- Page 1 LNX-1600-E Series 16-Port Industrial Unmanaged Ethernet Switch, with 16*10/100Tx, 12-48VDC Power Input, E-mark Version Hardware Manual Version 1.0 (January 2021) ...
- Page 2 Antaira Technologies, LLC may make improvements and/or changes to the product and/or specifications of the product described in this manual, without prior notice. Antaira Technologies, LLC will not be liable for any technical inaccuracies or typographical errors found in this guide. Changes are periodically made ...
- Page 3 Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 Reorient or relocate the receiving antenna. ● ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is ...
- Page 4 Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 Industrial Ethernet Switches Industrial Grade Managed Ethernet Switches Hardware Manual Version 1.0 (January 2021) The manual supports the following models: ● LNX-1600-E LNX-1600-E-T ● ...
-
Page 5: Table Of Contents
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 Table of Contents 1 Overview 1 1.1 Product Hardware Features 1 1.2 Package Contents 2 1.3 Safety Precaution 2 2 Hardware Description 3 2.1 Physical Dimensions 3 ... -
Page 6: Overview
The LNX-1600-E series has a hardened design providing high EFT and ESD protection to prevent any unregulated voltage. It also has a dual power input support of 12~48VDC. There are two wide operating temperature models to support either a -10˚C to 65˚C or - 40˚C to 75˚C environment. There are also two ... -
Page 7: Package Contents
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 1.2 Package Contents LNX-1600-E(-T) Quick Installation Guide Wall mounting bracket set with screws Dust cover set 1.3 Safety Precaution Attention: If the DC voltage is supplied by an external circuit, please use a protection device on the power ... -
Page 8: Hardware Description
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 2 Hardware Description 2.1 Physical Dimensions Figure 2.1 , below, shows the physical dimensions of this product series: (W x D x H) is 46mm x 99mm x 142mm ... -
Page 9: Front View Panel
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 2.2 Front View Panel Figure 2.2 , below, shows the front panel of the product series: Figure 2.2 - Front View Panel 2.3 Top View Panel Figure 2.3 , below, shows the top panel of the product series: ... -
Page 10: Led Indicators
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 2.4 LED Indicators There are LED light indicators located on the front panel of the industrial Ethernet switch that display the power status and network status. Each LED indicator has a different color and has its own specific ... -
Page 11: Cabling
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 ● RJ45 Pin Assignments Crossover Cable Straight Through Cable Pin Number / Signal Pin Number / Signal Pin Number / Signal Pin Number / Signal 1 / RX+ ... -
Page 12: Wiring The Fault Alarm Contact
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 Figure 2.7 - Power Terminal Block Caution: Only use copper conductors, 1 25°C , tighten to 5 lbs. The wire gauge for the terminal block should range between 1 8~20 AWG . ... -
Page 13: Grounding Note
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 2.9 Grounding Note Grounding and wire routing help limit the effects of noise due to Electromagnetic Interference (EMI). Run the ground connection from the ground screw to the grounding surface prior to connecting devices. The grounding screw symbol is shown below in ... -
Page 14: Mounting Installation
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 3 Mounting Installation 3.1 DIN-Rail Mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see F igure 3.1 to learn how to install the DIN-Rail on the switch. ... -
Page 15: Wall Mounting
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 Figure 3.2 - Insert the Switch on the DIN-Rail Figure 3.3 - Stable the Switch on the DIN-Rail 3.2 Wall Mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown ... - Page 16 Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 Figure 3.4 - Remove DIN-Rail bracket from the Switch Below, in F igure 3.5 are the dimensions of the wall mounting bracket. Figure 3.5 - Wall Mounting Bracket Dimensions ...
-
Page 17: Hardware Installation
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 4 Hardware Installation 4.1 Installation Steps This section will explain how to install the industrial Ethernet switch: C aution: This device is intended for indoor use. ... -
Page 18: Maintenance And Service
Check for loose power connections, power losses or surges at the power outlet. ○ Please contact Antaira for technical support service if the problem still cannot be resolved. ● If the industrial switch LED indicators are normal and the connected cables are correct but the ... -
Page 19: Technical Specifications
Antaira Technologies - Industrial Ethernet Switches LNX-1600-E Series - Hardware Manual - v1.0 5 Technical Specifications Table 5.1 has the technical specifications for this product series. Technology IEEE 802.3 10Base-T Ethernet Standards IEEE 802.3 100Base-TX Fast Ethernet Processing Type Store and Forward ... - Page 20 (Antaira US Headquarter) + 844-268-2472 (Antaira Europe Office) +48-22-862-88-81 (Antaira Asia Office) +886-2-2218-9733 Please report any problems to Antaira: www.antaira.com / upport@antaira.com www.antaira.eu / nfo@antaira.eu www.antaira.com.tw / nfo@antaira.com.tw Any changes to this material will be announced on the Antaira website. 15 ...
