computer is installed.
Page 17
Ultrastat 21 Cooking Computer (refer to Manual P/N 30A189; French Version 30A189 FR) Ultrastat 11 Cooking Computer (refer to Manual P/N 30A191; French Version 30A191 FR) PN 30A169 rev Jan2008...
Initial calibration or adjustment is the responsibility of the customer and will not be covered by the Ultrafryer Systems warranty. NOTE: Calibration and adjustments must be performed by qualified personnel.
WARNING - To Avoid Injury: 1. Do not move a fryer filled with hot liquid. 2. Always wear oil-proof, insulated gloves when working with a fryer filled with hot oil. 3. Always drain hot oil into a metal container. Hot oil will melt plastic buckets or shatter glass. A.
F. CLOSING / SHUTDOWN INSTRUCTIONS: CLOSING: When closing at night; filter the shortening in the fryer, THOROUGHLY drain all filter lines and cover the fryer vessel. Turn the ON/OFF Switch on the fryer OFF and turn the Manual Gas Valve OFF. SHUTDOWN OR PROLONGED POWER FAILURE: Shutdown: Perform the following whenever a fryer is being shutdown for an extended period of time: Drain and discard the shortening.
Determine that the blower is operating. TROUBLESHOOTING CHART: Should a problem occur that cannot be corrected after performing the above CHECKS, contact an AUTHORIZED repairman and/or Ultrafryer Systems Customer Service 1-800-525-8130 and provide the information acquired while performing these checks.
Page 25
TROUBLESHOOTING CHART ITEM PROBLEMS POSSIBLE SOLUTIONS A. Check the Blower air pressure Switch by temporarily disconnecting the two (2) air switch wires and connecting them together. If the IGNITOR sparks when these wires are connected, the air pressure switch is defective and it will Main burner will not ignite.
CLEANING - Any item of equipment operates better and lasts longer when it is kept clean and properly maintained. The Gas Fryer is no exception. In order for this fryer to provide years of trouble-free service, it must be CLEANED and MAINTAINED according to instruc- tions herein and at the intervals listed below: TO ASSURE PRODUCING A QUALITY PRODUCT WHILE PROLONGING THE LIFE EXPECTANCY OF WARNING!!!
NOTE: The following applies only to those fryers that are equipped with a hard dock filtration assembly from Ultrafryer Systems. FILTER TUB ASSEMBLY - ENSURE all components of the filter tub have been thoroughly cleaned and that the Filter Screen has been assembled;...
Page 30
TECHNICAL ASSISTANCE, ORDERING INFORMATION PN 30A169 rev Jan2008...
(12% per annum) until full balance is paid. DAMAGES - Ultrafryer Systems is not responsible for damage occurring in transit. All deliveries must be inspected for damage to shipping containers prior to departure of the delivering carrier. Any damage must be documented on the receiving document to facilitate filing of freight claims.
Page 32
RECOMMENDED SPARE PARTS PN 30A169 rev Jan2008...
RECOMMENDED SPARE PARTS: To minimize downtime on the Model PAR25 gas fryer upon failure of a component part, at least one (1) of the following items should be kept as a spare part in the local area: MODEL PAR25 GAS FRYER RECOMMENDED SPARE PARTS LISTING Description Manufacturer’s Part Number...
Page 35
PARTS IDENTIFICATION: Locate the part on the following sketches and note the index number i.e, 3, 6, etc; then obtain the part number and description for that index number on the page facing the sketches. Use that part number when ordering a replacement part. ULTRAFRYER MODEL PAR25 GAS FRYER FRONT VIEW Note: Fryer shown is 18”...
Page 36
ULTRAFRYER MODEL PAR25 GAS FRYER REAR VIEW Note: Fryer shown is 14” Par25 with Filtration. For information on other fryer models, contact Ultrafryer Customer Service. � � � � � �� �� �� �� Note: Parts listed below are for 14” Par25 with Filtration. For information on other fryer models, contact Ultrafryer Customer Service. ITEM DESCRIPTION Model SMD 1204 Air Pressure Switch...
Page 38
PAR25 EZ DOCK FILTER TUB ASSEMBLY 14" With Micromesh Filter PN 12B112 14" With Magnepad Filter PN 12B177 � ITEM DESCRIPTION Filter Tub Scraper 12567 � Micromesh S/S Filter Screen Assembly with 12B113 StandPipe & Docking Assembly � Magnepad Magnesol Impregnated Filter 12B178 Pad with Standpipe and Docking Assembly Wash Down Hose Assembly...
Page 39
FILTER SCREEN ASSEMBLY ITEM DESCRIPTION Replacement Frame Set 21A284 Replacement “Upper” Screen 21A285 Replacement Baffle Assembly 21A286 Replacement “Lower” Screen 21A287 � �� � �� � � � �� STANDPIPE CLIP, BAFFLE AND MAGNEPAD ASSEMBLY PN 12B178 ITEM DESCRIPTION 1/2" (13mm) Black Iron Close Nipple 24003 3/8"(10mm) x 7"...
Page 40
ULTRAFRYER MODEL PAR25 GAS FRYER AUTOMATIC VAT CLEANER � � 14” PN 12B157 � � � � � � �� ����� ITEM DESCRIPTION Proximity Actuator Sensor 18A059 Cool II Handle 22734 1⁄2” (13mm) HH-2236 SQ Spray Nozzle 22A111 1⁄2" (13mm) x 90˚ Black Iron Elbow 24007 1⁄2"...
WIRING DIAGRAM - Since minor wiring changes may occur in the future, USE the diagram pasted to the fryer for circuit tracing and/or troubleshooting a gas fryer. PN 30A169 rev Jan2008...
